Cinko 10 - 10W Solar Panel (10W Solar panel)
Description:
Aesthetic appearance with excellent efficiency based on innovative photovoltaic technologies. They feature high quality, strong aluminum frame, passing mechanical load testing 5400 Pa and wind pressure 2400Pa
Polycrystalline solar panels can last up to 25 years, after which the efficiency can drop as electrical forces cause their crystals to separate.
Specifications:
Aesthetic appearance with excellent efficiency based on innovative photovoltaic technologies. They feature high quality, strong aluminum frame, passing mechanical load testing 5400 Pa and wind pressure 2400Pa
Polycrystalline solar panels can last up to 25 years, after which the efficiency can drop as electrical forces cause their crystals to separate.
Specifications:
- Cell: Poly-crystalline solar cell 78 x 22 mm.
- No. of Cells (Connections): 36 (4x9).
- Panel Dimensions: 280mm x 350mm x 17 mm.
- Weight: 1 kg.
- Connectors and Cables: Available upon request.
Electric performance at STC *
- Maximum Power: 10 Wp.
- Power Tolerance: 0/ 5 Wp.
- Maximum Power Voltage: 18 V.
- Maximum Power Current: 0.56 A.
- Open Circuit Voltage: 22.1 V.
- Short Circuit Current: 0.73 A.
5V Monocrystalline 1W Mini Solar Panel (5V 1W solar panel)
Description:
Build Your DIY Powered Models,Solar Display and Solar Toys. This 5V solar panel is lightweight, and durable, making it perfect for any small on the go project.
Specifications:
1x 5V Solar panel
Build Your DIY Powered Models,Solar Display and Solar Toys. This 5V solar panel is lightweight, and durable, making it perfect for any small on the go project.
Specifications:
- Power: 1W
- Voltage: 5V
- Material:Monocrystalline Silicon
- Size: 60x110mm
1x 5V Solar panel
Ideal for your dc electronic projects.
15A 45V Schottky Diode for solar panel (schottky diode 15A 45V)
Description:
Schottky diodes are used in photovoltaic (PV) systems to prevent a reverse current flowing through the PV modules.
They are used in stand-alone ("off-grid") systems to prevent batteries from discharging through the solar cells at night.
Features:
15A 45V
What's in the box:
1 x Schottky Diode
Resources:
Intoduction
Basics, Types, Characteristics, Applications & Packages
Schottky diodes are used in photovoltaic (PV) systems to prevent a reverse current flowing through the PV modules.
They are used in stand-alone ("off-grid") systems to prevent batteries from discharging through the solar cells at night.
Features:
15A 45V
What's in the box:
1 x Schottky Diode
Resources:
Intoduction
Basics, Types, Characteristics, Applications & Packages
6V/12V 10A Solar PWM Charge Regulator With Intelligent LED Indicator (mini solar charge controller)
Description:
A PWM (pulse width modulation) controller can be thought of as an (electronic) switch between the solar panels and the battery: The switch is ON when the charger mode is in bulk charge mode. The switch is “flicked” ON and OFF as needed (pulse width modulated) to hold the battery voltage at the absorption voltage.
A great charge control module for smaller sized solar projects
Features:
PWM controller,Long standby time
Three stage charging can effectively improve battery life.
Easy installation and easy operation
LED indicator, battery power display
Manual adjustable discharge mode
Specifications:
Charging mode: PWM
System current:5A/10A
Voltage:6V/12V
Interior input power:≤30W/≤60W
Overload, short circuit protection: 1.5 times rated current, five minutes off;Five minutes to recover
Rated voltage no-load current:≤6mA
Package includes:
1x Solar controller
1x User manual
A PWM (pulse width modulation) controller can be thought of as an (electronic) switch between the solar panels and the battery: The switch is ON when the charger mode is in bulk charge mode. The switch is “flicked” ON and OFF as needed (pulse width modulated) to hold the battery voltage at the absorption voltage.
A great charge control module for smaller sized solar projects
Features:
PWM controller,Long standby time
Three stage charging can effectively improve battery life.
