R279.90  Inc VAT
A low cost, high-performance microcontroller board built around Raspberry Pi's very own chip - the RP2040.
R69.90  Inc VAT
OS releases from Bullseye onwards will no longer support the older camera system and applications. There is no Python interface yet. An alternative to the old Picamera, imaginatively named Picamera2, is in development. Raspberry Pi OS Buster is still available to download if you’re not ready to use Bullseye
R1,269.90  Inc VAT
OKdo Raspberry Pi 4 8GB Model B Starter Kit (OKDO Pi48 metal starter kit)

Description

The OKdo Raspberry Pi 4 8GB Model B Starter Kit is an exclusive 8-piece kit that includes everything you need to start discovering the world of the Raspberry Pi. It includes essential hardware in a single box, access to an online step-by-step guide, and projects to get up and running faster than ever, effortlessly.

Details

Each kit contains the best performing Raspberry Pi 4 Model B board along with a reliable power supply, 2 X micro HDMI cables for dual display, SD Card Reader and a 32GB micro SD card with NOOBS operating system preloaded. As well as 3 x heat sinks and a unique aluminium case with an inbuilt fan for better thermal management. With all of the most current components on the market included in this Raspberry Pi 4 kit, it’s perfect for anyone interested in electronics at any level of experience, even beginners.

What’s in the box?

  • Raspberry Pi 4 Model B 8GB board.
  • 5.1v Power supply with 4 x interchangeable mains adaptors.
  • USB to USB-C cable with in-line switch.
  • 2 x Micro HDMI to HDMI cables.
  • SanDisk 3D Gen3 X3 256Gb 2-Plane NAND Flash Die for 32GB MicroSD Card. (with NOOBS 3.1.1 preloaded)
  • SD card reader.
  • 3 x Heat sinks.
  • Aluminium Raspberry Pi case with an integrated fan.

The Raspberry Pi

Raspberry Pi’s are compact computer boards roughly the size of a credit card, offering endless opportunities. The Pi was first designed to be a user-friendly alternative to more complicated computer boards but giving the same high specification output, allowing for the customer to do whatever they want with it. Whether you’re planning on introducing programming to children, or an engineer looking to make a complex-controlled system, simply plug into a monitor, keyboard, mouse and power supply and you’re ready to go.

The Raspberry Pi 4 is uniquely designed with high specifications to allow the product to carry out multiple tasks for increased usability:

  • Processor: Broadcom BCM2711 Processor Quad-core A72 (ARM v8) 64-bit SoC
  • Memory: 4GB LPDDR4 SDRAM
  • Bluetooth: Bluetooth 5.0WiFi: 2.4GHz/5.0GHz IEEE 802.11ac
  • Ethernet: Gigabit Ethernet
  • USB: 2 x USB 2.0 ports, 2 x USB 3.0 ports
  • Connection: 40-pin GPIO Header
  • HDMI: 2 x micro HDMI ports (up to 4Kp60 supported)
  • Video: 2-lane MIPI DSI display port, 2-lane MIPI CSI camera port
  • Audio: 4 Pole stereo output and composite video port
  • Multimedia: H.265 (4Kp60 decode), H.264 (1080p60 decode, 1080p30 encode. OpenGL ES 3.0 graphics.
  • Storage: microSD card slot for loading operating system and data storage
  • Input power: 5v DC via USB-C Connector (min 3A), 5v DC via GPIO header. POE enabled (PoE HAT required)
  • Operating Temperature: 0 to 50°C

Aluminium Case

This slick protective case made from aluminium includes 3 heat sinks and an integrated fan to ensure the Pi 4 stays cool and runs at maximum efficiency. Cut-outs are made on the case for the dual micro HDMI, Audio/Video, USB and Ethernet ports, as well as the USB-C power connector and access to the MicroSD card.

Memory?

You won’t be able to forget about this kit… With 4GB LPDDR4 SDRAM built on-board and a 32GB MicroSD card also included, this kit ensures speed and versatility. The 32GB card included meets the SD 5.1 Standard and has an R/W performance: up to 100/25MB/s.

FAQ’s

What’s the difference between to the Raspberry Pi 3b+ and the Raspberry Pi 4 Model B?

Raspberry pi 4 is the newest model of the raspberry pi series. Raspberry Pi 4 takes Pi to another level, with a performance that’s good enough to use in a pinch as a desktop PC, plus the ability to output 4K video at 60 Hz or power dual monitors. New features include:

  • A faster processor and GPU,
  • More and faster RAM,
  • The addition of USB 3 ports,
  • Dual Micro HDMI ports instead of a single HDMI connection and support for 4K output,
  • A higher bus speed that enables USB 3 support also allows the on-board Ethernet port to support true Gigabit connections (125 MB/s)

Where can I learn how to set up my Raspberry Pi Kit?

