Charger Docter - USB Voltage and Current Meter (USB Docter single)

Use the USB Charger Doctor to measure the working voltage and current output for any USB port and project. This plastic dongle plugs between a USB device, and passes the data lines through. There's a 0.05 ohm resistor in line with the power pin that is used to measure current draw. The Doctor's digital display instantly reads the numbers out for testing devices such as chargers, cables, and cell phones.

You can use this device from 3.5-7VDC input voltage (although most USB devices tend to hover around 4.75 to 5.25) and up to 3A of current. It flips between voltage and current readouts every 3 seconds or so. It's a very handy tool for testing USB devices, checking load levels and debugging battery chargers and boost converters.

Technical Data

Dimensions:

  • 21mm x 53mm x 15mm / 0.8" x 2.1" x 0.6"
  • USB Plug: 13mm / 0.5"
  • Weight: 16.2g

Specifications:

  • USB 1.x and 2.x - all data speeds. Does not have USB v3 pins so USB v3 connections will automatically downgrade to v2
  • Working Range: 0~3A, 3.5~7VDC
  • Resolution: 10mV / 10mA
  • Operating Temperature: 0-60ºC
Add to Cart
R90.00
Mini Digital Blue + Red LED DC Current Meter Voltmeter w/ Ampere Shunt (DC meter volt/amp shunt)
- Color: Black
- Material: Plastic
- Features:
- Operating voltage:DC 4.5 ~ 30V
- Measure voltage: DC 0 ~ 100V
- Minimum resolution(V): 0.1V
- Measure current:50A (require external shunt)
- Minimum resolution(A): 0.1A
- Operating current: <20mA
- Display: three 0.28" LED digital tube
- Display color: Red and Blue (two-color display)
- Dimensions: 48 x 29 x 21mm
- Mounting cutout: 45.5 x 26.5mm
- Refresh rate: about 500mS / times
- Measure accuracy: 1% (± 1 digit)
- Operating temperature: -10 to 65°c
- Operating Humidity: 10 to 80% (non-condensing)
- Working pressure: 80 to 106 kPa
- Applications:Suitable for automotive/electric cars/motorcycles battery monitoring or other products voltage current measurement
- Wiring:
- Black line (thin): vacant or buck circuit (module) negative
- Red line (thin): power supply+
- Black line (thick): COM, common measuring
- Red line (thick): PW+, measuring terminal voltage input positive
- Yellow line (thick): IN+, current input+
- Notice:
- The voltage between the thin red and thin black lines must be within DC 4.5-30V
- The ammeter can only be connected to the negative of the device under test
- Exceeds 5A, long-term full load working continuously, it is recommended that the measurement side of the leads are directly soldered to the socket
- When the black thin line vacant, it is better to use insulating tape around the exposed part of the wire, to prevent short circuits
- If just be used as a voltmeter, it is recommended that the yellow line and the black line were connected together, to prevent the ammeter digital flashing
- Package include:
- 1x Digital Volt Amp Meter
- 1x 50A/75mV DC Current Shunt
Dimensions: 1.89 in x 1.14 in x 0.83 in (4.8 cm x 2.9 cm x 2.1 cm)
Weight: 2.61 oz (74 g)
Add to Cart
R255.00
Jagged Design Experimental Platform For Arduino UNO R3 (JD exp uno)
Description:

Mounting holes for Arduino Uno R3
Size: 135mm x 102mm
Ideal for use with Solderless 400 Point Breadboard.(Not included)
Acrylic board locally designed and laser cut by Jagged Design
Shadows engraved on board for easy component placing

Kit includes:

1 x Acrylic plate
4 x standoffs
4 x M2.5x6 screws
4 x M2.5 nuts
4 x bumper pads
Add to Cart
R74.99
Jagged Design Experimental Platform For Raspberry B+, Pi 2 and Pi 3 Model B (JD Exp RPi)
Description:

This Experimental Platform is for Raspberry Pi 2, 3 Model B  B+
Size: 134mm x 118mm
Ideal for use with Solderless 400 Point Breadboard.(Not included)
Acrylic board locally designed and laser cut by Jagged Design
Shadows engraved on board for easy component placing

Kit includes:

1 x Acrylic plate with mounting holes
4 x Standoffs
4 x M2.5x6 screws
4 x M2.5 nuts
4 x bumper pads
Add to Cart
R74.99
Digital Ammeter LED Panel Meter 0-10A (Digital Ammeter Panel 0-10A)
Description:

DC ammeter: 0-10A with reverse polarity protection
Power supply: DC4-30V
Measuring range: 0 - 10A
Measurement accuracy: ±0.1%
Refresh rate: about 200ms
Display: 0.56 inch digital tube
Color: Green display
Operating current: Less than 8mA
Operating temperature: -10°C to 65°C
Input impedance: 5mΩ
Overall dimension: 48 x 29 x 26mm

