All Products

Sort By:
R29.90  Inc VAT
This third generation model maintains the same popular board format as the Raspberry Pi 2 and Raspberry Pi B+, but boasts a faster 1.2GHz 64Bit SoC, and on board WiFi and Bluetooth!
R699.90  Inc VAT
This brilliant Starter Kit is a perfect starting point to get you up and running with your RPI Zero so you can get Playing / Making/ Prototyping etc ASAP.
R539.90  Inc VAT
R598.80
This brilliant Starter Kit is a perfect starting point to get you up and running with your RPI Zero so you can get Playing / Making/ Prototyping etc ASAP.
R664.40  Inc VAT
Go on.....give away your age. You remember these?
R6,186.08  Inc VAT
R8,990.80
Would you like to learn electronics, with an all-in-one board that has sensors and LEDs built in? Circuit Playground is here, and it's the best way to practice programming on real hardware. No soldering or sewing required!
R539.90  Inc VAT
R489.90  Inc VAT
ATMEGA8 ATMEGA8A-PU DIP28 (Arduino IC)
Description:

The ATMEGA8A-PU is a high-performance, low-power 8-bit AVR RISC-based Microcontroller combines 8kb ISP flash memory with read-while-write capabilities, 512B EEPROM, 23 general purpose I/O lines, 32 general purpose working registers, three flexible timer/counters with compare modes, internal and external interrupts, serial programmable USART, a byte oriented two-wire serial interface, 6-channel 10-bit A/D converter (8-channel in TQFP and QFN/MLF packages), programmable watchdog timer with internal oscillator, SPI serial port and five software selectable power saving modes. The device operates between 2.7 to 5.5V. By executing powerful instructions in a single clock cycle, the device achieves throughputs approaching 1 MIPS per MHz, balancing power consumption and processing speed.

  •     High-performance, Low-power AVR® 8-Bit Microcontroller
  •     Advanced RISC Architecture
  •     High Endurance Non-volatile Memory Segments
  •     Atmel QTouch® Library Support
  •     Power-on Reset and Programmable Brown-out Detection
  •     Internal Calibrated RC Oscillator
  •     External and Internal Interrupt Sources
  •     Idle, ADC Noise Reduction, Power-save, Power-down and Standby Sleep Modes
  •     2.7 to 5.5V, 0 to 16MHz Operating Voltage
  •     3.6mA Active, 1.0mA Idle Mode and 0.5µA Power-down Mode Power Consumption

Applications:

Building Automation, Consumer Electronics, Motor Drive & Control, Industrial, Automation & Process Control, Metering
R29.90  Inc VAT
UNO R3 MEGA328P ATMEGA16U2 for Arduino Compatible (Uno Board DIP IC)

Arduino is an open-source electronics platform based on easy-to-use hardware and software. Arduino boards are able to read inputs - light on a sensor, a finger on a button, or a Twitter message - and turn it into an output - activating a motor, turning on an LED, publishing something online.

Find more info on Arduino at https://www.arduino.cc/en/guide/introduction

Description:

 Microcontroller ATmega328
Operating Voltage 5V
Input Voltage (recommended) 7-12V
Input Voltage (limits) 6-20V
Digital I/O Pins 14 (of which 6 provide PWM output)
Analog Input Pins 6
DC Current per I/O Pin 40 mA
DC Current for 3.3V Pin 50 mA
Flash Memory 32 KB (ATmega328) of which 0.5 KB used by bootloader
SRAM 2 KB (ATmega328)
EEPROM 1 KB (ATmega328)
Clock Speed 16 MHz
Length 68.6 mm
Width 53.4 mm

Package includes:

1 x UNO R3
1 x USB cable


R249.90  Inc VAT
Raspberry Pi 3 Model B (Pi3B board)


This third generation model maintains the same popular board format as the Raspberry Pi 2 and Raspberry Pi B+, but boasts a faster 1.2GHz 64Bit SoC, and on board WiFi and Bluetooth!

Specifications

  • Processor
    • Broadcom BCM2387 chipset.
    • 1.2GHz Quad-Core ARM Cortex-A53 (64Bit)
    • 802.11 b/g/n Wireless LAN and Bluetooth 4.1 (Bluetooth Classic and LE)
  • GPU
    • Dual Core VideoCore IV® Multimedia Co-Processor. Provides Open GL ES 2.0, hardware-accelerated OpenVG, and 1080p30 H.264 high-profile decode.
    • Capable of 1Gpixel/s, 1.5Gtexel/s or 24GFLOPs with texture filtering and DMA infrastructure
  • Memory
    • 1GB LPDDR2
  • Operating System
    • Boots from Micro SD card, running a version of the Linux operating system or Windows 10 IoT
  • Dimensions
    • 85 x 56 x 17mm
  • Power
    • Micro USB socket 5V, 2.5A if you want to add some power hungry USB devices

