Zero Boards And Phats

Raspberry Pi Zero related boards and Phats
Sort By:
While the Zero 1.3 and the Zero W have limits set to 1 per order, the Zero WH has no limits. Finally you can buy as many as you need to complete that project.
R309.90  Inc VAT
Maximum 1 Unit Per Customer. We Reserve the Right to Cancel Repeat Orders.
R239.90  Inc VAT
Limited to 1 RPI Zero per customer (including units included in kits), we reserve the right to cancel duplicate and/or multiple orders.
R194.30  Inc VAT
The ProtoZero is a prototyping board for the Raspberry Pi Zero, that also fits the A+, B+ and Pi2.
R119.90  Inc VAT
Convert your Pi Zero or Pi Zero W into a convenient USB dongle.
R109.96  Inc VAT
R269.90  Inc VAT
This is a 4-port USB 2.0 hub for Raspberry Pi Zero, and it can be mounted to Raspberry Pi Zero back-to-back.
R229.90  Inc VAT
This RGB LED HAT can be easily attached on top of the Raspberry Pi to display colorful effect, and controlled by only one signal pin.
R150.31  Inc VAT
This addon board connects to a Raspberry Pi Zero (RPi0) or Zero W (Wireless) via pogo pins to provide a full sized, USB Type-A dongle
R129.90  Inc VAT
R219.90  Inc VAT
Use Four Letter pHAT to display... four letter words. Not that sort!
R199.90  Inc VAT
Explorer pHAT is the perfect prototyping side-kick for your Raspberry Pi!
R199.90  Inc VAT
This neat little board plugs directly into the Raspberry Pi GPIO header and provides 2 or 4 connectors for small stepper motors
R299.90  Inc VAT
R799.90  Inc VAT
Six touch-sensitive buttons to use for whatever your heart desires, with added LEDs (did you expect anything less?)
R109.96  Inc VAT
R179.90  Inc VAT
The cluster HAT V2.2 is an ideal tool for teaching, testing or simulating small scale clusters.
R1,390.90  Inc VAT
R1,491.49
Raspberry Pi Zero Wireless WH (Pre-Soldered Header) (ZERO WH)

The Raspberry Pi Zero WH has landed at PiShop! The Raspberry Pi Zero is an ultra low cost and ultra small variant of the original Raspberry Pi. It's tiny, measuring just 65mm x 30mm, and is perfectly designed for embedded applications, wearables, prototyping and any other Pi based tinkering you can think of, on a micro scale! The Raspberry Pi Zero Wireless features on board Wireless Internet & Bluetooth for all your connectivity needs!

The Raspberry Pi Zero features a BCM2835 chipset, overclocked to 1Ghz with 512MB RAM, and the same 1080p video output, so there's plenty of oomph in that little board. It also features the same 40 pin GPIO layout as the Raspberry Pi 2/B+/A+, with a pre-soldered male header. With it's small form factor and reduction in connectors, the Raspberry Pi Zero only uses ~ 140mA at 5V!

Unlike it's larger brothers and sisters, the Raspberry Pi Zero has an unpopulated composite (RCA) header and an unpopulated reset header. There's also no DSI screen port, no ethernet, no analogue audio and no full sized USB ports. Instead, the Pi Zero features a micro-USB power port, a micro USB OTG host port (for peripherals e.g. WiFi dongle), and a mini HDMI port for video.

HAT Compatibility Note: The Pi Zero is fully compatible with all HAT breakout boards, as it features the same 40 Pin GPIO as the Raspberry Pi 2/B+/A+

Raspberry Pi Zero Wireless Features:

  • BCM2835 chipset, Overclocked to 1Ghz
  • 512MB RAM
  • Tiny Form Factor: 65mm x 30mm x 5mm
  • Fully HAT compatible
  • 40pin GPIO with pre-soldered header
  • Stream and watch Hi-definition video output at 1080P
  • Micro SD Slot for OS
  • Tiny Current Draw ~ 140mA at 5V!
  • Mini-HDMI for Video
  • Micro-USB OTG Host for Data
  • Micro-USB for Power
  • Micro-CSI Camera Port
  • On-Board WiFi
  • On-Board Bluetooth

Raspberry Pi Operating System Downloads: https://www.raspberrypi.org/downloads/
Getting Started with Raspberry Pi

While the Zero 1.3 and the Zero W have limits set to 1 per order, the Zero WH has no limits. Finally you can buy as many as you need to complete that project.
R309.90  Inc VAT
Raspberry Pi Zero W (ZERO Wireless)


Maximum 1 Unit Per Order. If you require Raspberry Pi Zero Wireless in bulk, we allow quantity purchases of the Raspberry Pi Zero Wireless with pre-soldered headers!