Visit our getting starter guide here, to get up and running. Then head to our projects hub for innovative ideas on what to do with your Raspberry Pi kit.

R2,599.90  Inc VAT
OKdo Raspberry Pi 4 4GB Basic Kit with Universal Power Supply (OKDO Pi44 19 black kit)
Description:

The Okdo Raspberry Pi 4 basic Kit UNI Version contains everything you need to get up and running with a Raspberry Pi 4 and is perfect for someone looking to start their Pi adventure. The kit includes our most popular accessories to help you on your coding journey, all provided neatly inside an OKdo box.

What's in the box?

1 x Raspberry Pi 4 – 4GB
1 x 2m micro-HDMI cable
1 x 32GB SD card preloaded with NOOBS software
1 x OKdo universal power supply
1 x Okdo exclusive black case
R1,829.90  Inc VAT
OKdo Raspberry Pi 4 4GB Model B Starter Kit (OKDO Pi44 metal starter kit)

Description

The OKdo Raspberry Pi 4 4GB Model B Starter Kit is an exclusive 8-piece kit that includes everything you need to start discovering the world of the Raspberry Pi. It includes essential hardware in a single box, access to an online step-by-step guide, and projects to get up and running faster than ever, effortlessly.

Details

Each kit contains the best performing Raspberry Pi 4 Model B board along with a reliable power supply, 2 X micro HDMI cables for dual display, SD Card Reader and a 32GB micro SD card with NOOBS operating system preloaded. As well as 3 x heat sinks and a unique aluminium case with an inbuilt fan for better thermal management. With all of the most current components on the market included in this Raspberry Pi 4 kit, it’s perfect for anyone interested in electronics at any level of experience, even beginners.

What’s in the box?

  • Raspberry Pi 4 Model B 4GB board.
  • 5.1v Power supply with 4 x interchangeable mains adaptors.
  • USB to USB-C cable with in-line switch.
  • 2 x Micro HDMI to HDMI cables.
  • SanDisk 3D Gen3 X3 256Gb 2-Plane NAND Flash Die for 32GB MicroSD Card. (with NOOBS 3.1.1 preloaded)
  • SD card reader.
  • 3 x Heat sinks.
  • Aluminium Raspberry Pi case with an integrated fan.

The Raspberry Pi

Raspberry Pi’s are compact computer boards roughly the size of a credit card, offering endless opportunities. The Pi was first designed to be a user-friendly alternative to more complicated computer boards but giving the same high specification output, allowing for the customer to do whatever they want with it. Whether you’re planning on introducing programming to children, or an engineer looking to make a complex-controlled system, simply plug into a monitor, keyboard, mouse and power supply and you’re ready to go.

The Raspberry Pi 4 is uniquely designed with high specifications to allow the product to carry out multiple tasks for increased usability:

  • Processor: Broadcom BCM2711 Processor Quad-core A72 (ARM v8) 64-bit SoC
  • Memory: 4GB LPDDR4 SDRAM
  • Bluetooth: Bluetooth 5.0WiFi: 2.4GHz/5.0GHz IEEE 802.11ac
  • Ethernet: Gigabit Ethernet
  • USB: 2 x USB 2.0 ports, 2 x USB 3.0 ports
  • Connection: 40-pin GPIO Header
  • HDMI: 2 x micro HDMI ports (up to 4Kp60 supported)
  • Video: 2-lane MIPI DSI display port, 2-lane MIPI CSI camera port
  • Audio: 4 Pole stereo output and composite video port
  • Multimedia: H.265 (4Kp60 decode), H.264 (1080p60 decode, 1080p30 encode. OpenGL ES 3.0 graphics.
  • Storage: microSD card slot for loading operating system and data storage
  • Input power: 5v DC via USB-C Connector (min 3A), 5v DC via GPIO header. POE enabled (PoE HAT required)
  • Operating Temperature: 0 to 50°C

Aluminium Case

This slick protective case made from aluminium includes 3 heat sinks and an integrated fan to ensure the Pi 4 stays cool and runs at maximum efficiency. Cut-outs are made on the case for the dual micro HDMI, Audio/Video, USB and Ethernet ports, as well as the USB-C power connector and access to the MicroSD card.

Memory?

You won’t be able to forget about this kit… With 4GB LPDDR4 SDRAM built on-board and a 32GB MicroSD card also included, this kit ensures speed and versatility. The 32GB card included meets the SD 5.1 Standard and has an R/W performance: up to 100/25MB/s.

FAQ’s

What’s the difference between to the Raspberry Pi 3b+ and the Raspberry Pi 4 Model B?

