CNC
Packing: 10 x T-nut
Size: 75mm x 50mm x 35mm (L x W x H)
Rated maximum output: ± 3A, peak 3.5A
Working voltage: DC 10V-35V
Recommended to use a switching power supply: DC24V power supply
Subdivision: whole step, half-step, step 1/8, 1/16 step, a maximum of 16 Subdivisions.
Feature:
Using the Toshiba TB6560AHQ new original chip with low voltage shutdown, overheating stop and over current protection circuit to ensure optimal performance.
For two-phase within 42, 57 stepping 3A / four-phase / of line four / six-wire stepper motor, and is not suitable for more than 3A stepper motor.
Automatic half current function.
6N137 high-speed optical coupling, guarantee high speed without losing step.
Features similar products:
1. Current grade-by-adjustable to meet your demand for a variety of applications.
2. Semi-automatic flow adjustable.
3. 6N137 high-speed optical coupling, guarantee high speed without losing a step.
4. Thick teeth heat sink for good heat dissipation.
Package includes:
1 x TB6560 1 axis driver board
| General Specification | |
| Brand | EleksMaker® |
| Model | EleksLaser-A3 pro 2.5W |
| Material | Aluminum Profile and Acrylic |
| Packaging Size | 58x40x14cm / 22.83x15.75x5.51inch (L*W*H) |
| Assembled Product Size | 60x46x18cm / 23.62x18.11x7.09inch (L*W*H) |
| Package Weight | 4.60kg |
| Can Engrave | Wood, Plastic, Paper, Bamboo, Ox Horn, Leather, Sponge Paper, etc. |
| Can not engrave | Metal, Stone, Ceramics, Glass, Reflective or Transparent Material |
| Technical Parameters | |
| Laser Power | 2.5W / 2500mW (laser included) |
| Laser Wavelength | 445nm |
| Control Board | EleksMana SE |
| Communication Port | MircoUSB |
| Laser Quick Replace | Supported |
| Stepper Motor | 42H34S-1304A |
| Power Input | AC100-240V |
| Working Voltage | DC 12V |
| Working Current | DC 4-5A |
| System Support | Win XP/7/8/10 |
| Engrave Mode | Photo, Word, Scan, outline, Pixel Laser Engraving |
| Supported Formats | jpg, bmp, svg, G-code |
| Control Software System | EleksCam, T2-Laser, GrblController, LiteFire, Laser GRBL, etc.(Can NOT use Benbox) |
| Engraving Accuracy | 0.01mm |
| Engraving Area | 30x40cm / 11.81 x 15.75inch (maximum) |
| Engraved Object Height limitatiion | No Limitation |
| Function | Ideal for amateur laser engraving, equipped with low light positioning and freedom positioning functions. |
| Features | 30X38cm ultra large engraving area,gantry shape design, no engraving height limitation. |
| Three stepper motor drive providing faster moving speed. | |
| 2500mW violet laser module with heatsink, high laser engraving power and long term use. | |
| can print any pictures easily | |
Tips:
Laser machine installation, software downloading, software setting ,operating instructions and FAQ: http://wiki.eleksmaker.com/doku.php?id=elekslaser_a3_pro
Laser module self-checking tips link: https://www.dropbox.com/s/nuuu98e3einfee4/Laser%20Tips.pdf?dl=0
Please Note:
1. Please wear laser goggles during usage and avoid touching the laser directly with your eyes or skin!
2. The red cord is DC12v(+),black cord is GND(-), yellow cord is signal(S). Please make sure you know the wire position and connect to the ManaSE board correctly!
3. Do not use the laser module for more than 30 minutes at a time
Packaging List:
1 x DIY 2500mW Laser Engraving Machine(assembly needed)
FAQ:
1. How to assemble the kit?
The whole assembly and operating manual link is here:http://wiki.eleksmaker.com/doku.php?id=elekslaser_a3_pro
You can also watch the video to do it:https://www.youtube.com/embed/_1ypts5489Y
2. What software can support this machine? And what image format? Engrave Mode?
Supported Software: EleksCam,T2-Laser, GrblController, LiteFire, Laser GRBL, etc.