The Brand New Raspberry Pi Zero Wireless has landed at PiShop! The Raspberry Pi Zero is an ultra low cost and ultra small variant of the original Raspberry Pi. It's tiny, measuring just 65mm x 30mm, and is perfectly designed for embedded applications, wearables, prototyping and any other Pi based tinkering you can think of, on a micro scale! The Raspberry Pi Zero Wireless features on board Wireless Internet & Bluetooth for all your connectivity needs!

The Raspberry Pi Zero features a BCM2835 chipset, overclocked to 1Ghz with 512MB RAM, and the same 1080p video output, so there's plenty of oomph in that little board. It also features the same 40 pin GPIO layout as the Raspberry Pi 2/B+/A+, which you'll need to solder your own headers to. With it's small form factor and reduction in connectors, the Raspberry Pi Zero only uses ~ 140mA at 5V!

Unlike it's larger brothers and sisters, the Raspberry Pi Zero has an unpopulated GPIO, unpopulated composite (RCA) header and an unpopulated reset header. There's also no DSI screen port, no ethernet, no analogue audio and no full sized USB ports. Instead, the Pi Zero features a micro-USB power port, a micro USB OTG host port (for peripherals e.g. WiFi dongle), and a mini HDMI port for video.

HAT Compatibility Note: The Pi Zero is fully compatible with all HAT breakout boards, as it features the same 40 Pin GPIO as the Raspberry Pi 2/B+/A+

Raspberry Pi Zero Wireless Features:

  • BCM2835 chipset, Overclocked to 1Ghz
  • 512MB RAM
  • Tiny Form Factor: 65mm x 30mm x 5mm
  • Fully HAT compatible
  • 40pin GPIO (Unpopulated)
  • Stream and watch Hi-definition video output at 1080P
  • Micro SD Slot for OS
  • Tiny Current Draw ~ 140mA at 5V!
  • Mini-HDMI for Video
  • Micro-USB OTG Host for Data
  • Micro-USB for Power
  • Micro-CSI Camera Port
  • On-Board WiFi
  • On-Board Bluetooth

Raspberry Pi Operating System Downloads: https://www.raspberrypi.org/downloads/
Getting Started with Raspberry Pi

Maximum 1 Unit Per Customer. We Reserve the Right to Cancel Repeat Orders.
R239.90  Inc VAT
Raspberry Pi Zero v1.3 (3B4 RPi Zero v1.3)

Maximum 1 Unit Per Order. If you require Raspberry Pi Zero Wireless in bulk, we allow quantity purchases of the Raspberry Pi Zero Wireless with pre-soldered headers!

The Raspberry Pi Zero features a BCM2835 chipset, overclocked to 1Ghz with 512MB RAM, and the same 1080p video output, so there's plenty of oomph in that little board. It also features the same 40 pin GPIO layout as the Raspberry Pi 2/B+/A+, which you'll need to solder your own headers to. With it's small form factor and reduction in connectors, the Raspberry Pi Zero only uses ~ 140mA at 5V!

Unlike it's larger brothers and sisters, the Raspberry Pi Zero has an unpopulated GPIO, unpopulated composite (RCA) header and an unpopulated reset header. There's also no DSI screen port, no ethernet, no analogue audio and no full sized USB ports. Instead, the Pi Zero features a micro-USB power port, a micro USB OTG host port (for peripherals e.g. WiFi dongle), and a mini HDMI port for video.