Raspberry pi 4 is the newest model of the raspberry pi series. Raspberry Pi 4 takes Pi to another level, with a performance that’s good enough to use in a pinch as a desktop PC, plus the ability to output 4K video at 60 Hz or power dual monitors. New features include:

  • A faster processor and GPU,
  • More and faster RAM,
  • The addition of USB 3 ports,
  • Dual Micro HDMI ports instead of a single HDMI connection and support for 4K output,
  • A higher bus speed that enables USB 3 support also allows the on-board Ethernet port to support true Gigabit connections (125 MB/s)

Where can I learn how to set up my Raspberry Pi Kit?

Visit our getting starter guide here, to get up and running. Then head to our projects hub for innovative ideas on what to do with your Raspberry Pi kit.

R2,229.90  Inc VAT
Raspberry Pi Engraved Official Stainless Steel Pen (RPi stainless pen)
Description:

Add some more goodies to your officially branded merch collection with this Raspberry Pi stainless steel engraved pen.

What's in the box?

1 x official stainless steel pen
R97.90  Inc VAT
Raspberry Pi 48W (8V DC, 6A) power supply for Build HAT (RPi build power supply 8V)
Description:

Official 48W (8V DC, 6A) power supply, designed for use with the Raspberry Pi Build HAT. Shipped with easily interchangeable heads for the UK, US, EU and Australia you can now use your Pi in all four corners of the world!

Power your Raspberry Pi Build HAT projects with the Raspberry Pi Build HAT Power Supply. This 48W power supply will power the Build HAT and connected LEGO® Technic™ motors, as well as your Raspberry Pi computer.
Compatible with LEGO Technic motors and sensors included in the LEGO® Education SPIKE™ Portfolio, the Build HAT combines the power of Raspberry Pi computing with easy building opportunities to help you make creative and robust projects.

Specifications:

Output
  • Output voltage: +8.0V DC
  • Minimum load current: 0.01A
  • Nominal load current: 6.0A
  • Maximum power: 48.0W
  • Load regulation: ±5%
  • Line regulation: ±5%
  • Ripple & noise: 200mVp-p
  • Rise time: 100ms maximum to regulation limits for DC outputs
  • Turn-on delay: 3000ms maximum at nominal input AC voltage and full load
  • Protection: Short circuit protection
  • Overcurrent protection
  • Overvoltage protection
  • Efficiency: 87.77% minimum (output current from 100%, 75%, 50%, 25%)
  • Output cable: 1.5m 16AWG
  • Output connector: Barrel connector 5.5mm × 2.1mm × 11mm Centre positive

Input
  • Voltage range: 100-240Vac (rated)
  • 96-264Vac (operating)
  • Frequency: 50/60Hz ±3Hz
  • Current: 1.2A maximum
  • Power consumption (no load): 0.1W maximum
  • Inrush current: No damage shall occur and the input fuse shall not blow

What's in the box?

1 x Official 48W power supply for Build HAT
R269.90  Inc VAT
Raspberry Pi4 Official USB-C 15.3W power supply White 5.1V 3A (Pi4 3A power white)

Description:

You will find a South African plug adapter here

The official Raspberry Pi USB-C power supply is designed to power the latest Raspberry Pi 4 Model B computers, which were released in June 2019.
Featuring a captive USB-C cable, the power supply is available in four different models to suit different international power sockets, and in two colours, white and black.

If you need to use the power supply for an earlier model RPi or the zero you'll need a type C to micro B adapter than you will find at https://www.pishop.co.za/store/rpi-power/usb-type-c-female-to-micro-usb-male-adapter

Specifications

Output
  • Output voltage: 5.1V DC
  • Minimum load current: 0A
  • Nominal load current: 3.0A
  • Maximum power: 15.3W
  • Load regulation: ±5%
  • Line regulation: ±2%
  • Ripple & noise: 120mVp-p
  • Rise time: 100ms maximum to regulation limits for DC outputs
  • Turn-on delay: 3000ms maximum at nominal input AC voltage and full load
  • Protection: Short circuit protection, Overcurrent protection, Over temperature protection
  • Efficiency: 81% minimum (output current from 100%,75%, 50%, 25%)72% minimum at 10% load
  • Output cable: 1.5m 18AWG
  • Output connector: USB Type-C


Input
  • Voltage range: 100-240Vac (rated)
  • 96-264Vac (operating)
  • Frequency: 50/60Hz ±3Hz
  • Current: 0.5A maximum
  • Power consumption (no load): 0.075W maximum
  • Inrush current: No damage shall occur and the input fuse shall not blow
Case material
UL94V-1

AC pin material
Brass (NI plated)

What's in the box:

1 x USB-C 15.3W power supply

WARNINGS
• This product should be operated in a well-ventilated environment.
• The connection of incompatible devices to this power supply may affect compliance, result in damage to the unit and invalidate the warranty.