Package Included:

1 x 0.56 Inch digital ammeter
Add to Cart
R115.00
Jagged Design Dual Experimental Platform RPi and Uno (Dual Exp board)
Description:

This is an Experimental Platform For Raspberry Pi 2/3 Model B and B+ and Arduino UNO R3
Acrylic board locally designed and laser cut by Jagged Design
Shadows engraved on board for easy component placing
Size 210mm x 145mm

Package includes:

1 x Acrylic Platform
8 x Standoffs
8 x M2.5 screws
8 x M2.5 nuts
4 x rubber bumper feet
Add to Cart
R99.00
2Pcs Speaker Terminal Binding Post Banana Plug Socket Connector (2 x binding posts)
Description :

Type : Banana plug or lug
Solid hard plastic shell
Quantity : 2pcs ( 1 x red and 1 x black )
Easy installation with screws and nuts
Suitable for :  4mm banana plugs, lugs or bare wire

Package Included :

  1 pair of speaker binding posts (1 x red and 1 x black)
Add to Cart
R16.50
PLCC IC Chip Extractor Motherboard Circuit Board Component Puller (IC chip extractor tool)
Description:

Appropriate for extracting PLCC, PGA, PCLL and IC packed by DIP from SOCKET or PCB
With gripping your hand you can extract the IC vertically and perfectly
Great for extracting dense IC
Metal and shielded plastic to avoid static charge damage to IC components
Small hook for easy extracting IC and installation
Perfect for repair man, such as TV / DVD / PC technicians or IC workers

Specifications:

Dimension: extractor L100mm, small hook L4 to 9mm (when you grip the extractor the hook will shorten to 4mm)
Material: stainless steel and plastic

Package includes:

1 x IC chip extractor
Add to Cart
R49.00
V27D-T1 0.56" 3-Digital LED Voltmeter - Black (DC 3.2~30V) (dc panel volt meter)
Features:

Display Color: Red
The black line connects to the negative electrode, red line connects to positive pole of power supply, yellow line connects to positive pole of tested power supply
Material: Plastic Shell
Display Digit: 3
Measuring Range: DC 0-30V
Working voltage: 4-30V
Display Size: Approx 2.3cm x 1.2cm / 0.91" x 0.47"
Overall Dimension: Approx 3.4cm x 2.2cm x 2cm / 1.34" x 0.87" x 0.79" (L x W x H)
Cable Length: Approx 20cm / 7.87"

Package Includes:

1 x Digital LED Display Voltmeter
Add to Cart
R80.00
GPIO Reference Board (Model B+,A+,2B and 3B) (gpio ref 40pin board)

RASPBERRY PI NOT INCLUDED(Neither the keys for those who wondered)

This cute little GPIO reference board from ModMyPi allows you to quickly and easily distinguish between the different pins of the Raspberry Pi Model B+, Raspberry Pi 2B and Pi 3B! It's even got a key chain hole, so you can carry it around and keep it handy - you'll never know when you need to hack a Pi!

The GPIO reference board features BCM numbering on one side and the pin names on the other. It can be soldered for permanent referencing, or slipped on and off when required.

Dimensions:

Width = 67mm
Height = 19mm
Thickness = 0.8mm
Add to Cart
R35.00
Solder Wire 1mm 17gr - Dispenser (17g solder dispenser)

Specifications

  • weight: 17g
  • 1.0mm
  • remark: tube
  • 60% Sn - 40% Pb
  • with resin core
  • melting point: 185C
Add to Cart
R39.99
Anti-Static ESD Wrist Band with Grounding Lead (anti static wrist)

Product information
Brand new high quality anti-static wrist strap with grounding lead and clip to prevent ESD damage to sensitive electronic components or equipment. The wrist strap with alligator clip tip is fully adjustable. The inner conducting layer is made of stainless steel filaments. The lead is made from durable polyurethane coated coil cords.

Specifications
High quality strain relief
Soft elastic band for comfort
Current limiting resistor 1M Ohm ± 5%
Electro-scattering time 0.1sec
Rinse resistant
Weight: 25g
Cable Length: 180cm

Package includes
1 x Anti-static wrist band with 180cm grounding lead

Add to Cart
R49.00
RJ45 RJ11 2-in-1 Network and Phone Cable Tester (RJ45 tester)
The cable tester can be used for RJ45 networks, RJ11 and telephone cables. It can test the cables with reliable accuracy. This is a useful tool for technicians in installation and maintenance.