HAT Compatibility Note: The Pi Zero is fully compatible with all HAT breakout boards, as it features the same 40 Pin GPIO as the Raspberry Pi 2/B+/A+

Raspberry Pi Zero Features:

  • BCM2835 chipset, Overclocked to 1Ghz
  • 512MB RAM
  • Tiny Form Factor: 65mm x 30mm x 5mm
  • Fully HAT compatible
  • 40pin GPIO (Unpopulated)
  • Stream and watch Hi-definition video output at 1080P
  • Micro SD Slot for OS
  • Tiny Current Draw ~ 140mA at 5V!
  • Mini-HDMI for Video
  • Micro-USB OTG Host for Data
  • Micro-USB for Power
  • Micro-CSI Camera Port
Note: As this product is limited to 1 per customer; We reserve the right to cancel multiple and/or duplicate orders.

Raspberry Pi Operating System Downloads: https://www.raspberrypi.org/downloads/
Getting Started with Raspberry Pi

Limited to 1 RPI Zero per customer (including units included in kits), we reserve the right to cancel duplicate and/or multiple orders.
R194.30  Inc VAT
ProtoZero (protozero phat)

The ProtoZero is a prototyping board for the Raspberry Pi Zero, that also fits the A+, B+ and Pi2.

The ProtoZero is a breadboard-style prototyping board for the new Raspberry Pi Zero (and the first ever Pi Zero based Kickstarter campaign).

It's designed to make it easy to move your messy Raspberry Pi breadboard projects to a PCB.

Simply add your components to the prototyping area, connect GPIO, power and GND as required - solder it all up and away you go!

Features

  • Full breakout of the PiZero's 40-Pin GPIO header, ready to connect to your project
  • 154 holes of prototyping area - set in lanes of 3+ to make it even easier to connect your components to the Pi
  • Labelled GPIO numbers and printed lanes on both sides on the board
  • High-quality ENIG (Electroless nickel immersion gold) PCB plating
  • Female GPIO header included

The only assembly involved is the soldering of the GPIO header.

Make sure the header is fitted in to the PCB with the main 'PROTOZERO' text on the underside like the image below:

You should then solder the header from the top face of the PCB, ensuring the header is fitted to the outer GPIO section:

The ProtoZero is a prototyping board for the Raspberry Pi Zero, that also fits the A+, B+ and Pi2.
R119.90  Inc VAT
Pi Zero USB Stem (3A3 zero usb stem)

The Zero Stem uses the test points underneath your Pi Zero to attach a full-sized USB connector. Convert your Pi Zero or Pi Zero W into a convenient USB dongle.

Just plug it into a free USB port and you can connect to your Pi over USB ethernet and share your computer's internet connection without any additional cables or power supplies.

Zero Stem is soldered onto the bottom of your Pi Zero and secured with bolts, making it convenient to use on the go. Use it to create your own little plug-and-play virtual machine, VNC server, proxy server or combine several into a cluster.

Kit includes:

  • Zero Stem PCB
  • USB connector
  • Nylon bolts and nuts

Details:

  • Compatible with Pi Zero V1.3 (with camera connector) and Pi Zero W.
  • Not compatible with Pi Zero v1.2 (without camera connector)!
  • Supported in Raspbian Jessie Pixel and Lite
  • Setup needed (see below)
  • Requires soldering!

Assembly and Installation:

Visit https://zerostem.io/installation/ for complete assembly instructions.

Preparing Raspbian:

Thanks to Andrew Mulholland for writing up these instructions, which you can find in this GitHub Gist.

In short:

  • Flash your SD card as usual using Etcher or Win32DiskImager
  • Open up the "boot" partition and edit "config.txt", adding "dtoverlay=dwc2" to the bottom
  • Open up "cmdline.txt" and add "modules-load=dwc2,g_ether" after "rootwait"
  • Create a new file named "ssh" in the boot folder

Pop your newly set up SD card into your Pi Zero, plug it into a USB port and you should be able to SSH in to "raspberrypi.local", you will need Bonjour, iTunes or Quicktime installed in Windows or Avahi Daemon in Linux for this to work.

As Seen On Bilge Tank

Convert your Pi Zero or Pi Zero W into a convenient USB dongle.
R109.96  Inc VAT
ReSpeaker 2-Mics Pi pHAT (C4 respeaker 2 microphones)

ReSpeaker 2-Mics Pi HAT is a dual-microphone expansion board for Raspberry Pi designed for AI and voice applications! This means that you can build a more powerful and flexible voice product that integrates Amazon Alexa Voice Service, Google Assistant, and so on with your Raspberry Pi B+/2/3/Zero/ZeroW!