SAFETY INSTRUCTIONS
To avoid malfunction or damage to this product please observe the following:
• Do not expose to water or moisture, or place on a conductive surface whilst in operation.
• Do not expose to heat from any source; this is designed for reliable operation at normal ambient room temperatures.
• Do not attempt to open or remove the power supply case.
R169.90  Inc VAT
Raspberry Pi4 Official USB-C 15.3W power supply Black 5.1V 3A (Pi4 3A power black)

Description:

You will find a South African plug adapter here

The official Raspberry Pi USB-C power supply is designed to power the latest Raspberry Pi 4 Model B computers, which were released in June 2019.
Featuring a captive USB-C cable, the power supply is available in four different models to suit different international power sockets, and in two colours, white and black.

If you need to use the power supply for an earlier model RPi or the zero you'll need a type C to micro B adapter than you will find at https://www.pishop.co.za/store/rpi-power/black-usb-type-c-female-to-micro-usb-male-adapter

Specifications

Output
  • Output voltage: 5.1V DC
  • Minimum load current: 0A
  • Nominal load current: 3.0A
  • Maximum power: 15.3W
  • Load regulation: ±5%
  • Line regulation: ±2%
  • Ripple & noise: 120mVp-p
  • Rise time: 100ms maximum to regulation limits for DC outputs
  • Turn-on delay: 3000ms maximum at nominal input AC voltage and full load
  • Protection: Short circuit protection, Overcurrent protection, Over temperature protection
  • Efficiency: 81% minimum (output current from 100%,75%, 50%, 25%)72% minimum at 10% load
  • Output cable: 1.5m 18AWG
  • Output connector: USB Type-C


Input
  • Voltage range: 100-240Vac (rated)
  • 96-264Vac (operating)
  • Frequency: 50/60Hz ±3Hz
  • Current: 0.5A maximum
  • Power consumption (no load): 0.075W maximum
  • Inrush current: No damage shall occur and the input fuse shall not blow
Case material
UL94V-1

AC pin material
Brass (NI plated)

WARNINGS
• This product should be operated in a well-ventilated environment.
• The connection of incompatible devices to this power supply may affect compliance, result in damage to the unit and invalidate the warranty.

What's in the box:

1 x USB-C 15.3W power supply

SAFETY INSTRUCTIONS
To avoid malfunction or damage to this product please observe the following:
• Do not expose to water or moisture, or place on a conductive surface whilst in operation.
• Do not expose to heat from any source; this is designed for reliable operation at normal ambient room temperatures.
• Do not attempt to open or remove the power supply case.
R169.90  Inc VAT
Raspberrry Pi RP2040 microcontroller (RPi RP2040 microcontroller)
Description:

Raspberry Pi RP2040 is the first microcontroller designed in-house at Raspberry Pi (“Raspberry Silicon”).

It features:
• Dual-core Arm Cortex-M0 @ 133MHz
• 264KB of on-chip RAM
• Support for up to 16MB of off-chip Flash memory via a QSPI bus
• DMA controller
• Interpolator and integer divider peripherals
• 30 GPIO pins, 4 of which can be used as analogue inputs
• 2 × UARTs, 2 × SPI controllers, and 2 × I2C controllers
• 16 × PWM channels
• 1 × USB 1.1 controller and PHY, with host and device support
• 8 × Raspberry Pi Programmable I/O (PIO) state machines
• USB mass-storage boot mode with UF2 support, for drag-and-drop programming


Please see the RP2040 datasheet for more details

and Hardware Design with RP2040

To date, RP2040 has only been available on Raspberry Pi Pico, and as a component to a limited number of partners. We now cover the availability of RP2040 as a component to the broad market in single-unit quantities. Bulk quantities on reels of 500 and more available soon.

R18.27  Inc VAT
Raspberry Pi Zero 2 W (zero 2 W board)




Description:


Raspberry Pi Zero 2 W is the latest product in our most affordable range of single-board computers. The successor to the breakthrough Raspberry Pi Zero W, Raspberry Pi Zero 2 W is a form factor–compatible drop-in replacement for the original board.

The board incorporates a quad-core 64-bit Arm Cortex-A53 CPU, clocked at 1GHz. At its heart is a Raspberry Pi RP3A0 system-in-package (SiP), integrating a Broadcom BCM2710A1 die with 512MB of LPDDR2 SDRAM. The upgraded processor provides Raspberry Pi Zero 2 W with 40% more single-threaded performance, and five times more multi-threaded performance, than the original single-core Raspberry Pi Zero.