EleksCam can be found at http://wiki.eleksmaker.com/doku.php?id=elekscam
Supported Image Format: jpg, bmp, svg, G-code
Supported Engrave Mode: Photo, Word, Scan, Outline, Pixel Laser Engraving
3. What systems can the EleksCAM support?
PC Windows XP/7/8/10
4. My laser doesn't work, what should I do?
If the machine does not work, it might be due to:
① The wire connection is wrong.Please check the connection like the picture shown.
② Your computer could not support the software.Please use Win XP 7/8/10 to check it.
③ Software problem.Please check whether wires are inserted rightly. And then check your data settings.
④ The kit misses some accessories.Please compare with the instructions
⑤ Laser module/ driver board/power supply is faulty.
⑥ Laser module self-checking tips link at http://www.dropbox.com/s/nuuu98e3einfee4/Laser%20Tips.pdf?dl=0
5: My software shows: Not data, what should I do?
There might be two reasons.
① You did not open Administrator privileges to run the software.
② Your computer architecture is incomplete:check whether VC ++ and .Net and directX are installed
6. Can I regulate the laser power or is the laser power is adjustable?
Our new Mana SE controller board can adjust the power. Please download our ElekesCAM software to do it.
7. Can I upgrade stronger power laser module by myself? Can I extent rail frame?
Yes,you can. A DC12V laser module can be installed on this machine. The red is positive.You can also extent the frame by yourself, but we do not stock the rails.
8. When I click arrows to control the motors, it works. But when I begin to make it work with EleksCAM software,
it does not move. What should I do?
The EleksCAM could move by hand but could not move when focus.The problem is the area and language inside the system control panel.
Please set the format to English and United States.Then it will be ok. Detail is shown in the wiki link above.
9. My laser module is always on and could not turn off.What should I do?
Please try to connect the Signal(S) and GND(-).
If the laser module turn off, that means the laser module is ok, the problem might be the ManaSE board or a software setting.
Description:
There are two L9110S motor controller chips onboard
This module can simultaneously drive two DC motors or a 4-wire 2-phase stepper motor
Feature:
Work under low static current
Power supply voltage: DC 2.5V - 12V
Each channel has 800mA continuous current output
Low saturation pressure drop
TTL / CMOS output level compatible, can be connected directly to the CPU
Output built-in clamping diode, apply to the perceptual load
Control and drive integrate in IC
Pin high pressure protection function
Working temperature: 0°C - 80°C
Size: 29 x 21mm(L x W)
Circuit diagram:
Package includes:
1x L9110S stepper motor driver
Robot control with Python
Fire four solenoids, spin two DC motors or step one bi-polar or uni-polar stepper with 1.2A per channel (3A peak) using the TB6612.
We really like these dual H-bridges, so if you want to control motors without a shield or HAT these are easy to include on any solderless breadboard or perma-proto.
We solder on TB6612 onto a breakout board for you here, with a polarity protection FET on the motor voltage input and a pullup on the "standby" enable pin. Each breakout chip contains two full H-bridges (four half H-bridges). That means you can drive four solenoids, two DC motors bi-directionally, or one stepper motor. Just make sure they're good for 1.2 Amp or less of current, since that's the limit of this chip. They do handle a peak of 3A but that's just for a short amount of time. What we like most about this particular driver is that it comes with built in kick-back diodes internally so you dont have to worry about the inductive kick damaging your project or driver!
There's two digital inputs per H-bridge (one for each half of the bridge) as well as a PWM input per driver so you can control motor speed. Runs at 2.7V-5V logic. The motor voltage is separate from the logic voltage. Good for motor voltages from 4.5V up to 13.5V! This wont work well for 3V motors.
Comes as one assembled and tested breakout plus a small strip of header. You'll need to do some light soldering to attach the header onto the breakout PCB. Arduino, motors, and power supply not included. Check out the handy tutorial on assembly and wiring!
| Model | 42BYGH34-0400A |
| Material | Metal |
| Dimensions | approx. 42x42x34mm (Length x Width x Thickness) |
| Step Angle | 1.8° |
| Rated Voltage | 12V |
| Rated Current | 0.4A |
| Number of phase | 2 |
| Resistace Per Phase | 30Ω±10% |
| Rotor Intertia | 34g.cm2 |
| Holding Torque | 28N.cm |
| Detent Torque | 1.6N.cm |
Scope: 3D Printers, Monitor Equipment, Medical Machinery, Textile Machinery, Packaging Machinery, Stage Lighting,ect.