- Tests both RJ45 (max 8-pin Network) and RJ11 (max 6-pin phone)
- Powered by a single 9V cell battery
- Carrying case not included
Add to Cart
R125.40
USB Detector Current Voltage 3V-9V Tester Dual USB Dual display (USB Docter Dual)

Use the USB Charger Doctor to measure the working voltage and current output for any USB port and project. This plastic dongle plugs between a USB device, and passes the data lines through. There's a 0.05 ohm resistor in line with the power pin that is used to measure current draw. The Doctor's digital display instantly reads the numbers out for testing devices such as chargers, cables, and cell phones.

You can use this device from 3.5-7VDC input voltage (although most USB devices tend to hover around 4.75 to 5.25) and up to 3A of current. It displays both voltage and current readouts. It's a very handy tool for testing USB devices, checking load levels and debugging battery chargers and boost converters.

Out Of Stock
R110.00
-55 to 125 Degree Red LED Digital Temperature Meter Sensor (temp display & probe)

  This item could be used in many harsh applications such as refrigerators, air-conditioners, aquariums and so on.
With DC7-30V power range, you could power it with 12V DC easily. When out of range, the meter will display E2.
This Thermometer can only display the temperature in ℃.

Specifications :

Power Supply Voltage : DC7-30V(with anti-reverse protection)
Measuring Temperature : -55℃ to 125℃
Units of Measurement : ℃
Display Color : Red
Display : Three 0.56 Inch LED digital tube
Refresh Rate : About 300mS/ times
Minimum Input : -55℃
Maximum Input : 125℃
Accuracy : About 0.2℃
Overload : Please do not attempt to measure higher than 150℃
Operating Temperature : -40℃-85℃
Sensor : DS18B20, stainless steel sheath package, waterproof, anti-corrosion, high temperatures
Size: Approx. 47mmx28mmx25mm
Length of Sensor : 1m
Probe Dimensions : Approx. 25 x 6 mm (LxD)

Package includes :

1 x -55 ~125 Degree LED Thermometer Meter with probe
Add to Cart
R199.00
Mini 5'' (125mm) Wire Strippers (mini wire stripper)

Just like the one's you used at school, except these one's are new and super sharp!

These low cost wire strippers are excellent for beginners and pro's alike! Spring loaded and adjustable for cable and wire up to 3mm, everyone needs a pair! By fixing the adjustable screw to the desired length (or using the strippers free hand), they can 'strip' the PVC insulation from copper wire for prototyping, breaboarding and any other electronic project you can think of!

Features:

  • 5" Stripper and Cutter
  • Pressed Steel Stripper for Cables up to 3mm Diameter.
  • Hardened and tempered sprung steel blades.
  • Red insulated handles.
  • Adjustable screw controller.
  • Length - 5"
  • Cutting Capacity - 3mm
Add to Cart
R59.00
150mm Diagonal Cutters (150mm Diagonal Cutters)

These 6" Diagonal Cutters are the perfect companion for all your Raspberry Pi projects. Strong, accurate, comfortable and well proportioned for electronics. Excellent for snipping wires and trimming solder - a good 'all-rounder'.

Features

  • Drop forged, heat treated fully polished steel
  • Long Nose Pliers with a Matted (Rubber Feel) handle for a comfortable grip.
  • Diagonal Cutters with accurate 'pointed' tip for precision trimming
  • Length - 150mm (6'')
Add to Cart
R65.00
150mm Long Nose Pliers (150mm Long Nose Pliers)

These 6" Long Nose Pliers are an excellent addition to your Raspberry Pi project toolkit. The extra long nose of these pliers is perfect for getting at those little components!

Strong, accurate and comfortable with a matted grip - a good 'all-rounder' and excellent for squeezing, bending and shaping anything!

Features

  • Drop forged, heat treated fully polished steel
  • Long Nose Pliers with a Matted (Rubber Feel) handle for a comfortable grip.
  • Serrated Jaw for Extra Grip
  • Integrated Wire Cutters
  • Length - 150mm (6'')
Add to Cart
R55.00
Helping Hand Clamp Tool with Magnifier (Helping Hand Clamp)

Ever felt like you need a third hand when soldering or fiddling with little components?  How about two extra mini crocodile-clip hands, with the addition of a magnifying glass, which also looks like a mini robot?

Well, we think you'll love this helping hand then! Perfect for gripping PCB's, small components, or even as a nice stand for your Raspberry Pi.

Features

  • 'Third Hand' Tool with integrated Magnifying Glass
  • Adjustable joints for movement in all directions
  • 2 x Strong alligator clips hold work securely
  • Heavy cast iron base for added stability
  • Distortion free magnifying glass
Add to Cart
R79.00