The ReSpeaker is based on the Cirrus Logic WM8960, a low power stereo codec and features 2 microphones on both sides of the board for collecting sounds. It also provides 3 x APA102 RGB LEDs, 1 x User Button and 2 x on-board Grove interfaces for expanding your applications. What is more, 3.5mm Audio Jack or JST 2.0 Speaker Out are both available for audio output.

Note: This product does not include the Pi Zero board!

Features

  • Raspberry Pi compatible (Supports Raspberry Pi Zero/Zerow/B+/2/3)
  • pHAT Size
  • Dual-Microphones
  • 2 Grove Interfaces: Supports GPIO and I2C
  • Programmable Button and LED: 1 x button and 3 x LEDs
  • Cirrus Logic WM8960 Audio Codec
  • Two types audio output socket : 3.5mm Audio Jack, JST2.0 Speaker Out
  • Far field support (up to 3 meters)

Usage

1.Get started with Google Assistant

2.How to use button to trigger Google Assistant

Documentation

Please visit Seed Studio's wiki page for more info about this product. It will be appreciated if you can help us improve the documents, add more demo code or tutorials. For technical support, please post your questions to Seed Studio's forum.

R269.90  Inc VAT
Zero4U (AW 3B3 ZERO4U usb hub phat)

This is a 4-port USB 2.0 hub for Raspberry Pi Zero, and it can be mounted to Raspberry Pi Zero back-to-back.

The 4 pogo pins on the back will connect the PP1, PP6, PP22 and PP23 testing pads on Raspberry Pi Zero, hence no soldering will be needed.

The USB hub will take power directly from your Raspberry Pi Zero, so you don’t need to power the USB hub separately. However you can use the JST XH2.54 connector on board as the alternative power input port.

The blue LED on board works the power indicator, and lights up when power is connected.

Each USB port has a dedicated white LED as transaction indicator, and a dedicated electrolytic capacitor to help stabilizing the output voltage.

If you use this USB hub with other types of computer, you can use a USB cable (not included) to connect the mini-USB port on board to the up-stream USB port.

Contents

  • 4-port USB hub board x 1
  • plastic spacer x 4
  • M2.5 plastic screw x 4
  • M2.5 plastic nut x 4

For more details, check out the User Manual

Please note: This version of Zero4U only works with Raspberry Pi Zero V1.3 (with camera connector)

SPECIFICATIONS

  • Dimension: 65mm x 30mm x 9mm
  • Weight: 14 g (net weight without any accessory)
  • Power Mode: Bus-Power / Self-Power
  • Standards: USB 2.0 and 1.1 compatibility
  • Working Voltage: 5V DC
  • Static Current: 1mA
  • Maximum Output Current: 2A for all ports in self-power mode, 500mA for all ports in bus-power mode
  • Operating Temperature: 0°C~70°C
  • Storage Temperature: -20°C~80°C
  • Humidity: 0~80%RH, no condensing
This is a 4-port USB 2.0 hub for Raspberry Pi Zero, and it can be mounted to Raspberry Pi Zero back-to-back.
R229.90  Inc VAT
WS True color RGB LED PHAT for Raspberry Pi (1B3 WS RGB LED PHAT)

Overview

This RGB LED HAT can be easily attached on top of the Raspberry Pi to display colorful effect, and controlled by only one signal pin.

Features

  • Supports any revision of Raspberry Pi (directly plugable)
  • Onboard 4 × 8 RGB LED (WS2812B)
  • Control pin is configurable via jumpers (0Ω resistor)
  • Break out control pins, easy for working with other MCUs
  • Comes with development resources and manual (examples in Python and Web control)

Specifications

  • Operating voltage: 5V
  • Brightness: adjustable 256 levels
  • Color depth: 24-bit true color (8-bit for R/G/B respectively, totally 256x256x256=16777216 colors)
  • Data rate: 800Kbps(typ)
  • Dimension: 65mm × 30.2mm
  • Mounting hole size: 3.0mm

How to Use

In the case of working with a MCU:

  • 5V ↔ 5V power
  • GND ↔ GND
  • DIN ↔ Signal input
  • DOUT ↔ Signal output (optional)

Development Resources

Wiki : www.waveshare.com/wiki/RGB_LED_HAT

This RGB LED HAT can be easily attached on top of the Raspberry Pi to display colorful effect, and controlled by only one signal pin.
R150.31  Inc VAT
USB-A Addon Board V1.1 Connector Expansion Board For Raspberry Pi Zero / Zero W (Zero USB A dongle board)
Please note: Raspberry pi zero not included

Overview:


This addon board connects to a Raspberry Pi Zero (RPi0) or Zero W (Wireless) via pogo pins to provide a full sized, USB Type-A connector.
You can use Raspberry pi zero or Raspberry pi zero W as a U disk via P4wnP1 P4wnP1 project, and you can use it as a BadUSB device too.

Specifications:

Size: 6g
Weight: 8.0 x 3.0 x 0.5cm  (with USB port)
             6.5 x 3.0 x 1.2mm (PCB size)

More info available at http://www.raspberrypiwiki.com/index.php/Raspberry_Pi_Zero_W_USB-A_Addon_Board

Package includes:

1x USB-A Addon Board
This addon board connects to a Raspberry Pi Zero (RPi0) or Zero W (Wireless) via pogo pins to provide a full sized, USB Type-A dongle
R129.90  Inc VAT
PXFmini autopilot shield for the Raspberry Pi (PXFmini autopilot)

The PXFmini is a low cost and open autopilot shield for the Raspberry Pi that allows you to create a ready-to-fly autopilot with support for Dronecode’s APM flight stack.

The shield has been designed specially for the Raspberry Pi Zero but it is also pin-to-pin compatible with the following boards:

  • - Raspberry Pi
  • - Raspberry Pi 2
  • - Raspberry Pi 3
  • - Raspberry Pi Zero

The PXFmini includes a header, spacers and the corresponding bolts to fix it to the Raspberry Pi Zero.

Sensors

- 3 AXES GRAVITY SENSOR
- 3 AXES GYROSCOPE
- 3 AXES DIGITAL COMPASS
- PRESSURE SENSOR
- TEMPERATURE SENSOR
- ADC FOR BATTERY SENSING


Note: not all the functionality might be available simultaneously. Some functions might shadow others. Also take in consideration that we are continuously improving the board thereby support for some options might be added in the future.

Getting started: http://docs.erlerobotics.com/brains/pxfmini/getting_started

Projects: http://docs.erlerobotics.com/brains/pxfmini/projects

3D model: https://mega.nz/#!A1JXnC5K!G8-YkEqQwrEg_ZOpubR8um43P-Ez5DCazUrnLYKrgRc

Operating system images: http://docs.erlerobotics.com/brains/os_images

Debian: http://docs.erlerobotics.com/brains/os_images/debian
R1,799.90  Inc VAT
White – Scroll pHAT HD (3B3 HD scroll phat white)

Scroll pHAT HD

A whole heap of LED pixels with individual brightness control, for scrolling messages, animations, and more - Scroll pHAT HD!

Scroll pHAT HD packs 17x7 pixels (119 total) onto a single pHAT, and gives you full PWM brightness control over each pixel. Create beautiful animations and even anti-aliased text by taking advantage of the per-pixel brightness.

Now also available in beautiful coloured versions: red, orange, yellow, green, blue, and pink!

Use Scroll pHAT HD as a scrolling message display for your tweets, the weather or the news, or use it as a 17-band spectrum analyser for your audio. There's even enough pixels for simple games like Tetris, Pong, or snake.

Features

  • 17x7 matrix of bright white, or coloured, pixels (119 total)
  • Individual PWM brightness control of each pixel
  • Uses the IS31FL3731 LED matrix driver chip
  • Scroll pHAT HD pinout
  • Compatible with Raspberry Pi 3B+, 3, 2, B+, A+, Zero, and Zero W
  • Python library
  • Female header requires soldering

Software

Our handy one-line installer will install the Scroll pHAT HD Python library for you. We've included a bunch of examples too, to show off what you can do with Scroll pHAT HD.