Connectors

  • Ethernet
    • 10/100 BaseT Ethernet socket
  • Video Output
    • HDMI (rev 1.3 & 1.4)
    • Composite RCA (PAL and NTSC)
  • Audio Output
    • Audio Output 3.5mm jack
    • HDMI
    • USB 4 x USB 2.0 Connector
  • GPIO Connector
    • 40-pin 2.54 mm (100 mil) expansion header: 2x20 strip
    • Providing 27 GPIO pins as well as +3.3 V, +5 V and GND supply lines
  • Camera Connector
    • 15-pin MIPI Camera Serial Interface (CSI-2)
  • Display Connector
    • Display Serial Interface (DSI) 15 way flat flex cable connector with two data lanes and a clock lane
  • Memory Card Slot
    • Push/pull Micro SDIO
Please note: This is only the Raspberry Pi 3 board. No extras



Raspberry Pi Operating System Downloads: https://www.raspberrypi.org/downloads/
Getting Started with Raspberry Pi
This third generation model maintains the same popular board format as the Raspberry Pi 2 and Raspberry Pi B+, but boasts a faster 1.2GHz 64Bit SoC, and on board WiFi and Bluetooth!
R699.90  Inc VAT
Geekcreit® MEGA 2560 R3 ATmega2560-16AU MEGA2560 Development Board With USB Cable (Arduino Mega)
Description:

Arduino compatible R3 Mega2560 ATmega2560-16AU control board with USB cable
Arduino Mega is an ATmega2560 core microcontroller development board. Itself has 54 digital input/output terminals (14 PWM outputs), 16 simulation inputs, 4 UARTs (hardware serial ports), using the 16 MHz crystal oscillator. With the bootloader, download the program directly via USB without having to go through other external writers. Supply part of the optional USB power, or external power using a AC-to-DC adapter and battery.
Rapid growth due to open original code, as well as the concept of using Java (cross-platform) C language development environment for Arduino module. The Arduino can easily use the Arduino language with Flash or Processing ... software communication, to make multimedia interactive works. Arduino development IDE interface is based on open-source principles, allows you to download for use in projects.
Power supply design:
There are two options for the power supply system of the Arduino Mega. USB direct power supply or external power supply. The power supply will be switched automatically. External supply AC-to-DC adapter or the battery can be selected on this control panel. Limit the voltage range of 6V ~~ 12V, but if the voltage supplied is less than 6V, I / O port may not be supplied to a voltage of 5V, and therefore not stable; If the voltage is greater than 12V, the regulator device may possibly overheat and damage the Arduino MEGA. It is therefore recommended that for the operating supply of 6.5 ~ 12V, the recommended power supply is 7.5V or 9V.
The development board have been rigorously tested at the factory.

Specification:

Microcontroller: ATmega2560
Operating voltage: 5V
Input voltage (recommended): 7-12V
Digital I/O pins: 54 (of which 14 provide PWM output)
Analog input pins: 16
DC current per I/O pin: 40 mA
DC current for 3.3V Pin: 50 mA
Flash Memory: 256 KB of which 4 KB is used by the bootloader
SRAM: 8 KB
EEPROM: 4 KB
Clock Speed: 16MHz


Getting started with Arduino products

Package includes:

  1 x Control board
  1 x USB cable
R329.90  Inc VAT
Raspberry Pi Zero Essentials Kit(V1.33) (zero essentials kit(V1.33))
This brilliant Starter Kit is a perfect starting point to get you up and running with your RPI Zero so you can get Playing / Making/ Prototyping etc ASAP.


The Kit includes:
Don't forget to grab yourself a WIFI Dongle or USB to Ethernet Converter to get your RPI Zero networked, if you want to connect a few devices to your RPI Zero (like a Keyboard and Mouse) dont forget to grab a Powered USB Hub or the Awesome New Zero4U
This brilliant Starter Kit is a perfect starting point to get you up and running with your RPI Zero so you can get Playing / Making/ Prototyping etc ASAP.
R539.90  Inc VAT
R598.80
Raspberry Pi Zero W Essentials Kit(WiFi) (zero W kit)
This brilliant Starter Kit is a perfect starting point to get you up and running with your RPI Zero Wireless so you can get Playing / Making/ Prototyping etc ASAP.