Easy installation and easy operation
LED indicator, battery power display
Manual adjustable discharge mode
Specifications:
Charging mode: PWM
System current:5A/10A
Voltage:6V/12V
Interior input power:≤30W/≤60W
Overload, short circuit protection
Rated voltage no-load current:≤6mA
Package includes:
1x Solar controller
1x User manual
130A High Precision DC Watt Meter And Power Analyzer (DC Power analyzer)
Description:
We found this little unit great to measure our incoming solar power versus outgoing battery load on a second unit
Examples of Uses:
How Much Power Does my Fridge Use - with the Battery connected to the SOURCE side and Car Fridge (or other accessory) connected to the LOAD side. The Watt Meter shows the current into the Fridge, voltage and power at the battery and accumulates the Ah and Wh while the fridge is running.
How much charge is going into my battery - With a battery charger (or alternator) connected to the SOURCE side and the aux battery connected to the LOAD side, the Watt Meter shows the charging current into the battery, the voltage and charging power at the battery and accumulates the charge (Ah) and energy (Wh) into the battery.
What is the output of my solar panel - With a solar panel connected to the SOURCE side and solar regulator connected to the LOAD side, the Watt Meter shows the charging current into the regulator, the voltage and charging power at the solar panel and accumulates the charge (Ah) and energy (Wh) into the regulator.
How much charge is my solar panel putting into my battery - Now with a solar regulator connected to the SOURCE side and battery connected to the LOAD side, the Watt Meter shows the charging current into the battery, the voltage and charging power at the regulator and accumulates the charge (Ah) and energy (Wh) into the battery.
Specification:
English Manual please click here
Package Includes:
1x 130A High Precision Battery Watt Meter And Power Analyzer
We found this little unit great to measure our incoming solar power versus outgoing battery load on a second unit
Examples of Uses:
How Much Power Does my Fridge Use - with the Battery connected to the SOURCE side and Car Fridge (or other accessory) connected to the LOAD side. The Watt Meter shows the current into the Fridge, voltage and power at the battery and accumulates the Ah and Wh while the fridge is running.
How much charge is going into my battery - With a battery charger (or alternator) connected to the SOURCE side and the aux battery connected to the LOAD side, the Watt Meter shows the charging current into the battery, the voltage and charging power at the battery and accumulates the charge (Ah) and energy (Wh) into the battery.
What is the output of my solar panel - With a solar panel connected to the SOURCE side and solar regulator connected to the LOAD side, the Watt Meter shows the charging current into the regulator, the voltage and charging power at the solar panel and accumulates the charge (Ah) and energy (Wh) into the regulator.
How much charge is my solar panel putting into my battery - Now with a solar regulator connected to the SOURCE side and battery connected to the LOAD side, the Watt Meter shows the charging current into the battery, the voltage and charging power at the regulator and accumulates the charge (Ah) and energy (Wh) into the battery.
Specification:
| Item Name | Watt Meter and Power Analyzer |
| Item NO. | FT08 |
| Operation Voltage | 4.8V-60V |
| Measures Range | 0-130A, resolution 0.01A; 0-60V, resolution 0.01v; 0-6554W, resolution 0.1w; 0-65Ah,resolution 0.001An; 0-6441Wh,resolution 0.1Wh; |
| LCD | 16 x 2, backlit LCD display |
| Size | 85 mm x 43 mm x 25 mm (3.35 in x 1.69 in x 0.98 in) |
| Weight | 82g |
| Color | Black |
English Manual please click here
Package Includes:
1x 130A High Precision Battery Watt Meter And Power Analyzer
We found this little unit great to measure our incoming solar power versus outgoing battery load on a second unit
Solar Power Management Module, for 6V~24V Solar Panel (WS solar manager)
Overview
Dimensions
Development Resources
CAUTION:
DO NOT put any non-rechargeable battery, like dry cell, into the battery holder. Serious consequences including explosion may occur if you try to charge a non-rechargeable battery.
DO NOT put any non-rechargeable battery, like dry cell, into the battery holder. Serious consequences including explosion may occur if you try to charge a non-rechargeable battery.
SAFETY MEASUREMENTS:
- Li-ion and Li-po batteries are quite unstable. They may cause fire, personal injury, or property damage, if they're not properly recharged or used.
- Do not reversely connect the polarities when recharging or discharging the battery. Do not use inferior charger/charging panel to recharge the battery.
- Do not mix use old batteries with new ones, avoid using batteries of different brands.
- When buying Lithium battery, should always make sure the battery specification is compatible with the expansion board. Choose batteries from formal manufacturer, and ensure the batteries will work stably and safely by aging test.
- Lithium batteries have limited cycle life, they will also deteriorate as time goes by. Should be replaced with new ones when the batteries reaching their max cycle life, or working over two years, whichever comes first.