Raspberry Pi Zero 2 W offers 2.4GHz 802.11 b/g/n wireless LAN and Bluetooth 4.2, along with support for Bluetooth Low Energy (BLE), and modular compliance certification.

The board has a microSD card slot, a CSI-2 camera connector, a USB On-The-Go (OTG) port, and an unpopulated footprint for a HAT-compatible 40-pin GPIO header. It is powered via a micro USB socket. Video output is via a mini HDMI port; composite video output can easily be made available via test points if needed.

Sharing the same form factor as the original Raspberry Pi Zero, Raspberry Pi Zero 2 W fits inside most existing Raspberry Pi Zero cases.



Specifications:

Form factor: 65mm × 30mm
Processor: Broadcom BCM2710A1, quad-core 64-bit SoC (Arm Cortex-A53 @ 1GHz)
Memory: 512MB LPDDR2
Connectivity:
• 2.4GHz IEEE 802.11b/g/n wireless LAN, Bluetooth 4.2, BLE, onboard antenna
• 1 × USB 2.0 interface with OTG
• HAT-compatible 40-pin I/O header footprint
• microSD card slot
• Mini HDMI port
• CSI-2 camera connector
Video:
• HDMI interface
• Composite video
Multimedia:
• H.264, MPEG-4 decode (1080p30)
• H.264 encode (1080p30)
• OpenGL ES 1.1, 2.0 graphics
Input power: 5V DC 2.5A
Operating temperature: -20°C to 70°C
Production lifetime: Raspberry Pi Zero 2 W will remain in production until at least January 2028
Compliance: For a full list of local and regional product approvals,
please visit pip.raspberrypi.com

WARNINGS
• Any external power supply used with Raspberry Pi Zero 2 W shall comply with relevant regulations and standards applicable in the country of intended use.
• This product should be operated in a well-ventilated environment, and if used inside a case, the case should not be covered.
• Whilst in use, this product should be placed on a stable, flat, non-conductive surface, and should not be contacted by conductive items.
• The connection of incompatible devices to Raspberry Pi Zero 2 W may affect compliance, result in damage to the unit, and invalidate the warranty.
• All peripherals used with this product should comply with relevant standards for the country of use and be marked accordingly to ensure that safety and performance requirements are met. These articles include but are not limited to
keyboards, monitors, and mice when used in conjunction with Raspberry Pi Zero 2 W.
• The cables and connectors of all peripherals used with this product must have adequate insulation so that relevant safety requirements are met.

SAFETY INSTRUCTIONS
To avoid malfunction or damage to this product, please observe the following:
• Do not expose to water or moisture, or place on a conductive surface whilst in operation.
• Do not expose to heat from any source; Raspberry Pi Zero 2 W is designed for reliable operation at normal ambient temperatures.
• Take care whilst handling to avoid mechanical or electrical damage to the printed circuit board and connectors.
• Whilst it is powered, avoid handling
R279.90  Inc VAT
Raspberry Pi Pico with presoldered headers (RPi Pico H board)

Description:

This is an official Raspberry Pico that has had headers professionally pre-soldered on by a South African electronic manufacturing company.


Raspberry Pi Pico, a microcontroller board built on silicon designed by Raspberry Pi.

Whether you choose to use our C/C SDK, or the official MicroPython port, everything you need to get started is here. You’ll also find links to the technical documentation for both the Raspberry Pi Pico microcontroller board and our RP2040 microcontroller chip.



Board Specifications:
  • RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
  • Dual-core ARM Cortex M0 processor, flexible clock running up to 133 MHz
  • 264kB of SRAM, and 2MB of on-board Flash memory
  • Castellated module allows soldering direct to carrier boards
  • USB 1.1 Host and Device support
  • Low-power sleep and dormant modes
  • Drag & drop programming using mass storage over USB
  • 26 multi-function GPIO pins
  • 2×SPI, 2×I2C, 2×UART, 3×12-bit ADC, 16×controllable PWM channels
  • Accurate clock and timer on-chip
  • Temperature sensor
  • Accelerated floating point libraries on-chip
  • 8×Programmable IO (PIO) state machines for custom peripheral support


Download Pinout Diagram


Documentation

Documentation for the Raspberry Pi Pico board and the RP2040 microcontroller:

The API level Doxygen documentation for the Raspberry Pi Pico C/C SDK is available as a micro-site.

While Raspberry Pi Pico does not come with anything soldered to its pads, we will recommend that users fit 2.54mm pitch male pin strip headers.