The Kit includes:
If you want to connect a few devices to your RPI Zero (like a Keyboard and Mouse) dont forget to grab a Powered USB Hub or the Awesome New Zero4U

Raspberry Pi Operating System Downloads:
https://www.raspberrypi.org/downloads/
Getting Started with Raspberry Pi
This brilliant Starter Kit is a perfect starting point to get you up and running with your RPI Zero so you can get Playing / Making/ Prototyping etc ASAP.
R664.40  Inc VAT
WS AlphaBot2 robot building kit for Raspberry Pi 3, Pi 4 Model B (no Pi included) (Alphabot2 RPi 3/4)

Note: Raspberry Pi is NOT included. Batteries are not included

AlphaBot2-Pi (EN) can be used with Raspberry Pi4 ,you will need to buy a USB Micro-B to USB-C Adapter

Overview

This AlphaBot2 robot kit is designed to use with Raspberry Pi 3/4 Model B (not included). It features rich common robot functions including line tracking, obstacle avoiding, Bluetooth/infrared/WiFi remote control, video monitoring, etc.

Thanks to the highly integrated modular design, it is fairly easy to assemble by a snap, no soldering, no wiring. After a few minutes spent on hardware assembling, you're almost there, our open source demo codes is ready to help you get started fast.

AlphaBot2 Features

AlphaBot2 employs a 2-layer structure to provide excellent stability and compatibility.

AlphaBot2-Base, the lower base chassis:

  • 5-ch infrared sensor, analog output, combined with PID algorithm, stable line tracking
  • Onboard modules like line tracking, obstacle avoiding, needs no messy wiring
  • TB6612FNG dual H-bridge motor driver, compared with L298P, it's more efficient, more compact, and less heating
  • N20 micro gear motor, with metal gears, low noise, high accuracy
  • Onboard RGB LEDs, true color lighting, pretty cool

AlphaBot2-Pi, the upper adapter board for controller:

  • LM2596 voltage regulator, provides the Pi with stable 5V power
  • TLC1543 AD acquisition chip, allows the Pi to use analog sensors
  • PCA9685 servo controller, make it more smoothly to rotate the pan head
  • CP2102 UART converter, easy for controlling the Pi via UART

What's on the AlphaBot2-Base


  1. AlphaBot2 control interface: for connecting sorts of controller adapter board
  2. Ultrasonic module interface
  3. Obstacle avoiding indicators
  4. Omni-direction wheel
  5. ST188: reflective infrared photoelectric sensor, for obstacle avoiding
  6. ITR20001/T: reflective infrared photoelectric sensor, for line tracking
  7. Potentiometer for adjusting obstacle avoiding range
  8. TB6612FNG dual H-bridge motor driver
  9. LM393 voltage comparator
  10. N20 micro gear motor reduction rate 1:30, 6V/600RPM
  11. Rubber wheels diameter 42mm, width 19mm
  12. Power switch
  13. Battery holder: supports 14500 batteries
  14. WS2812B: true color RGB LEDs
  15. Power indicator

What's on the AlphaBot2-Pi

  1. AlphaBot2 control interface: for connecting AlphaBot2-Base
  2. Raspberry Pi interface: for connecting Raspberry Pi 3 Model B
  3. Servo interface
  4. USB TO UART: easy for controlling the Pi via UART
  5. LM2596: 5V voltage regulator
  6. TLC1543: 10-bit AD acquisition chip, allows the Pi to use analog sensors
  7. PCA9685: servo controller, make it more smoothly to rotate the pan head
  8. CP2102: USB TO UART converter
  9. Joystick
  10. IR receiver
  11. Buzzer

Examples

AlphaBot2 multi robots line following

AlphaBot2-Pi robot obstacle avoiding

AlphaBot2-Pi robot RGB LED remote control

AlphaBot2-Pi robot video monitor

AlphaBot2-Pi robot Bluetooth control

Development Resources

Wiki : www.waveshare.com/wiki/AlphaBot2-Pi

Package Includes:


Note: this product requires two 14500 batteries to work, which are NOT included and should be purchased separately. Even though the battery holder fits the normal AA batteries DO NOT USE THEM!  A 14500 lithium cell is identical in shape and size to a standard AA battery. But that is where the similarities end. AA supplies 1.5V each where 14500 supply 3.7V each.

  1. AlphaBot2-Pi (adapter board) x1
  2. AlphaBot2-Base (base chassis) x1
  3. RPi Camera (B) x1
  4. Micro SD Card 16GB x1
  5. Power adapter US standard 5V/2.5A USB output x1
  6. SG90 servo x2
  7. 2 DOF pan and tilt kit x1
  8. IR remote controller x1
  9. FC-20P cable 8cm x1
  10. USB type A plug to micro B plug cable x1
  11. 15PIN FFC 25cm x1
  12. AlphaBot2-Pi screws x1
  13. Micro SD Card Reader x1
  14. Screwdriver x1
R1,369.90  Inc VAT
Counter Top Arcade 2 player ****COLLECTION ONLY**** (arcade 2 player)
These arcades are available in different designs and colours. Please give us a call at 087 702 2764 for availability.