- Should be placed carefully and properly, keep it away from inflammables and explosives articles, away from children, avoid any safety accident caused by careless storage.
Overview
This solar power management module is designed for 6V~24V solar panel. It can charge the 3.7V Li battery through solar panel or USB connection, and provides 5V/1A regulated output.
The module features MPPT (Maximum Power Point Tracking) function and multi protection circuits, therefore, it is able to keep working with high-efficiency, stability, and safety. It is suited for solar powered, low-power IoT, and other environmental protection projects.
Features- Supports MPPT (Maximum Power Point Tracking) function, maximizing the efficiency of the solar panel
- Supports solar panel / USB connection battery charging
- For 6V~24V solar panel, DC-002 jack input or screw terminal input
- Onboard MPPT SET switch, select the level closed to input level to improve charging efficiency
- Two 5V output interfaces: pinheaders and USB port
- Onboard high capacity aluminum electrolytic capacitor and SMD ceramic capacitor, reducing the ripple, stable performance
- 14500 battery holder and Pstrong.0 battery connector, for connecting multi kinds of 3.7V Li battery
- Several LED indicators, for monitoring the status of solar panel and battery
- Multi protection circuits: over charge / over discharge / reverse protection / over heat / over current, stable and safe to use
- Solar panel input voltage (SOLAR IN): 6V~24V
- Micro USB input voltage (USB IN): 5V
- Pinheader / USB output (USB OUT): 5V 1A
- Charging cutoff voltage: 4.2V±1％
- Over discharging protection voltage: 2.9V±1％
- Solar panel charge efficiency:: ~78%
- USB charge efficiency:: ~82%
- 3.7V battery boost output efficiency: ~86%
- Max quiescent current: <2mA
- Operating temperature: -40℃~85℃
- Dimension: 65.2mm × 56.2mm × 22.9mm
- Solar panel charging input: charged by solar panel, DC-002 jack or screw terminal
- USB charging input: charged by USB connection, connect a 5V power adapter through the Micro USB port
- 5V/1A power output: provides regulated 5V/1A output, USB port or 2.54mm pinheader
- Battery interfaces: for connecting 3.7V Li battery, Pstrong.0 connector or 14500 battery holder
- CS8501: USB power management chip, for USB charging and 5V/1A boost output
- CN3791: solar power management chip, for solar panel charging and buck input
- Li battery protection chip: Li battery over charge / over discharge protection
- Battery switch
- MPPTSET switch (bottom side):
supported level: 6V/9V/12V/18V/24V
select the level closed to input level to improve charging efficiency - BOOT key
- Battery capacity indicators
- USB charging indicators:
USB Charge: on when USB charging
USB Done: on when the battery is full charged by USB - Solar panel charging indicators:
Solar Charge: on when solar panel charging
Solar Done: on when the battery is full charged by solar panel
Solar Warning: on when solar panel reverse connection - Battery warning: on when battery reverse connection
- Power output indicator: 5V/1A output
DimensionsDevelopment ResourcesWiki : www.waveshare.com/wiki/Solar_Power_Manager
RecommendationApplicable solar panel: Solar Panel (6V 5W)
or Solar panel 18V 10W
Solar Panel (6V 5W) (6V 5W solar panel)
Description:
A small solar panel perfect for taking your solar powered project on the go!
Specifications
A small solar panel perfect for taking your solar powered project on the go!
Specifications
- Solar cell type: 156 monocrystalline cell
- Surface: toughened glass
- Frame material: anodic oxidation aluminum alloy
- Back board material: 0.25mm PET
- Power: 5.0W ± 5%
- Operating voltage: 6.0V ± 5%
- Operating current: 833mA ± 5% (max)
- Open circuit voltage: 7.2V ± 5%
- Short circuit current: 916mA ± 5%
- For use with: Solar Power Manager
Note: specifications above are tested on standard condition: 1000W/m2 radiation intensity, 25℃, AM1.5 air quality.
Application ExampleA simple solar power supply system:
PWM 30A Dual USB Solar Panel Battery Regulator Charge Controller 12/24V LCD (30A PWM solar charge controller)
Description:
Solar panels are a clean and ecological source of electricity.
Obtaining this energy, however, poses a number of challenges for device designers. The amount of energy produced by the panel is strongly dependent on the angle of incidence and the intensity of the light falling on the surface of the cells. This, in turn, leads to unstable power supply parameters at the output, as even shading a small part of the panel may drastically reduce the efficiency.