Resources:

https://www.raspberrypi.org/blog/raspberry-pi-silicon-pico-now-on-sale/

https://www.raspberrypi.org/products/raspberry-pi-pico/

https://www.youtube.com/watch?v=ZY-HrRGCQ4w

Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts

YouTube video on Pico by Jeff Geerling

https://projects.raspberrypi.org/en/projects/getting-started-with-the-pico/1
R99.90  Inc VAT
RP2040-Plus Pico-like MCU Board Based on Raspberry Pi MCU RP2040 Plus version with pre-soldered headers (WS RP2040-PLUS WH)
RP2040 MCU Board Plus with pre-soldered headers, a Pico-like MCU board based on Raspberry Pi RP2040. Compatible with most of the Raspberry Pi Pico add-on modules.


Board specifications

Need more Flash for Raspberry Pi Pico? Dislike the outdated Micro USB connector? All these problems are solved by our RP2040-Plus now.

Same as Raspberry Pi Pico, it incorporates the RP2040 microcontroller, with dual-core Arm Cortex M0+ processor running up to 133 MHz, and 26x multi-function GPIO pins.

What's different, it features onboard 4MB Flash, USB-C connector, recharge header, and higher current DC-DC chip.

Key features include:

  •     RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
  •     Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz
  •     264KB of SRAM, and 4MB of on-board Flash memory
  •     USB-C connector, keeps it up to date, easier to use
  •     Lithium battery recharge/discharge header, suitable for mobile devices
  •     Onboard DC-DC chip TPS63000, high efficiency DC-DC buck-boost chip, 1.8A current switch
  •     Castellated module allows soldering direct to carrier boards
  •     USB 1.1 with device and host support
  •     Low-power sleep and dormant modes
  •     Drag-and-drop programming using mass storage over USB
  •     26 × multi-function GPIO pins
  •     2 × SPI, 2 × I2C, 2 × UART, 3 × 12-bit ADC, 16 × controllable PWM channels
  •     Accurate clock and timer on-chip
  •     Temperature sensor
  •     Accelerated floating-point libraries on-chip
  •     8 × Programmable I/O (PIO) state machines for custom peripheral support
C/C++,MicroPython support

Comprehensive SDK, dev resources, tutorials to help you easily get started



26 × multi-function GPIO pins

configurable pin function, allows flexible development and integration



What's On Board?



  1. LED user LED (not power indicator)
  2. ETA6096 high efficiency Lithium battery recharge manager
  3. TPS63000 high efficiency DC-DC buck-boost chip
  4. USB Type-C connector
  5. BOOT button press it when resetting to enter download mode
  6. W25Q32JVSSIQ 4MB NOR-Flash
  7. RESET button
  1. RP2040 dual-core processor, up to 133MHz operating frequency
  2. Battery header MX1.25 header, for 3.7V Lithium battery, allows recharging the battery and powering the board at the same time
  3. Pinout compatible with Raspberry Pi Pico
  4. USB test points connecting to USB interface
  5. BOOT test point connecting to BOOT button
  6. DEBUG points
outline dimensions



Wiki: RP2040-Plus

What's in the box?

1 x WS RP2040-Plus WH
R189.90  Inc VAT
Raspberry Pi Pico Maker kit 1 (Pico maker kit 1)
Description:

This Starter Kit is based around the Raspberry Pi Pico development board which features the Raspberry Pi RP2040 microcontroller chip.

Whats in the box:

Resources:

Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts

R117.69  Inc VAT
Raspberrry Pi RP2040 microcontroller IC 7inch reel of 500 (RP2040 7inch reel 500)
Raspberry Pi RP2040 is the first microcontroller designed in-house at Raspberry Pi (“Raspberry Silicon”).

It features:
• Dual-core Arm Cortex-M0 @ 133MHz
• 264KB of on-chip RAM
• Support for up to 16MB of off-chip Flash memory via a QSPI bus
• DMA controller
• Interpolator and integer divider peripherals
• 30 GPIO pins, 4 of which can be used as analogue inputs
• 2 × UARTs, 2 × SPI controllers, and 2 × I2C controllers
• 16 × PWM channels
• 1 × USB 1.1 controller and PHY, with host and device support
• 8 × Raspberry Pi Programmable I/O (PIO) state machines
• USB mass-storage boot mode with UF2 support, for drag-and-drop programming


Please see the RP2040 datasheet for more details

and Hardware Design with RP2040

To date, RP2040 has only been available on Raspberry Pi Pico, and as a component to a limited number of partners. We now cover the availability of RP2040 as a component to the broad market in single-unit quantities. Bulk quantities on reels of 500.
R8,760.69  Inc VAT
Raspberry Pi Build HAT for LEGO (RPi build hat)
Read more in HackSpace magazine issue 49 at https://hackspace.raspberrypi.com/issues/49

Description:


The Raspberry Pi Build HAT combines the power of Raspberry Pi computing with LEGO® hands-on learning to enable a fun and creative learning experience for students, teachers and makers.