Our software does not support Raspbian Wheezy.

R219.90  Inc VAT
ws 4 Port USB HUB pHAT for Raspberry Pi Zero (3B3 USB hub phat)

This neat little 4 port USB hub pHAT for the Raspberry Pi B+/2/3 & Raspberry Pi Zero/W, provides 4 extra USB ports for your Pi and features a USB to UART converter for easy serial communication!

The board comes in a pHAT format and comes complete with micro USB cable, and Micro USB/Micro USB shim PCB. Raspberry Pi 3, Zero and dongle not included.

Please check image Point 3 below on how to connect the Hub to your chosen Raspberry Pi version.

Features

  • 4 USB Ports, compatible with USB2.0/1.1
  • Onboard USB to UART, convenient for Raspberry Pi serial debugging
  • Onboard multi indicators, for monitoring the status of power, USB to UART, and each USB port
  • Operating voltage: 5V
  • Dimension: 65mm × 30mm
  • Mounting hole size: 3.0mm

Assembly Instructions

  1. Raspberry Pi GPIO interface: for connecting Raspberry Pi
  2. USB to UART: for controlling the Raspberry Pi via serial terminal
  3. USB HUB interface (Micro USB): for connecting the HUB to the Raspberry Pi USB port
    1. Raspberry Pi Zero / Zero W: connected via Micro USB to Micro USB PCB
    2. Raspberry Pi B+ / 2B / 3B: connected via USB to Micro USB cable
  4. USB extended ports: USB1~USB4
  5. USB port indicators: dedicated indicator for each USB port, D1~D4 for USB1~USB4 respectively
  6. Power indicator
  7. USB to UART indicator
  8. FE1.1S: USB HUB chip
  9. 12MHz crystal
  10. CP2102: USB to UART converter

Development Resources

R109.90  Inc VAT
Four Letter pHAT (four letter phat)

Use Four Letter pHAT to display... four letter words. Not that sort!

Pi ZERO and case not included!

Four Letter pHAT has four 14-segment displays that you can use to display text, numbers, and a host of other characters. Its LEDs are a beautiful retro green, just like you old digital alarm clock. They're driven by the HT16K33 chip over I2C.

It's perfect as a readout for your projects, displaying temperatures, times, etc. and becomes really useful when combined with some of our other boards like Enviro pHAT or Explorer pHAT to display their sensor values.

Features

  • Four 14-segment displays with green LEDs
  • HT16K33 driver chip
  • Compatible with Raspberry Pi 3, 2, B+, A+, Zero, Zero W
  • Python library
  • Female header and display pins require soldering

Software

Our handy one-line installer will install the Four Letter pHAT Python library for you. We've included a bunch of examples too, to show off what you can do with Four Letter pHAT; things like a clock, a countdown timer, or CPU activity monitor.

Use Four Letter pHAT to display... four letter words. Not that sort!
R199.90  Inc VAT
Explorer pHAT (explorer phat)

Explorer pHAT is the perfect prototyping side-kick for your Raspberry Pi!

A more diminutive version of our popular Explorer Hat Pro, it's cheaper and designed to fit perfectly on a Raspberry Pi Zero!

We've added a heap of useful input and output options that will take your projects to the next level. Great for driving motors, using analog sensors, and interfacing with 5V systems (like Arduino).

Perfect for building a tiny robot, or use it to prototype all sorts of circuits with its LEDs, analog dials, and temperature sensor.

Features

  • Four buffered 5V tolerant inputs (perfect for Arduino compatibility)
  • Four powered 5V outputs (up to 500mA total across all four channels)
  • Four analog inputs
  • Two H-bridge motor drivers (up to 200mA per channel; soft PWM control)
  • Compatible with Raspberry Pi 3, 2, B+, A+, and Zero
  • Python library
  • Female headers require soldering

    Software

    Explorer pHAT uses the same easy-to-use Python library as Explorer HAT Pro, that includes a bunch of examples to demonstrate Explorer pHAT's functions.

    Notes

    The inputs use a 5-channel buffer that will accept anything from 2V-5V as logic high.

