Wireless

This small size Bluetooth 4.0 TTL transceiver module allows your target device to communicate with your iPhone/iPAD, IOS 6 or Android 4.3 devices.

Ultra-low standby power consumption 90uA~400uA
Coverage up to 60 meters
Built in PCB antenna
Power input: 3.6V-6V DC(Can not higher than 6V)
Size: 43mm x 15mm
Color: Blue
Net Weight: 4g

What's in the box?

Certified for use with Raspberry Pi Compute Module 4

Specifications

• FREQUENCY RANGE    2400-2500/5150-5850 MHz
• MAXIMUM POWER    10 W
• BANDWIDTH    100–700 MHz
• DIMENSIONS    109 × 10 mm
• VSWR    ≤1.92
• CONNECTOR    SMA male central pin
• PEAK GAIN    2±0.5 dBi
• BODY MATERIAL    TPEE
• OUTPUT IMPEDANCE    50 Ω
• OPERATING VOLTAGE    -20˚C ~ + 70˚C
• POLARISATION    Vertical
• RADIATION    Omnidirectional

What's in the box?

1 x CM4 Antenna kit

Resources

The CC2531 USB dongle is a fully operational USB device which provides a PC interface to IEEE802.15.4 / ZigBee applications, comes with a CC2531ZNP-Prod firmware, the dongle can be plugged directly into your PC/Raspberry etc used as a Zigbee packet sniffer.



Features

Flashed with CC2531ZNP-Prod firmware for zigbee2mqtt application Lead out 8 IO connectors Debug interface Size: 5.6*1.6*0.7cm Two buttons and two LEDs for user interaction.

What's in the box?

1 x Sonoff Zigbee dongle

AC8265 Wireless NIC, 2.4G / 5G WiFi, Bluetooth 4.2, Applicable For Jetson Nano.
This is a dual mode wireless NIC module applicable for Jetson Nano, supports 2.4GHz / 5GHz dual band WiFi and Bluetooth 4.2.

Specifications

• Chip: Intel 8265AC
• Bands: 2.4GHz / 5GHz
• Speed: 300Mbps / 867Mbps
• WiFi protocol: 802.11ac
• Bluetooth version: 4.2
• NIC interface: NGFF (M.2)
• Antenna interface: IPEX connector
• Supported OS: Linux, Windows 10/8.1/8/7
• Dimensions: 22mm × 30mm × 2.4mm

What's In the box ?

1 x Wireless-AC8265
2 x Antenna
2 x IPEX to SMA cable

Resources

The kit includes one pair of transmitter and receiver modules and one pair of spring antennas for increasing the communication distance. The frequency is 433MHz. It is very popular for remote control systems, such as Remote control rolling gates, robotics, smart home, etc.

Short antenna for Transmitter
Long antenna for Receiver

About the transmitter module (square shape)

• Model: WL102-341
• Material: Plastic Metal
• Colour: shown as pictures
• Size: 16×12×1mm
• Operating frequency: 433.92 MHz
• Mains input voltage range: 2.0V-3.6V
• Shutdown mode current is less than 1uA
• Transfer rate: up to 20KHz
• Launch distance: 20-100 meters
• External antenna: 25cm ordinary multi-core or single-core line
• Temperature range: -45℃～85℃

About receiver module (rectangular shape)

• Model: RX470-4 (RX470-4 is WL101-341 upgraded version, more stable performance, faster data transfer)
• Material: Plastic Metal
• Colour: shown as pictures
• Size: 30×9×1mm
• Operating frequency: 433.92 MHz
• Mains input voltage range: 2.2V-5V
• Working current: Type: 2.1mA (Requirement:VDD=5V) ; Type: 2.1mA (Requirement:VDD=3V)
• Quiescent Current: 1uA
• Temperature range: -40℃～85℃
• External antenna: 32cm single core wire, wound into a spiral

What's in the box?

1 x 433MHz RF transmitter module
1 x 433MHz RF receiver module
2 x 433MHz spring antennas (Short antenna for Transmitter; long antenna for Receiver.)