The optimal solution to the above-mentioned problems is the use of a set consisting of a solar panel, a battery and a charge controller. Such a set allows to ensure constant parameters of power supply to receivers, and also to store energy produced excessively for later use.
The 30A-PWM-LCD solar charge controller allows you to connect panels connected to each other both in series and in parallel - remembering not to exceed the permissible values of current and voltage at the input of the device. Due to the operating characteristics of the PWM controllers, it should be remembered that when the panels are connected in series, the rated voltage at the output for charging the battery is 24V.
PWM stands for Pulse Width Modulation. PWM charge control devices can be explained as an electrical switch between batteries. The switch can be quickly switch on and switch off. Therefore, desired voltage can be obtained to charge the batteries. The charge current will be slowly decreased as the batteries charged.
Specifications:
Solar panels are a clean and ecological source of electricity.
Obtaining this energy, however, poses a number of challenges for device designers. The amount of energy produced by the panel is strongly dependent on the angle of incidence and the intensity of the light falling on the surface of the cells. This, in turn, leads to unstable power supply parameters at the output, as even shading a small part of the panel may drastically reduce the efficiency.
The optimal solution to the above-mentioned problems is the use of a set consisting of a solar panel, a battery and a charge controller. Such a set allows to ensure constant parameters of power supply to receivers, and also to store energy produced excessively for later use.
The 30A-PWM-LCD solar charge controller allows you to connect panels connected to each other both in series and in parallel - remembering not to exceed the permissible values of current and voltage at the input of the device. Due to the operating characteristics of the PWM controllers, it should be remembered that when the panels are connected in series, the rated voltage at the output for charging the battery is 24V.
PWM stands for Pulse Width Modulation. PWM charge control devices can be explained as an electrical switch between batteries. The switch can be quickly switch on and switch off. Therefore, desired voltage can be obtained to charge the batteries. The charge current will be slowly decreased as the batteries charged.
Specifications:
Rated Voltage: 12V/24V(Auto recognition)
Rated Current: 30A
Charging Mode: PWM
USB output: 5V 2A
Self-consume: <10mA
Operating Temperature: -35 ~ 60 °C
Storage Temperature: -35 ~ 60 °C
Typical usage example:
Typical usage example:
Package Includes:
1 x 30A Solar Charge Controller
DC UPS Mecer 3500mAh battery On-line UPS (For WiFi / 3G / 4G Router) (DC 3500mAh UPS router)
Mecer 350000mAh battery On-line UPS (For WiFi / 3G / 4G Router), Built-in Li-ion battery
Features:
- Built-in Li-ion battery
- Microprocessor control guarantees high reliability
- Manual power off switch
- Auto start when plugged in
- Multi-color indicator
- Overload, short-circuit, over-charge and over-discharge protection
MODEL ePower
AC INPUT
- Voltage Range 90 VAC ~ 264 VAC
- Frequency 50 or 60 Hz
- Surge protection 1.5KV (Optional K.21 enhanced, 6KV)
DC OUTPUT
- Voltage 12VDC ± 5%
- Max. Power 25W (2.1A)
Battery
- Type Lithium-ion Battery
- Voltage 3.7VDC
- Capacity 3500mAh
- Typical Charging Time 3 hours recover to 90% capacity
Protection
- Battery Deep Discharge, Over-charge and Short Circuit Protection
- Input/Output Fuse for Short Circuit and Overload Protection
INDICATORS
- LED Full Battery Green lighting
- Battery Charging Constant flashing on Green LED
Battery
- Discharging Quick flashing on Green LED
- Fault Red lighting
PHYSICAL
- Input Plug Mounted on the housing (NEMA/UK/Schuko)
- Ouput Cable 1m Length (DC Male Jack, OD 4mm, ID 1.7mm or OD 5.5mm, ID 2.5mm)
Dimensions
- L X W X H (mm) 68 x 42 x 74
- Net Weight (g) 280
Backup Time Table : (For Reference only)
- 12V/1A Router 150 mins
- 12V/1.5A Router 120 mins
- 12V/2.0A Router 90 mins
Mecer 850VA OFF-LINE UPS (Mecer UPS 850VA black)