The Build HAT is compatible with the most recent generation of LEGO® Technic™ motors, and with sensors included in the LEGO® Education SPIKE™ Prime portfolio.

The Build HAT is the second Raspberry Pi product, after Raspberry Pi Pico, to be powered by the Raspberry Pi RP2040 microcontroller.



Specifications:

• Controls up to 4 motors and sensors.
• Powers the Raspberry Pi (when used with a suitable external PSU).
• Easy to use from Python on the Raspberry Pi.


What's in the box?

1 x Raspberry Pi Build HAT for LEGO

Build HAT Links


LEGO Links

R469.90  Inc VAT
Raspberry Pi Pico (RPi Pico board)

https://www.raspberrypi.org/blog/raspberry-pi-silicon-pico-now-on-sale/

https://www.raspberrypi.org/products/raspberry-pi-pico/

https://www.youtube.com/watch?v=ZY-HrRGCQ4w

Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts

YouTube video on Pico by Jeff Geerling

Raspberry Pi Pico, a microcontroller board built on silicon designed here at Raspberry Pi.

Whether you choose to use our C/C++ SDK, or the official MicroPython port, everything you need to get started is here. You’ll also find links to the technical documentation for both the Raspberry Pi Pico microcontroller board and our RP2040 microcontroller chip.



Board Specifications

  • RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
  • Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz
  • 264kB of SRAM, and 2MB of on-board Flash memory
  • Castellated module allows soldering direct to carrier boards
  • USB 1.1 Host and Device support
  • Low-power sleep and dormant modes
  • Drag & drop programming using mass storage over USB
  • 26 multi-function GPIO pins
  • 2×SPI, 2×I2C, 2×UART, 3×12-bit ADC, 16×controllable PWM channels
  • Accurate clock and timer on-chip
  • Temperature sensor
  • Accelerated floating point libraries on-chip
  • 8×Programmable IO (PIO) state machines for custom peripheral support


Download Pinout Diagram


Documentation

Documentation for the Raspberry Pi Pico board and the RP2040 microcontroller:

The API level Doxygen documentation for the Raspberry Pi Pico C/C++ SDK is available as a micro-site.

While Raspberry Pi Pico does not come with anything soldered to its pads, we will recommend that users fit 2.54mm pitch male pin strip headers.


A low cost, high-performance microcontroller board built around Raspberry Pi's very own chip - the RP2040.
R69.90  Inc VAT
RP2040-Zero Pico-like MCU Board Based on Raspberry Pi MCU RP2040 Mini ver with pre-soldered headers (WS RP2040-Zero WH)
RP2040 MCU Board Zero, a Pico-like MCU board based on Raspberry Pi RP2040, Castellated module, suitable for SMD applications. Pre-soldered Headers.


Board specifications

  •     RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
  •     Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz
  •     264KB of SRAM, and 2MB of on-board Flash memory
  •     USB-C connector, keeps it up to date, easier to use
  •     Castellated module allows soldering direct to carrier boards
  •     USB 1.1 with device and host support
  •     Low-power sleep and dormant modes
  •     Drag-and-drop programming using mass storage over USB
  •     29 × multi-function GPIO pins (20× via edge pinout, others via solder points)
  •     2 × SPI, 2 × I2C, 2 × UART, 4 × 12-bit ADC, 16 × controllable PWM channels
  •     Accurate clock and timer on-chip
  •     Temperature sensor
  •     Accelerated floating-point libraries on-chip
  •     8 × Programmable I/O (PIO) state machines for custom peripheral support
C/C++,MicroPython support

Comprehensive SDK, dev resources, tutorials to help you easily get started



29 × multi-function GPIO pins

configurable pin function, allows flexible development and integration



What's On Board?



  1. USB Type-C connector
  2. W25Q16JVUXIQ 2MB NOR-Flash
  3. BOOT button press it when resetting to enter download mode
  4. RESET button
  5. WS2812 cool RGB LED
  1. ME621 low dropout LDO, max current 800MA
  2. RP2040 dual-core processor, up to 133MHz operating frequency
  3. RP2040 pins 10x solder points, 9 of which are for GPIO
outline dimensions


Wiki: RP2040-Zero

What's in the box?

1 x RP2040-Zero

R109.90  Inc VAT
Raspberry Pi Power over Ethernet Plus (POE ) HAT (RPi POE HAT)
Description:

The Raspberry Pi PoE HAT is an add-on board for Raspberry Pi computers with PoE pins, including Raspberry Pi 3B and Raspberry Pi 4. It is used to power Raspberry Pi via an Ethernet cable, provided that power-sourcing equipment is installed on the Ethernet network. The HAT also includes a fan that will cool the Raspberry Pi processor.