Teeth: 16
Groove width: 7mm
Total width: 15mm
Bore: 5mm
Flange: Dual
Material: Aluminium
GT2 Belt:
Pitch: GT2
Width: 6mm
Length: 5m
Features:
Durable and practical
Designed specifically for linear motion
GT2 Pulley and GT2 Belt are used together.
Round tooth profile guarantees that the belt tooth fits smoothly
16 Teeth contact with the belt, that minimizes the chance of the belt slipping
Package includes:
1 x GT2 Belt
5 x GT2 Pulleys
1 x allen key
Teeth: 20
Groove width: 5mm
Total width: 15mm
Diameter of bore: 5mm
Flange: Dual
Material: Aluminium
GT2 Belt:
Pitch: GT2
Width: 6mm
Length: 2m
Idler:
Teeth: 20
Diameter of bore: 5mm
Total width: 8mm
Material: Aluminium
Features:
Durable and practical
Designed specifically for linear motion
GT2 Pulley and GT2 Belt are used together
Round tooth profile guarantees that the belt tooth fits smoothly
20 Teeth contact with the belt minimizes the chance of the belt slipping
Package includes:
1 x GT2 Belt
2 x GT2 Pulley
2 x Idler
4 x Tensioner
1 x Allen key
Bore distance: 20mm x 20mm
For: M3 (Both sides of the screw)
Suitable belt: GT2 / MXL 6mm (note: belt not included)
Material: High strength nylon
Package includes:
1 x M3 Delta Adjustable Pulley
Specifications:
Teeth: 36 (T)
Pitch: 2 (mm)
Bore: Dia.5 (mm)
Material: Aluminum Alloy
Belt Width: 6 (mm)
Package includes:
1 x GT2 Aluminum timing belt pulley
The universal Ball Bearings is great for you to replace the damaged Ball Bearings in your devices to improve efficiency and save energy.
Widely used in home appliances, industrial, low noise and high speed electric motors, construction machinery, automotive components, pumps, and machinery. Smooth moving, low friction, high rigidity and long life. Economical, easy to maintain replace.
Specifications :
Model : SC8UU
Material : Steel, Aluminum
Size : Approx. 34 x 30 x 22cm / 1.34 x 1.18 x 0.87"
Inner Diameter : Approx. 8mm / 0.31"
Package included :
1x SC8UU Linear Motion Ball Bearing
Here are the links of the CE Certification and the Environmental Certification:
CE Certification:
https://www.dropbox.com/s/x937yu696g449o2/CE%20Certification%20.pdf?dl=0
Environmental Certification:
https://www.dropbox.com/s/38ncgzktlsxlhvw/Environmental%20Certification%20.pdf?dl=0
Brand: Machifit
| Dimensions | 140mm×110mm×48mm (L*W*H) |
| Input | AC220V±10% 50/60Hz |
| Spindle Motor | 500w |
| Spindle Speed | 3000-12000r/min |
| Motor Diameter | 52mm |
| Motor Length | 208mm |
| Operating Voltage | 100V DC |
| Current | 6A |
| Speed | Up to idle up to 15,000 rev / min |
| Torque | 5000G/CM |
| Insulation Resistance | > 2 megohms |
| Dielectric Strength | 400V |
| High precision spindle runout 0.01-0.03 | |
Chuck size:
Small diameter: 7.8mm
Nut Size:
Inner Diameter: 8.7mm
Height: 13mm
Hex Diameter: 17mm
Outer Diameter:19mm
The Usage of "Don't pipe":
Its function is to inhibit the switched source. If they are open, the source does not give tension.
If the short circuits, for example with a relay, the source generates the voltage to which it is regulated with the potentiometer.
There will be no problem in controlling the motor using these pins.
| Model | F695ZZ |
| Material | Chrome Steel |
| Size | 5 x 13 x 4mm |
| Quantity | 1pcs |
Smooth operation, high accuracy.