Description:
Mecer 850VA OFF-LINE UPS (with AVR,Monitoring Software Cable & Built-in Surge Protection) - Black
Mecer 850VA OFF-LINE UPS (with AVR,Monitoring Software Cable & Built-in Surge Protection) - Black
Features:
- 850VA line interactive UPS
- Microprocessor control guarantees high reliability
- Boost and buck AVR for voltage stabilization
- Auto restart while AC is recovering
- Simulated sine wave
- Off-mode charging
- Cold start function
- USB communication port and RJ-11/RJ-45 protection
- Overload, discharge, and overcharge protection
Mecer 2000VA / 1200W OFF-LINE UPS - Black (Mecer UPS 2000VA)
Description:
Output:
- AC Voltage Regulation(Batt. Mode): ±10%
- Frequency Range (Batt.Mode): 50Hz or 60Hz ± 1 Hz
- Transfer Time: Typical 2-6 ms, 10 ms max
- Waveform (Batt. Mode): Simulated Sine Wave
Alarm:
- Battery Mode: Sounding every 10 seconds
- Low Battery: Sounding every second
- Overload: Sounding every 0.5 second
- Fault: Continuously sounding
Includes:
- 1x UPS Unit
- 2x Male to Female Extension Power Cord IEC C13-C14 Serial (From UPS to PC)
- 1x USB cable (From UPS to PC)
Specifications:
- Dimensions: 397 x 146 x205
- Weight: 11.5kg
NO Dedicated Power cord with kettle plug (sold separately)
Please Note:
A UPS is not designed to provide continuous power, merely a window period that allows a computer or other user to finalise the work at hand and shut down. It's ability to do this is dependent on the number of devices connected to the UPS.
To establish what you can and cannot connect, calculate the total wattage you need to supply and ensure that the UPS you purchase meets that requirement.
What's in the box?
1 x Mecer 2KVA UPS
2 x Mate to Female Extension Cables
1 x Software Disk
1 x USB Cable
1 x User Manual
Output:
- AC Voltage Regulation(Batt. Mode): ±10%
- Frequency Range (Batt.Mode): 50Hz or 60Hz ± 1 Hz
- Transfer Time: Typical 2-6 ms, 10 ms max
- Waveform (Batt. Mode): Simulated Sine Wave
Alarm:
- Battery Mode: Sounding every 10 seconds
- Low Battery: Sounding every second
- Overload: Sounding every 0.5 second
- Fault: Continuously sounding
Includes:
- 1x UPS Unit
- 2x Male to Female Extension Power Cord IEC C13-C14 Serial (From UPS to PC)
- 1x USB cable (From UPS to PC)
Specifications:
- Dimensions: 397 x 146 x205
- Weight: 11.5kg
NO Dedicated Power cord with kettle plug (sold separately)
Please Note:
A UPS is not designed to provide continuous power, merely a window period that allows a computer or other user to finalise the work at hand and shut down. It's ability to do this is dependent on the number of devices connected to the UPS.
To establish what you can and cannot connect, calculate the total wattage you need to supply and ensure that the UPS you purchase meets that requirement.
What's in the box?
1 x Mecer 2KVA UPS
2 x Mate to Female Extension Cables
1 x Software Disk
1 x USB Cable
1 x User Manual
Solar Power Manager (C), Supports 3x 18650 Batteries, Multi Protection Circuits (WS solar manager 3x18650)
Description
Compatible with 6V~24V solar panels, supports 3x 18650 batteries recharged from solar panel, or TYPE-C power adapter. 5V/3A regulated output.
SAFETY PRECAUTIONS
Li-ion and Li-po batteries are quite unstable. They may cause fire, personal injury, or property damage, if they're not properly recharged or used.
Do not reversely connect the polarities when recharging or discharging the battery.
Do not use inferior charger/charging panel to recharge the battery.
Do not mix use old batteries with new ones, avoid using batteries of different brands.
When buying a Lithium battery, you should always make sure the battery specification is compatible with the expansion board. Choose batteries from formal manufacturers and ensure the batteries will work stably and safely by aging test.
Lithium batteries have limited cycle life, they will also deteriorate as time goes by. Should be replaced with new ones when the batteries reaching their max cycle life, or working over two years, whichever comes first.
Batteries should be stored carefully and properly, keep it away from inflammables and explosives articles, away from children, avoid any safety accident caused by careless storage.
