Wearables
This is the LilyPad main board consisting of an ATmega328 using 5V DC power. The latest version of the LilyPad supports automatic reset for even easier programming. The back side of the LilyPad is now completely flat! We now use a surface mount programming connector to keep the header from poking through.
This version of the LilyPad now uses the new ATmega328 at 8MHz. 0016 supports the Pro Mini 328/8MHz/16MHZ. Use this setting when using this new LilyPad 328.
LilyPad is a wearable e-textile technology developed by Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing.
Various input, output, power, and sensor boards are available. They're even washable!
What's in the box?
1 x 328 Main Board
Perfect for soldering, perfect for robotic ,electronic, and restoration projects.
It can hold two CR2032 coin batteries.
Features:
Output: 6V
Color: Black
Model: For CR2032 x 2
What's in the box?
1 x CR2032 Battery enclosure (Batteries not included)
Need batteries? You will find our battery selection here
We designed this board to give the user a very discrete button without any edges. Button closes when you push it and opens when you release (momentary push button).
Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing. Various input, output, power, and sensor boards are available. They're even washable!
Package:
2 x LilyPad Button Board module for ArduinoWe designed this board to give the user a very discrete button without any edges. Button closes when you push it and opens when you release (momentary push button).
Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing. Various input, output, power, and sensor boards are available. They're even washable!
Dimensions:
8mm x 16mm
Thin 0.8mm PCB
Package Includes:
2 x LilyPad Button Board module for Arduino
Getting started with Lilypad button sensor board
Each LilyPad piece was creatively designed with large sew tabs to allow them to be sewn into fabric. Various input, output, power and sensor boards are available.
They're even washable (with special care)!
Specifications
- Operating voltage: 3-5V
- Operating current: 40MA
- Weight: 1g (5 by one weight)
- Size: 12.7 mm x 5.2mm x 2.2mm
What's in the box?
10 X LilyPad LED Modules
Resources
This LilyPad Coin Cell Battery Holder has a small slide switch installed on the board, in-line with the power so you can shut off your project and save batteries. This slide switch is the same as is found on the LilyPad slide switch board, so it's not easy to accidentally turn off or on.
Just like the original Coin Cell Battery Holder, this simple board holds a 20mm coin cell battery (such as a CR2032) and gives you 4 connection points (two positive and two negative) for sewing into your project.
Package Includes:
1 x LilyPad Coin Cell Battery Holder CR2032 Battery Mount Module
Need batteries? You will find our battery selection here
This board has AAA battery clips but can use an input from 1.2V to 5V.
LilyPad is a wearable e-textile technology developed by Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing. Various input, output, power, and sensor boards are available. They're even washable - but be sure to remove the battery!
What's in the box?
1 x LilyPad Power Supply Converter Module AAA Battery Step up to 5V
Need batteries? You will find our battery selection here
This is a small buzzer for the LilyPad system. Use 2 I/O pins on the LilyPad main board and create different noises based on the different frequency of I/O toggling. Loud enough to hear inside a pocket but not obtrusively loud.
Please note: This is an inductive buzzer meaning that is will act as a short to ground if you are not actively driving it. We recommend you put both I/O pins to low (0V) when the buzzer is not used. Also, it's come to our attention that washing these buzzers will damage them. Until we've figured out a solution to this, avoid washing any portion of your project that contains one of these buzzers.
LilyPad is a wearable e-textile technology developed by Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing. Various input, output, power, and sensor boards are available.
- 20mm outer diameter
- Thin 0.8mm PCB
Package Includes:
- 1 x LilyPad Buzzer module
Documents
Use the Tri-Colour LED board as a simple indicator, or by pulsing the red, green, and blue channels, you can create any colour. Very bright output.
This is a common anode(positive) design - to turn on a channel you simply need to ground one of the R/G/B pins to illuminate that channel.
LilyPad is a wearable technology developed by Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing. Various input, output, power, and sensor boards are available. They're even washable!
What's in the box?
1 x Lilypad common anode RGB module
Getting started with lillypad tri-color LED
This pack is a great way to get started with E-Textiles.
We have selected a number of products from our Electro-Fashion range, including three of our ultra-slim LEDs and two seperate power boards. There are enough components for you get started immediately to create some eye catching E-Textiles projects, the only limit is your imagination.
Features:
- Everything you need to complete two projects.
- Enough Electro-Fashion components to get started immediately with E-Textiles.
- Full instructions for assembly.
- Great project ideas and tutorials.
Contents:
- 2 x Coin Cell Holder.
- 3 x Sewable LEDs White.
- 3 x Flashing LEDs White.
- 1 x Slide Switch.
- 1 x Push Switch.
- 2 x CR2032 Coin Cell Batteries.
- 1 x 6m Conductive Thread.
Dimensions:
- Sewable Coin Cell Holder Length: 34mm.
- Sewable Coin Cell Holder Width: 20mm.
- Sewable Coin Cell Holder Height: 4.5mm.
- Ultra Slim Sewable LED Length: 15mm.
- Ultra Slim Sewable LED Width: 6.5mm.
- Ultra Slim Sewable LED Height: 2.7mm.
- Slide Switch Length: 18mm.
- Slide Switch Width: 8.5mm.
- Slide Button Switch Height: 4mm.
- Push Button Switch Length: 18mm.
- Push Button Switch Width: 8.5mm.
- Push Button Switch Height: 3mm.
- CR2032 Battery Height: 3.2mm.
- CR2032 Battery Diameter: 20mm.
Requires:
- Scissors.
- Needles.
Resources:
Caution:
- The coin cell holders in this pack contain Nickel and should not be used in designs where it will be in prolonged contact with the skin.
- Button/Coin compact design enclosure with On and Off Switch.
- Perfect for soldering, perfect for robotic ,electronic, and restoration projects.
- Holds one CR2032 coin batteries.
- Output: 3V
- Colour: Black
What's in the box?
1 x CR2032 battery holder with switch
Need batteries? You will find our battery selection here
Copper tape can be an interesting addition to your maker toolbox. The tape itself is made of thin pure copper so it's extremely flexible and can take on nearly any shape. You can solder to it, and the tape itself can carry current just like a normal wire. On the back is an electrically conductive adhesive. The adhesive can't carry significant current, but it is very handy for sensing applications where you don't want to solder the copper tape.
We've seen such tape used for EMI shielding, working with EL, making capacitive touch pads, ultra-thin wiring needs, etc.
It comes in a roll 25 meters long, and this tape is 5mm wide and .07mm thick. The tape has conductive adhesive on one side and a protective paper backing over the adhesive.
This is an example of a circuit made of Copper Foil Tape connected to the LED:

- Conductive Copper Tape
- Tape width: 5mm
- Tape Length: 25 meters
- Tape thickness: 0.07mm
- Adhesive on one side
This is conductive stainless steel sewing thread. Very thin, strong, smooth and is suited to build wearable products.
Stainless steel fiber yarn has its ability in thermal resistant up to 1300 degrees, and these spun yarn can produce into different kind of electromagnetic shielding fabrics, and in producing permanent shielding and conductive products.
Features:
- Thin
- Strong
Specifications:
- Material: 100% Stainless Steel Fiber
- Certification: ISO9001:2008
Sold per 1 meter lengths