Pishop has created this pre-built beauty that will take you back to the good old days. We made them just a little bit smaller to fit on your lapa or kitchen table. 550mm x 540mm x 890mm with a 19.5 inch display.

Dual player controls with all the good 2D games you remember.
We also include a T16 remote control for easy use on Kodi as a media center.

Unfortunately we cannot offer the standard flat rate R100 shipping on these units as they are too heavy and bulky. Please also ask about shipping rates to your area. You are as always still welcome to collect at our premises.

Cabinet:

Proudly locally designed and manufactured 11 panel arcade case with high quality matt vinyl wrapping.
550mm x 540mm x 890mm (LxWxH)

Display:

Tech Specs



Product Description

Mecer LED monitor - 19.5"

Device Type

LED-backlit LCD monitor - 19.5"

Aspect Ratio

16:9

Native Resolution

1366 x 768 at 60 Hz

Brightness

250 cd/m²

Contrast Ratio

5000000:1 (dynamic)

Response Time

2 ms

Colour Support

16.7 million colours

Input Connectors

VGA/HDMI

Colour

Black



Sound system:

Tech Specs



Product Description

Logitech Z211 - speaker system

Product Type

Speaker system - 2.1-channel

Localisation

EMEA

System Components

2 speakers, subwoofer

Speaker Type

Active

Amplifier

Integrated

Power Options

USB powered


Power supply:

Specifications:
Input Voltage:AC 110/220V
Output Voltage:DC12V
Max Current:5A
Power:60W
Frequency:50/60Hz
Size:About 110mm x 79mm x 37mm

https://www.pishop.co.za/store/power-other/110220v-12v-5a-miniature-switching-power-supply

Zero delay controller x 2:

https://www.pishop.co.za/store/arcade/zero-delay-arcade-usb-encoder_1132

Features

  • "Zero Delay" Lag-Free USB Encoder
  • Plug and Play USB Encoder
  • Fully Compatible with Raspberry Pi (in addition to Windows/XP etc.)
  • Includes Wiring Loom
    • USB to Microcontroller
    • 1 x 5 Pin Joystick Loom
    • 16 x 2 Pin JST Button Wires
  • Encoder Inputs
    • 1 x 5 Pin Joystick Input
    • 1 x 10 Pin Joystick Input
    • 12 x Unmapped Button Inputs
    • 4 x Hardware Preset Button Input
      • AUTO - For autofire
      • TURBO - For rapidfire
      • CLR - Clears AUTO/TURBO
      • MODE - Sets thumb-joystick mode
    • Dimensions: 85mm x 35mm x 10mm


Buttons x 16:

https://www.pishop.co.za/store/arcade/arcade-button-blade-type-red

LENGTH: 6,2 cm
WIDTH: 3,7 cm
CIRCUMFERENCE: 19 cm
WEIGHT : 40g

Joystick x 2:

https://www.pishop.co.za/store/arcade/round-8-way-joystick

LENGTH: 10cm
WIDTH: 9cm
CIRCUMFERENCE: 28cm
WEIGHT : 160g

This joystick works using blades instead of switches.
The blades are replaceable and available as listed parts.



Pi 3 model B:

https://www.pishop.co.za/store/raspberry-pi-boards/raspberry-pi-3---model-b

Specifications

  • Processor
    • Broadcom BCM2387 chipset.
    • 2GHz Quad-Core ARM Cortex-A53 (64Bit)
    • 11 b/g/n Wireless LAN and Bluetooth 4.1 (Bluetooth Classic and LE)
  • GPU
    • Dual Core VideoCore IV® Multimedia Co-Processor. Provides Open GL ES 2.0, hardware-accelerated OpenVG, and 1080p30 H.264 high-profile decode.
    • Capable of 1Gpixel/s, 1.5Gtexel/s or 24GFLOPs with texture filtering and DMA infrastructure
  • Memory
    • 1GB LPDDR2
  • Operating System
    • Boots from Micro SD card, running a version of the Linux operating system or Windows 10 IoT
  • Dimensions
    • 85 x 56 x 17mm
  • Power
    • Micro USB socket 5V, 2.5A if you want to add some power hungry USB devices

Connectors

  • Ethernet
    • 10/100 BaseT Ethernet socket
  • Video Output
    • HDMI (rev 1.3 & 1.4)
    • Composite RCA (PAL and NTSC)
  • Audio Output
    • Audio Output 3.5mm jack
    • HDMI
    • USB 4 x USB 2.0 Connector
  • GPIO Connector
    • 40-pin 2.54 mm (100 mil) expansion header: 2x20 strip
    • Providing 27 GPIO pins as well as +3.3 V, +5 V and GND supply lines
  • Camera Connector
    • 15-pin MIPI Camera Serial Interface (CSI-2)
  • Display Connector
    • Display Serial Interface (DSI) 15 way flat flex cable connector with two data lanes and a clock lane
  • Memory Card Slot
    • Push/pull Micro SDIO ………………………………………………………………………………………………………………………………………..
    • Power Converter for sound and Pi:

SD card
Comes pre-loaded with the following software:

Software:


All games loaded are from “My abandon ware”:

https://www.myabandonware.com/browse/developer/A/

How to load new games:

https://www.youtube.com/watch?v=YDdN6HieYvA

Go on.....give away your age. You remember these?
R6,186.08  Inc VAT
R8,990.80
Adafruit Circuit Playground Express (Circuit playground express)

Circuit Playground Express is the next step towards a perfect introduction to electronics and programming. We've taken the original Circuit Playground Classic and made it even better! Not only did we pack even more sensors in, we also made it even easier to program.

Start your journey with Microsoft MakeCode block-based or Javascript programming. Or, you can follow along with code.org CS Discoveries. Then, you can use the same board to try CircuitPython, with the Python interpreter running right on the Express. As you progress, you can advance to using Arduino IDE, which has full support of all the hardware down to the low level, so you can make powerful projects.

Because you can program the same board in 3 different ways - the Express has great value and re-usability. From beginners to experts, Circuit Playground Express has something for everyone.

Here's some of the great goodies baked in to each Circuit Playground Express:

  • 10 x mini NeoPixels, each one can display any color
  • 1 x Motion sensor (LIS3DH triple-axis accelerometer with tap detection, free-fall detection)
  • 1 x Temperature sensor (thermistor)
  • 1 x Light sensor (phototransistor). Can also act as a color sensor and pulse sensor.
  • 1 x Sound sensor (MEMS microphone)
  • 1 x Mini speaker with class D amplifier (7.5mm magnetic speaker/buzzer)
  • 2 x Push buttons, labeled A and B
  • 1 x Slide switch
  • Infrared receiver and transmitter - can receive and transmit any remote control codes, as well as send messages between Circuit Playground Expresses. Can also act as a proximity sensor.
  • 8 x alligator-clip friendly input/output pins
  • Includes I2C, UART, 8 pins that can do analog inputs, multiple PWM output
  • 7 pads can act as capacitive touch inputs and the 1 remaining is a true analog output
  • Green "ON" LED so you know its powered
  • Red "#13" LED for basic blinking
  • Reset button
  • ATSAMD21 ARM Cortex M0 Processor, running at 3.3V and 48MHz
  • 2 MB of SPI Flash storage, used primarily with CircuitPython to store code and libraries.
  • MicroUSB port for programming and debugging
  • USB port can act like serial port, keyboard, mouse, joystick or MIDI!

More product details available at https://learn.adafruit.com/adafruit-circuit-playground-express

Circuit Playground Lessons available at https://learn.adafruit.com/circuit-playground-lesson-number-0/intro


Would you like to learn electronics, with an all-in-one board that has sensors and LEDs built in? Circuit Playground is here, and it's the best way to practice programming on real hardware. No soldering or sewing required!
R539.90  Inc VAT
WS AlphaBot2 robot building kit for BBC micro:bit V2 (no micro:bit included) (Alphabot 2 micro:bit)

Please note: Micro:bit is not included

Overview

This AlphaBot2 robot kit is designed to use with the BBC micro:bit (not included). It features rich common robot functions including line tracking, obstacle avoiding, ultrasonic ranging, Bluetooth/2.4G remote control, etc.

Thanks to the highly integrated modular design, it is fairly easy to assemble by a snap, no soldering, no wiring. After a few minutes spent on hardware assembing, you're almost there, our open source demo codes is ready to help you get started fast.

AlphaBot2 Features

AlphaBot2 employs a 2-layer structure to provide excellent stability and compatibility.

AlphaBot2-Base, the lower base chassis:

  • 5-ch infrared sensor, analog output, combined with PID algorithm, stable line tracking
  • Onboard modules like line tracking, obstacle avoiding, needs no messy wiring
  • TB6612FNG dual H-bridge motor driver, compared with L298P, it's more efficient, more compact, and less heating
  • N20 micro gear motor, with metal gears, low noise, high accuracy
  • Onboard RGB LEDs, true color lighting, pretty cool

AlphaBot2 for micro:bit, the upper adapter board for controller:

  • micro:bit dedicated connector, for easily connecting with the micro:bit
  • MP1584 voltage regulator, provides stable 5V output
  • RT9193-33 voltage regulator, provides stable 3.3V voltage to the micro:bit
  • TLC1543 AD acquisition chip, allows the micro:bit to use analog sensors
  • PCA9685 PWM control chip, I/O expander
  • Onboard buzzer to play music