Product features
The Solar Power Manager (C) is compatible with general 6V~24V solar panels. It can recharge the 18650 rechargeable Li-ion batteries through solar panel or USB TYPE-C connection, and provides 5V / 3A regulated output (with multi protocols support including PD/QC/FCP/PE/SFCP).
The module features MPPT (Maximum Power Point Tracking) function and multi protection circuits, therefore, it is able to keep operating with high-efficiency, stability, and safety. It is suitable for solar powered, low-power IoT, and other environmental protection projects.
Supports 6V~24V solar panels
5-level voltage switch, for setting solar panel input voltage to improve efficiency
3x 18650 batteries support
Embedded battery holder for rechargeable Li-ion batteries
Application example
solar-powered control system for MCUs / development boards like:
Raspberry Pi / Jetson Nano / Arduino...
Note: for reference ONLY, the Raspberry Pi, display, solar panel are NOT included.
Resources introduction
Outline Dimensions
What's in the box?
1 x solar manager
Resources & Services
Compatible with 6V~24V solar panels, supports 3x 18650 batteries recharged from solar panel, or TYPE-C power adapter. 5V/3A regulated output.
SAFETY PRECAUTIONS
Li-ion and Li-po batteries are quite unstable. They may cause fire, personal injury, or property damage, if they're not properly recharged or used.
Do not reversely connect the polarities when recharging or discharging the battery.
Do not use inferior charger/charging panel to recharge the battery.
Do not mix use old batteries with new ones, avoid using batteries of different brands.
When buying a Lithium battery, you should always make sure the battery specification is compatible with the expansion board. Choose batteries from formal manufacturers and ensure the batteries will work stably and safely by aging test.
Lithium batteries have limited cycle life, they will also deteriorate as time goes by. Should be replaced with new ones when the batteries reaching their max cycle life, or working over two years, whichever comes first.
Batteries should be stored carefully and properly, keep it away from inflammables and explosives articles, away from children, avoid any safety accident caused by careless storage.
Product features
The Solar Power Manager (C) is compatible with general 6V~24V solar panels. It can recharge the 18650 rechargeable Li-ion batteries through solar panel or USB TYPE-C connection, and provides 5V / 3A regulated output (with multi protocols support including PD/QC/FCP/PE/SFCP).
The module features MPPT (Maximum Power Point Tracking) function and multi protection circuits, therefore, it is able to keep operating with high-efficiency, stability, and safety. It is suitable for solar powered, low-power IoT, and other environmental protection projects.
- Supports MPPT (Maximum Power Point Tracking) function, maximizing the efficiency of the solar panel.
- Flexible battery recharging: from solar panel or USB TYPE-C power adapter.
- Compatible with 6V~24V solar panels, DC-002 jack input or screw terminal input
- Onboard MPPT SET switch, select the level closed to input level to improve recharging efficiency
- Onboard aluminum electrolytic capacitor and SMD ceramic capacitor, reducing the ripple, stable performance
- Embedded battery holder, supports 3x 18650 rechargeable Li-ion batteries
- Several LED indicators, for monitoring the status of solar panel and battery
- Multi protection circuits: over charge / over discharge / reverse-proof / over heat / over current, stable and safe to use
Supports 6V~24V solar panels
5-level voltage switch, for setting solar panel input voltage to improve efficiency
3x 18650 batteries support
Embedded battery holder for rechargeable Li-ion batteries
Application example
solar-powered control system for MCUs / development boards like:
Raspberry Pi / Jetson Nano / Arduino...
Note: for reference ONLY, the Raspberry Pi, display, solar panel are NOT included.
Resources introduction
- Solar panel input
recharging through DC-002 jack or screw terminal - TYPE-C recharging/output port
supports 5V power adapter for recharging
supports PD protocol quick charge adapter
supports PD/QC/FCP/PE/SFCP multi protocols output - USB output port
5V/3A regulated output
supports PD/QC/FCP/PE/SFCP multi protocols output
- Battery on/off switch
- BOOT button
- Quick charge indicator
- Solar panel status indicators
Solar Warning: lights up if solar panel is reversed
Solar Charge: lights up when recharging from solar panel
Solar Done: lights up when the battery is fully recharged - Battery life indicators
Outline Dimensions
What's in the box?
1 x solar manager
Resources & Services
Wiki: Solar_Power_Manager_(C)
Polysilicon Solar Panel (18V 10W), High Conversion Efficiency (WS 18V 10W solar panel)
Application example
for reference ONLY, the Raspberry Pi, display, solar power manager are NOT included.