Resources

Configure and read a 433Mhz RF Transmitter With Receiver on the Raspberry Pi

Sonoff Zigbee 3.0 USB Dongle Plus is a universal Zigbee USB stick. It can be used as a universal Zigbee gateway in Home Assistant or other open-source platforms via ZHA or Zigbee2MQTT to locally control all your Zigbee sub-devices. You don’t need to invest in the Zigbee hubs for different brands, all you need is a universal gateway – Dongle Plus!

The dongle plus has a wide range of supported devices, and various sub-devices from various brands or flash router firmware to extend the network range.

The limits of ZBDongle Plus are 21 direct children and up to 40 children (Default values from official firmware). Supported to connect more by configurating yourself.
*Updated version (in the near future) will be supported to work with maximum 200 children.

Features



• Pre-flashed with Z-Stack 3.x.0 coordinator firmware
• Can use ZHA in Home Assistant or use Zigbee2MQTT
• Base on TI CC2652P + CP2102N
• +20dBm output gain
• SMA interface external antenna
• Aluminum housing effectively reduces signal interference from peripherals
• Optional 1.5m USB extension cable for better signal range


Specifications

• Model: ZBDongle-E
• Working Temperature: -10℃-40℃
• Input: DC 5V (100mA Max)
• Wireless: Zigbee 3.0
• Shell Material: aluminium  Alloy

What's in the box?

1 x Sonoff USB Dongle Plus Zigbee

Overview

This is the NodeMCU development board based on ESP32, features WiFi+Bluetooth connectivity, onboard CP2102 and keys. What's more, all the I/O pins of ESP32 module are accessible via the extension headers.

Thanks to the rich open-source resources, it supports development in various ways such as Lua/AT commands/MicroPython/Arduino/IOT source code, etc. helps you to fast prototype IoT applications.

Features

• Onboard ESP32 module
• Onboard CP2102, USB to UART converter
• USB port for power input, firmware programming, or UART debugging
• 2x19pin extension headers, breakout all the I/O pins of the module
• 2x keys, used as reset or user-defined

Version Comparison

Specifications

• WIFI module: ESP32
  • Processor: ESP32
• Built-in Flash: 32Mbit
• Antenna: Onboard PCB antenna
• Peripheral interface: UART/GPIO/ADC/DAC/SDIO/PWM/I2C/I2S
• WiFi protocol: IEEE 802.11 b/g/n
• Bluetooth: Bluetooth 4.2
• Frequency range: 2.4G ~ 2.5G (2400M ~ 2483.5M)
• WIFI mode: Station / SoftAP / SoftAP+Station
• Power supply: 5V
• Logic level: 3.3V
• Dimensions: 51.4mm x 25.4mm

Applications

The NodeMCU-32S suit for IOT applications such as:

• Smart home
• Intelligent building
• Industrial automation
• Wearable devices
• IP camera
• Intelligent agriculture

Pinouts

What's in the box?

1 x NodeMCU-32S

Resources

Wiki : www.waveshare.com/wiki/NodeMCU-32S

With the Volkano X Allcast, you can Cast and Stream from any Phone or Laptop to a TV, Monitor, or a Projector.

Extend your computer display, or drag windows from your PC or MAC to your big screen for meetings, entertainment, or even just for an extra display.

Features

• Works with Android, Apple iOS, Windows, or Mac
•  Transmit Video and Audio to a TV, Monitor or a Projector
•  Supports Miracast, DLNA & Airplay
•  USB Powered
•  Up to 1080P Full HD
•  Easily stream your favorite apps like Netflix and YouTube.

System Requirements

• Android Phone or Tablet: Android 4.2 Up
•  Apple Phone or Tablet: iOS 7 Up
•  Windows: 8.1, 10 & Up
•  MAC: MAC OS 10.8 Up
•  TV, Monitor, or a Projector with HDMI Input
•  Requires an External USB Power Source

Specifications

• Video Resolution: Up to 1080P @ 60Hz
•  Audio Channels: Up to 5.1 Surround Sound
•  Chipset: RK3036 Dual Core Cortex A7, 1.2GHz
•  Output: HDMI<br> Power: Micro USB 5 V @ 1 A

What's in the box?

1 x VolkanoX Allcast HDMI Wireless Display Receiver
1 x USB Power Cable
1 x Extension WiFi Receiver
1 x Instruction Manual