What's on the AlphaBot2-Base


  1. AlphaBot2 control interface: for connecting sorts of controller adapter board
  2. Ultrasonic module interface
  3. Obstacle avoiding indicators
  4. Omni-direction wheel
  5. ST188: reflective infrared photoelectric sensor, for obstacle avoiding
  6. ITR20001/T: reflective infrared photoelectric sensor, for line tracking
  7. Potentiometer for adjusting obstacle avoiding range
  8. TB6612FNG dual H-bridge motor driver
  9. LM393 voltage comparator
  10. N20 micro gear motor reduction rate 1:30, 6V/600RPM
  11. Rubber wheels diameter 42mm, width 19mm
  12. Power switch
  13. Battery holder: supports 14500 batteries
  14. WS2812B: true color RGB LEDs
  15. Power indicator

What's on the AlphaBot2 for micro:bit (Adapter Board)


  1. micro:bit connector
  2. AlphaBot2-Base header: for connecting with the base board
  3. RT9193-33: 3.3V voltage regulator, stable power supply for the micro:bit
  4. PCA9685: PWM control chip, I/O expander, I2C interface
  5. TLC1543: 10-bit AD acquisition chip, allows the micro:bit to use analog line tracking sensor
  6. Buzzer
  7. MP1584 5V voltage regulator

Dimensions

Development Resources

Wiki : www.waveshare.com/wiki/AlphaBot2_for_micro:bit

This Kit Includes:

Note: this product requires two 14500 batteries to work, which are NOT included and should be purchased separately.

Note: the controller micro:bit is NOT included.

AlphaBot2 for micro:bit Acce Pack

  1. AlphaBot2 for micro:bit (adapter board) x1
  2. AlphaBot2-Base (base chassis) x1
  3. Ultrasonic sensor x1
  4. FC-20P cable 8cm x1
  5. USB type A plug to micro B plug cable x1
  6. AlphaBot2 for micro:bit screws x1
  7. Screwdriver x1



R949.90  Inc VAT
Raspberry Pi3 - Model A+ (Pi3A+ board)

The Raspberry Pi 3 Model A+ is the latest product in the Raspberry Pi 3 range. Like the Raspberry Pi 3 Model B+, it boasts a 64-bit quad core processor running at 1.4 GHz, dual-band 2.4 GHz and 5 GHz wireless LAN, and Bluetooth 4.2/BLE. The dual-band wireless LAN comes with modular compliance certification, allowing the board to be designed into end products with significantly reduced wireless LAN compliance testing, improving both cost and time to market.

The Raspberry Pi 3 Model A+ features 512mb SDRAM (over the Pi 3 B+'s 1GB), has no Ethernet port or function, and includes only one USB port. The Raspberry Pi 3 Model A+ has the same mechanical footprint as the Raspberry Pi 1 Model A+.

Please Note. It is recommended to use a 2.5A Power Supply with the Raspberry Pi 3A+. This purchase is for the Raspberry Pi 3 Model A+ Board only.

Specifications

  • Processor
    • Broadcom BCM2837B0 chipset.
    • 1.4GHz Quad-Core ARM Cortex-A53 (64Bit)
  • Connectivity
    • 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2, BLE
    • 1 × USB 2.0 ports
  • GPU
    • Dual Core VideoCore IV® Multimedia Co-Processor. Provides Open GL ES 2.0, hardware-accelerated OpenVG, and 1080p30 H.264 high-profile decode.
    • Capable of 1Gpixel/s, 1.5Gtexel/s or 24GFLOPs with texture filtering and DMA infrastructure
  • Memory
    • 512mb LPDDR2
  • Operating System
    • Boots from Micro SD card, running a version of the Linux operating system or Windows 10 IoT
  • Dimensions
    • 65 x 56 x 8.5mm
  • Power
    • 5V/2.5A DC via Micro USB Connector
    • 5V DC via GPIO Header

Connectors

    • Video Output
      • HDMI (rev 1.3 & 1.4)
      • Composite RCA (PAL and NTSC)
    • Audio Output
      • Audio Output 3.5mm jack
      • HDMI
      • USB 1 x USB 2.0 Connector
    • GPIO Connector
      • 40-pin 2.54 mm (100 mil) expansion header: 2x20 strip
      • Providing 27 GPIO pins as well as +3.3 V, +5 V and GND supply lines
    • Camera Connector
      • 15-pin MIPI Camera Serial Interface (CSI-2)
    • Display Connector
      • Display Serial Interface (DSI) 15 way flat flex cable connector with two data lanes and a clock lane
    • Memory Card Slot
      • Push/Pull Micro SDIO

    Getting Started with Raspberry Pi
    R489.90  Inc VAT
    Mega2560 + WiFi R3 ATmega2560+ESP8266 32Mb memory USB-TTL CH340G. Compatible for Arduino Mega NodeMCU For WeMos ESP8266 (Mega2560 + wifi)

    Features:

    Full integration on one board: Mega R3 ATmega2560 and WiFi ESP8266 with memory 32Mb (megabyte)
    All of the modules can work together or each separately. And everyone has their own pinout headers
    The convenient solution for the development of new projects requiring Uno and WiFi
    Via USB you can update sketches and firmvare for ATmega2560 and for ESP8266. For this on board have the USB-serial converter CH340G
    Use this board is very simple
    The board has DIP-switch, to connect the modules
    For example, to: USB and ATmeg2560, USB and ESP8266, ATmega2560 and ESP8266

    Table DIP- Switch:

    Connection                                                                                       DIP
    ATmega2560<->ESP8266
    1            2           3             4           5             6              7
    ON         ON        OFF       OFF          OFF        OFF          OFF
    USB <->ATmega2560
    OFF        OFF       ON        ON         OFF        OFF          OFF
    USB<->ESP8266 (Update firmware or sketch)
    OFF        OFF       OFF       OFF        ON         ON           ON
    USB<->ESP8266 (communication)
    OFF        OFF       OFF       OFF        ON         ON           OFF
    All independent
    OFF        OFF       OFF       OFF        OFF        OFF          OFF

    Special solution:
    USB <->ATmega328<-> ESP8266
                                                                                           DIP                                        SWITH 2
    Connection                                        1       2       3      4      5         6           7

    USB <-> ATmega2560<-> ESP8266    ON    ON    ON      ON   OFF    OFF      OFF          To RXD3/TXD3


    USB converter CH340G connect to RX0/TX0 of ATmega2560
    ESP8266 connect to RX3/TX3 of ATmega2560

    Documents

    Dimensional drawing

    Dimensions MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USBDimensions MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USB

    Pinout

    Pinout MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USBPinout MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USB

    Schematic

    Schematic of MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USB

    Drivers

    Windows driver for MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USBLinux driver for MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USBMac OS driver for MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USBAndroid driver for MEGA+WiFi R3 ATmega2560+ESP8266, flash 32Mb, USB-TTL CH340G, Micro-USB


    Package Contents:
    1 x Mega + WiFi Board
    R399.90  Inc VAT
    UNO R3 SMD (CH340G) MEGA328P for Arduino UNO R3 + USB CABLE ATMEGA328P-AU Development board (UNO SMD fixed IC)
    Product introduction
    UNO R3 is a microcontroller board based on the ATmega328P.

    It has:
    - 14 digital input/output pins (of which 6 can be used as PWM outputs)
    - 6 analog inputs
    - a 16 MHz quartz crystal
    - a USB connection
    - a power jack
    - an ICSP header
    - a reset button.

    It contains everything needed to support the microcontroller. Simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started.


    Package Includes:

    1 x Arduino Uno SMD
    1 x Headers
    1 x USB cable

    Getting started with Arduino products
    R159.90  Inc VAT
    LilyPad 328 Main Board ATmega328P ATmega328 16M For Arduino (Lilypad)

    This is the LilyPad main board consisting of an ATmega328 using 5V DC power.

    The latest version of the LilyPad supports automatic reset for even easier programming.

    The back side of the LilyPad is now completely flat! We now use a surface mount programming connector to keep the header from poking through.



    This version of the LilyPad now uses the new ATmega328 at 8MHz. 0016 supports the Pro Mini 328/8MHz/16MHZ. Use this setting when using this new LilyPad 328.

    LilyPad is a wearable e-textile technology developed by Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing.

    Various input, output, power, and sensor boards are available. They're even washable!



    Package Includes:
    1 x 328 Main Board

    R69.90  Inc VAT
    Official Raspberry Pi US Keyboard (Red/White) (Official red/white keyboard)

    The Official Raspberry Pi Keyboard is finally here!

    This sleek and stylish keyboard from the team at Raspberry Pi includes three in-built USB 2.0 type-A ports for powering other peripherals (such as the official Raspberry Pi mouse)!

    Please Note. This keyboard is available in 6 language formats: UK, US, DE, FR, ES & IT. This model is the US version as used in South Africa.


    Keyboard Specification:

    • 79-key keyboard (78-key US keyboard)
    • 3 USB 2.0 type-A ports for powering other peripherals
    • Automatic keyboard language detection
    • USB type-A to micro USB type-B cable for connection
    • Compatible with all Raspberry Pi products
    • Ergonomic design for comfortable use
    • Available in Red/White and Black/Grey
    R279.90  Inc VAT
    Official Raspberry Pi Mouse (Red/White) (Official red/white mouse)

    The Official Raspberry Pi Mouse is finally here!

    This sleek, stylish and ergonomic mouse from the team at Raspberry Pi includes three buttons, two main ones for right and left click, and a scroll wheel with button for scrolling. . . and more clicking. . . what more do you need from a mouse!