Outline Dimensions
What's in the box?
1 x 10W solar panel with dc cable and barrel connector
Specifications
| Key specifications | |||
|---|---|---|---|
| Solar cell type | polysilicon | Power | 10 Wp (Max) |
| Output power tolerance | ±3% | Conversion efficiency | >20% |
| Operating voltage | 17.6 V | Operating current | 0.57 A |
| Open circuit voltage | 21.6 V | Short circuit current | 0.61 A |
| Cell quantity | 36 (4×9) | Standard system voltage | 1000 V (Max) |
| Others | |||
| Operating temperature | -40℃ ～ 85℃ | ||
| Pressure on panel | 30m/s(200kg/sq.m) (Max) | ||
| Cable length | 90 cm | ||
| Frame material | anodic oxidation aluminum alloy | ||
| Dimensions | 340 × 232 × 17 mm | ||
| Weight | 0.935 kg | ||
conversion efficiency > 20%
polysilicon solar panel, widened chips, larger receiving area, capturing trivial source
high strength frame
anodic oxidation aluminum alloy material, multi layers structure, waterproof and durable
Application example
for reference ONLY, the Raspberry Pi, display, solar power manager are NOT included.
Outline Dimensions
What's in the box?
1 x 10W solar panel with dc cable and barrel connector
PiJuice HAT - A Portable Power Platform For Every Raspberry Pi (PiJuice HAT)
Description:
PiJuice Video
As one of the smallest systems around there are so many amazing things you could do with the Raspberry Pi if it was self-powered and portable. Introducing PiJuice! A fully uninterruptible power supply that will always keep your Raspberry Pi powered.
Our revolutionary PiAnywhere technology contained in every PiJuice HAT - is the best way to take your Pi off the grid! The real time clock (RTC) on board will let your Pi know what time it is even with no power input or internet connection. Alongside this is an integrated microcontroller (MCU) chip which will manage soft shut down functionality and a true low power deep sleep state and intelligent startup.
You will be able to always keep track of the charge levels and other info with the two built-in tri-coloured RGB LEDs, trigger events and scripts with the three programmable buttons and since the PiJuice will use up to just five of your GPIO pins (just power and I2C), the rest are free to diversify your project. The stacking header allows you to continue to use your existing HATs and add-ons with PiJuice.
Keep your Raspberry Pi running with solar, wind and other renewable power.
Ultimate integrated power is one thing but what if we could make the Raspberry Pi renewably powered too? Solar, wind, thermoelectric and other renewable power is free, clean, and green and we're proud to have developed an affordable and efficient renewable power solution for the Raspberry Pi! PiJuice is self-monitoring and, like a space satellite, can become a completely autonomous system. Use the PiJuice as part of an autonomous camera system, weather stations, off-grid desktops, and so many other great outdoor projects. View and buy the solar panels separately.PiJuice Video
https://youtu.be/ESVaLw51YL8
PiJuice Features:
- Onboard 1820 mAh off the shelf Lipo / LiIon battery for ~4 to 6 hours in constant use! (with support for larger Lipo Battery of 5000 or 10,000 mAH to last up to 24 hrs )
- A Full Uninterrupted / Uninterruptable Power Supply solution.
- Designed for the Raspberry Pi boards A , B , 2B, 3B, 3B and Pi4 but also compatible with Raspberry Pi Zero v1.3 and Raspberry Pi Zero Wireless.
- Integrated Real Time Clock
- Onboard intelligent on/off switch
- Low power deep-sleep state with wake on interrupt/calendar event
- Programmable multi-colored RGB led (x2) and buttons (x3) with super simple user-configurable options
- Hardware watchdog timer to keep your Raspberry Pi on and working in mission-critical remote applications
- Our revolutionary PiAnywhere technology ? the best way to take your Pi off the grid!
- Full power management API available to Raspberry Pi OS with auto shutdown capability when running low on batteries
- Raspberry Pi HAT compatible layout, with onboard EEPROM for easy plug and play operation
- Low profile design to fit inside lots of existing Raspberry Pi cases!
- Enhanced graphical user interface (GUI) available for easy install (via APT)
- Customisable scripts for enhanced flexibility and full report of battery status
- All GPIOs available via stackable header for ease of expandability and connectivity
- Charge via on-board micro USB or via the Raspberry Pi micro USB (or from onboard pin headers)
- Batteries can be charged from different type of sources and voltages
- Replace the battery without downtime. Compatible with any single cell LiPo or LiIon battery
- Fully CE and FCC tested design. Battery safety tested also.