1 x Ball Bearing
Box Size: 87x52x10mm (L*W*H)
6pcs 1/2 Inch Shaft Round Over Edging Router Bit
Specifications:
| Size | Cutter Diameter | Total length |
| 1/2" R | 1.25’’ | 2.40’’ |
| 7/16R | 1.12’’ | 2.31’’ |
| 3/8" R | 1.01’’ | 2.31’’ |
| 5/16" R | 0.99’’ | 2.24’’ |
| 1/4" R | 0.88’’ | 2.04’’ |
| 1/8" R | 0.77’’ | 2.04’’ |
Suitable for the DC motors (or DC load) within 20A.
Very easy to install and use.
Potentiometer with adjustable speed switch function, and button switch function.
Input supply voltage: DC 9V to 60V
Max current: 20A
Sustained current: 18A
PWM frequency: 25KHz
Adjustable speed range: 0%-100%
Speed adjustment way: Potentiometer
Output voltage: Linear under load
Speed control type: Basins
Size(LxWxH): 90 x 50 x 35 mm
Cable Length: 130 mm
Operating instructions:
Before attempting to wire the controller, make sure the power is off.
WARNING:
DO NOT REVERSE POSITIVE AND NEGATIVE POWER LOADS.THIS WILL DAMAGE THE CONTROLLER.
TO CHANGE MOTOR DIRECTION, INTERCHANGE THE POSITIVE AND NEGATIVE WIRES OF MOTOR.
1.Connect wires refer to the "wiring diagram"
2.Turn on the power.
3.Adjust the potentiometer.
Connection mode:
Red Line: Power + Black Line: Power -
Blue Line: Motor+ Green Line: Motor -
1 x DC Motor Speed Controller with metal shell
Specifications:
Ball screw support base fixed end 4.2x3.5cm/1.7*1.4 inch
Package Includes:
Let your robotic dreams come true with the new DC+Stepper Motor HAT from Adafruit. This Raspberry Pi add-on is perfect for any motion project as it can drive up to 4 DC or 2 Stepper motors with full PWM speed control.
Raspberry Pi and motors are not included.
Since the Raspberry Pi does not have a lot of PWM pins, we use a fully-dedicated PWM driver chip
onboard to both control motor direction and speed. This chip handles
all the motor and speed controls over I2C. Only two pins (SDA & SCL)
are required to drive the multiple motors, and since it's I2C you can
also connect any other I2C devices or HATs to the same pins.
In fact, you can even stack multiple Motor HATs, up to 32 of them, for controlling up to 64 stepper motors or 128 DC motors (or a mix of the two) - just remember to purchase and solder in a stacking header instead of the one we include.
Motors are controlled by TB6612 MOSFET drivers with 1.2A per channel and 3A peak current capability, a big improvement over L293D drivers and there are built-in flyback diodes as well.
We even had a little space so we added a polarity protection FET on the power pins and a bit of prototyping area. And the HAT is assembled and tested here at Adafruit so all you have to do is solder on the included 2x20 plain header and the terminal blocks.
Lets check out these specs again:
- 4 H-Bridges: TB6612 chipset provides 1.2A per bridge (3A peak) with thermal shutdown protection, internal kickback protection diodes. Can run motors on 4.5VDC to 13.5VDC.
- Up to 4 bi-directional DC motors with individual 8-bit speed selection (so, about 0.5% resolution)
- Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil, interleaved or micro-stepping.
- Big terminal block connectors to easily hook up wires (18-26AWG) and power
- Polarity protected 2-pin terminal block and jumper to connect external 5-12VDC power
- Works best with Raspberry Pi model A+, B+, Pi 2 B or Pi 3 B.
- Install the easy-to-use Python library, check out the examples and you're ready to go!
Comes with an assembled & tested HAT, terminal blocks, and 2x20 plain header. Some soldering is required to assemble the headers on. Stacking header not included.
Raspberry Pi, motors, and battery pack are not included but we have lots of motors in the shop and all our DC motors, and stepper motors work great. Check out Adafruit's detailed tutorial for tons of info including schematics, wiring diagrams, python libraries and example walkthroughs.