    Mouse Specification:

    • Three-button optical mouse
    • Scroll wheel
    • USB type-A connector
    • Compatible with all Raspberry Pi products
    • Ergonomic design for comfortable use
    • Available in Red/White and Black/Grey
    • This mouse will look great with your Red/White official keyboard
    R119.90  Inc VAT
    Official Raspberry Pi Mouse (black/grey) (Official black/grey mouse)

    The Official Raspberry Pi Mouse is finally here!

    This sleek, stylish and ergonomic mouse from the team at Raspberry Pi includes three buttons, two main ones for right and left click, and a scroll wheel with button for scrolling. . . and more clicking. . . what more do you need from a mouse!

    Mouse Specification:

    • Three-button optical mouse
    • Scroll wheel
    • USB type-A connector
    • Compatible with all Raspberry Pi products
    • Ergonomic design for comfortable use
    • Available in Black/Grey and Red/White
    R119.90  Inc VAT
    Official Raspberry Pi US Keyboard (Black/Grey) (Official black/grey keyboard)

    The Official Raspberry Pi Keyboard is finally here!

    This sleek and stylish keyboard from the team at Raspberry Pi includes three in-built USB 2.0 type-A ports for powering other peripherals (such as the official Raspberry Pi mouse)!

    Please Note. This keyboard is available in 6 language formats: UK, US, DE, FR, ES & IT. This model is the US version as used in South Africa.


    Keyboard Specification:

    • 79-key keyboard (78-key US keyboard)
    • 3 USB 2.0 type-A ports for powering other peripherals
    • Automatic keyboard language detection
    • USB type-A to micro USB type-B cable for connection
    • Compatible with all Raspberry Pi products
    • Ergonomic design for comfortable use
    • Available in Red/White and Black/Grey
    R289.90  Inc VAT
    Pro Mini ATMEGA328P 5V/16MHz for arduino (Pro Mini ATMEGA328P)
    It's blue! It's thin! It's the Arduino Pro Mini! SparkFun's minimal design approach to Arduino. This is a 5V Arduino running the 16MHz bootloader. Arduino Pro Mini does not come with connectors populated so that you can solder in any connector or wire with any orientation you need. We recommend first time Arduino users start with the Uno R3. It's a great board that will get you up and running quickly. The Arduino Pro series is meant for users that understand the limitations of system voltage (5V), lack of connectors, and USB off board.

    We really wanted to minimize the cost of an Arduino. In order to accomplish this we used all SMD components, made it two layer, etc. This board connects directly to the FTDI Basic Breakout board and supports auto-reset. The Arduino Pro Mini also works with the FTDI cable but the FTDI cable does not bring out the DTR pin so the auto-reset feature will not work. There is a voltage regulator on board so it can accept voltage up to 12VDC. If you're supplying unregulated power to the board, be sure to connect to the “RAW” pin and not VCC.



    Features:

    •     ATmega328 running at 16MHz with external resonator (0.5% tolerance)
    •     0.8mm Thin PCB
    •     USB connection off board
    •     Supports auto-reset
    •     5V regulator
    •     Max 150mA output
    •     Over current protected
    •     Weighs less than 2 grams!
    •     DC input 5V up to 12V
    •     On board Power and Status LEDs
    •     Analog Pins: 8
    •     Digital I/Os: 14

    Getting Started
    Getting started with Arduino products
    R64.90  Inc VAT
    Raspberry Pi Official EU only Power Supply 5.1V 2.5A (Black) for RPi, RPi3, Zero and Pico (Pi3 Power 2.5A Black EU)

    You'll need a USB Type C adapter to use this supply for Pi 4


    This PSU supports up to 2.5A of current, so it won't let you down when powering hungry devices through your Raspberry Pi 3 Model B

    Technical Data

    • 5.1V 2.5A Output
    • 1.5m Cable
    • Black with Raspberry Pi Logo
    • Input Voltage AC Max: 264V
    • Input Voltage AC Min: 90V
    • Output Connector: USB Micro
    • Output Voltage Nom.: 5.1V
    • Interchangeable Adaptor - EU/UK

      The below is a copy from https://www.raspberrypi.org/help/faqs/#powerReqs.

      Here is a table comparing the amount of power drawn in amps under different situations:

        Pi1 (B+)Pi2 BPi3 B (Amps)Zero (Amps)
      BootMax0.260.400.750.20
       Avg0.220.220.350.15
      IdleAvg0.200.220.300.10
      Video playback (H.264)Max0.300.360.550.23
       Avg0.220.280.330.16
      StressMax0.350.821.340.35
       Avg0.320.750.850.23
      Test conditions used a standard Raspbian image (current as of 26 Feb 2016),

    R154.90  Inc VAT
    Per Page      1 - 20 of 1157