Specifications:

Standard: IEEE 802.3at-2003 PoE
Input voltage: 37–57 V DC, Class 4 device
Output power: 5 V DC/4 A
Cooling: 25 mm × 25 mm brushless fan delivering 2.2 CFM for processor cooling

Features:
  • Fully isolated switched-mode power supply
  • Fan control

Operating temperature: 0 °C to 50 °C
Production lifetime: The Raspberry Pi PoE HAT will remain in production until at least January 2027
Compliance: For a full list of local and regional product approvals, please visit www.raspberrypi.org/compliance

Physical specifications


What's in the box?:

1 x Power over Ethernet Plus (POE ) HAT

WARNINGS

• This product shall only be connected to a Raspberry Pi via the four PoE pins.
• Any external power-sourcing equipment/power injector used to enable an Ethernet network shall comply with relevant regulations and standards applicable in the country of intended use.
• This product should be operated in a well ventilated environment, and if used inside a case, the case should not be covered.
• The connection of incompatible devices to the GPIO connection of a Raspberry Pi computer may affect compliance and result in damage to the unit and invalidate the warranty.
• All peripherals used with this product should comply with relevant standards for the country of
use and be marked accordingly to ensure that safety and performance requirements are met.
These articles include but are not limited to keyboards, monitors and mice when used in conjunction with Raspberry Pi computers.
• Where peripherals are connected that do not include the cable or connector, the cable or connector must offer adequate insulation and operation in order that the relevant performance and safety requirements are met.


SAFETY INSTRUCTIONS

To avoid malfunction or damage to this product, please observe the following:
• Do not expose to water or moisture, or place on a conductive surface whilst in operation.
• Do not expose to heat from any source. Raspberry Pi computers and the Raspberry Pi PoE HAT are designed for reliable operation at normal ambient room temperatures.
• Take care whilst handling to avoid mechanical or electrical damage to the printed circuit board
and connectors.
• Avoid handling the printed circuit board whilst it is powered, and handle it only by the edges to minimise the risk of electrostatic discharge damage.
R409.90  Inc VAT
Raspberry Pi Zero 2 W All In One Kit with OTG (Zero2W All in one kit)
Description:

This Starter Kit is a perfect starting point to get you up and running with your RPI Zero so you can get Playing/Making/Prototyping etc ASAP.

What's in the box:

Resources:

Getting Started with Raspberry Pi
More on Raspberry Pi OS


R1,099.90  Inc VAT
R1,154.20
Raspberry Pi HQ camera add-on kit (HQ cam add-on kit)
Please note: Raspberry Pi board is not included

Description:


This is an integrated bracket case independently designed by Yahboom, which supports Raspberry Pi 4B/3B /3B. It is composed of two upper and lower acrylic plates. The upper acrylic cover comes with mounting holes for fixing the official Raspberry Pi HQ camera. The lower acrylic cover has reserved holes for a cooling fan, display, and 40Pin pin headers, allowing any external devices to be connected to the Raspberry Pi board. We will also provide a detailed installation video, and users can install it easily through the screw copper pillar.

If you're using this tripod stand with a camera, its versatility also allows you to get shots from various angles. The stand comes with adjustable socket joints and flexible feet. You can bend the feet at your will for perfect photos!

This octopus tripod stand is compatible with the Raspberry Pi HQ camera module.(Cam included)


Features:

  • A unique all-in-one bracket shell.
  • Supports the Raspberry Pi official HQ cameras.(INCLUDED)
  • Compatible with Raspberry boards:(BOARD NOT INCLUDED)
    • Raspberry Pi 4 Model B 2GB
    • Raspberry Pi 4 Model B 4GB
    • Raspberry Pi 4 Model B 8GB
    • Raspberry Pi 3 Model B
    • Raspberry Pi 3 Model B
  • Suitable holes for cooling fans, cameras, display screens, and 40Pin pin headers.


What's in the box?

1 x Acrylic top and bottom plate
1 x 5V fan
1 x Plastic rivet set to mount fan
1 x Spacer and screw set
1 x flexible portable camera tripod black
1 x Raspberry Pi HQ cam with ribbon

What You will need:

OS releases from Bullseye onwards will no longer support the older camera system and applications. There is no Python interface yet. An alternative to the old Picamera, imaginatively named Picamera2, is in development. Raspberry Pi OS Buster is still available to download if you’re not ready to use Bullseye
R1,269.90  Inc VAT
Raspberry Pi Pico Maker kit 2 power supply 5V 2A (Pico maker kit 2 white)

Description:

This Starter Kit is based around the Raspberry Pi Pico development board which features the Raspberry Pi RP2040 microcontroller chip.

Whats in the box:


Resources:

Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts


R253.90  Inc VAT
R277.60
Per Page      1 - 20 of 117