Technical Information
- The EEPROM can be disabled and its I2C address changed for increased compatibility with other boards
- BP7X battery - original battery from Motorola Droid 2 (A955) - 1820mAh battery
- Microcontroller is an ST Micro STM32F030CCT6 ARM Cortex-M0, 48MHz, F64KB, R8KB, I2C, SPI, USART, 2.4-3.6V
- Charge IC - BQ24160RGET Charger IC Lithium-Ion/Polymer, 2.5A, 4.2-10V
- Fuel gauge IC - LC709203FQH-01TWG Battery Fuel Gauge, 1-Cell Li-ion, 2.8%
- EEPROM - CAT24C32WI-GT3 EEPROM, I2C, 32KBIT, 400KHZ, 1V7-5V5
- Optional spring pin - Mil-Max 0929-7-15-20-77-14-11-0
- Compatible with any 4 pin battery on board that can be used with 00-9155-004-742-006 battery contacts from AVX including the BP7X, BP6X, and any compatible batteries including the 1600mAh and 2300mAh ones from CameronSino (CS-MOA853SL and CS-MOA855XL)
- There is an on board 4 pin screw terminal block for larger off board batteries. Any single cell LiPo / LiIon is compatible. However, you use your own sourced battery at your own risk. We HIGHLY RECOMMEND using a battery with an internal protection circuit and a NTC (temp sensor)
- Optional header for offboard button - connected to same output as SW1
- 6 pin breakout header - with two GPIO from the ARM Cortex-M0, Vsys, 5v0, 3v3, GND connections
- Header for optional off board solar panel / wind turbine etc.
- Optional RF Shield attachment - Harwin S02-20150300 (can also double as an inexpensive heatsink)
- Input voltage range - 4.2V 10V
- Output voltage - 3.3V and 5V
- Output amperage - maximum current at 5V gpio is 2.5A and at VSYS output 2.1A, but also this depends heavily on battery capacity. For BP7X have measured around 1.1A at 5V GPIO and around 1.6A at VSYS output. Obviously, this also depends heavily on the current draw demanded by the Raspberry Pi/device itself. To achieve a maximum of 2.5A it will need battery over 3500mAh.
- Boxed weight - 96g
- Boxed dimensions - 12.2 x 10.8 x 3.5 cm
- Unboxed weight - 57g
- Unboxed dimensions - 6.5 x 5.6 x 2 cm
PiJuice HAT box contains
- 1 x PiJuice HAT
- 1 x Battery and battery surround
- 1 x PiJuice guide
- 4 x Mounting posts attached to PiJuice
- 8 x Mounting screws (4 are already assembled to the board)
- 1 x Pogo pin
- 3 x Stickers
Software & Resources
Cinco 50W 12V Solar Panel (50W solar panel)
Description:
Cinco Solar's standard panels widely used in large-scale ground solar power station, industrial and commercial roof solar power station, solar home power generation system.
Not included:
MC4 Male Female solar Cable Connector Set
Package Includes:
1 x 50W solar panel
Cinco Solar's standard panels widely used in large-scale ground solar power station, industrial and commercial roof solar power station, solar home power generation system.
Features
- Aesthetic appearance with excellent efficiency based on innovative photovoltaic technologies.
- High quality, strong aluminium frame, passing mechanical load testing 5400 Pa and wind pressure 2400Pa.
Technical Specifications
- Maximum Power at STC (Pmax): 50W.
- Optimum Operating Voltage (Vmp): 17.8V.
- Optimum Operating Current (Imp): 2.81A.
- Open-Circuit Voltage (Voc): 22.00V.
- Short-Circuit Current (Isc): 3.01A.
- Solar Module Efficiency (%): 14.01.
- Dimension: 695 mm x 510 mm x 25mm.
- Weight: 5kg.
- Operating Temperature: -40˚C to 85˚C.
- Maximum System Voltage (DC): 1000.
- Maximum Series Fuse Rating: 10A.
- Power Tolerance: /-3%.
- Cell Type: Poly.
- Number of Cells: 36 Cell (156 x 156 series)
Not included:
MC4 Male Female solar Cable Connector Set
Package Includes:
1 x 50W solar panel
- 1