    Tutorials & Projects

    Explorer pHAT is the perfect prototyping side-kick for your Raspberry Pi!
    R199.90  Inc VAT
    PiStep2 Quad Stepper Motor Control Board for Raspberry Pi (3B2 PiStep2 stepper hat)

    This neat little board plugs directly into the Raspberry Pi GPIO header and provides 2 or 4 connectors for small stepper motors

    • Fully Assembled - No Soldering Required
    • Raspberry Pi Zero Form Factor - works with all versions of Raspberry Pi with 40pin GPIO connector
    • Stepper motors and Raspberry Pi not included

    Various Power Options:

    1. Powered from the Raspberry Pi 5V
    2. From the 2-pin Terminal (whatever voltage is required for the motors)
    3. Micro-USB - 5V only

    Pinout is simple:

    • Physical pins 11, 12, 13, 15 for Motor A (GPIO 17, 18, 27, 22)
    • Physical pins 16, 18, 22, 7 for Motor B (GPIO 23, 24, 25, 04)
    • Physical pins 33, 32, 31, 29 for Motor C (GPIO 13,12,6,5)
    • Physical Pins 38, 37, 36, 35 for Motor D (GPIO 20,26,16,19)

    Each pin has an associated white LED so you can see the stepper signals going through

    Power Supply Alternatives

    • Jumper VCC-VSTP (default). Power from the motors is taken from the Raspberry Pi 5V line
      • Micro-USB into Raspberry Pi. 5V for the Pi and the stepper motors goes through a poly-fuse which can trip if 2 motors are used simultaneously
      • Micro-USB into the PiStep board. 5V for both the Pi and the stepper motors is provided directly from the 5V USB input so no problems with 2 motors at once
    • Jumper VSTP-VIN. Power for the motors is provided from the 2-pin screw terminal, so can be any voltage that the steppers can handle. Ensure you use the correct polarity! We recommend to keep it below 12V. You will find that the stepper motors can go up to 9V and will be able to step faster, the higher the voltage that is applied, but there will be some deterioration of the life of the stepper motor at a higher voltage.

    Python Programming

    Please see the excellent example here for some pointers. You will need to change the pin numbers as above and also change the speed so it steps at a visible rate. You may also want to remove the print statements to speed it up. The lines in Red below are changed from the original to operate Motor A.

    # Use BCM GPIO references
    # instead of physical pin numbers
    GPIO.setmode(GPIO.BCM)

    # Define GPIO signals to use
    # Pins 18,22,24,26
    # GPIO24,GPIO25,GPIO8,GPIO7
    StepPins = [17,18,27,22]

    # Set all pins as output
    for pin in StepPins:
      print "Setup pins"
      GPIO.setup(pin,GPIO.OUT)
      GPIO.output(pin, False)

    # Define some settings
    StepCounter = 0
    WaitTime = 0.01

    ScratchGPIO Programming

    These pins are identical to those required by ScratchGPIO and therefore can easily be driven using simple Scratch commands:

    Set motor type for Scratch to be Stepper motor

    Set the position of the stepper motor A

    Set the speed of the stepper motor A

    This neat little board plugs directly into the Raspberry Pi GPIO header and provides 2 or 4 connectors for small stepper motors
    R299.90  Inc VAT
    Enviro+ for Raspberry Pi (3B3 enviro+ sensor phat)

    Monitor your world with Enviro+ for Raspberry Pi! There's a whole bunch of fancy environmental sensors on this board, and a gorgeous little full-colour LCD to display your data. It's the perfect way to get started with citizen science!

    Designed for environmental monitoring, Enviro+ lets you measure air quality (pollutant gases and particulates*), temperature, pressure, humidity, light, and noise level. When combined with a particulate matter sensor*, it's great for monitoring air quality just outside your house (more information below), or without the particulate sensor you can use it to monitor indoor conditions.

    Enviro+ is an affordable alternative to environmental monitoring stations that can cost tens of thousands of pounds and, best of all, it's small and hackable and lets you contribute your data to citizen science efforts to monitor air quality via projects like Luftdaten.

    Features

    • BME280 temperature, pressure, humidity sensor (datasheet)
    • LTR-559 light and proximity sensor (datasheet)
    • MICS6814 analog gas sensor (datasheet)
    • ADS1015 analog to digital converter (ADC) (datasheet)
    • MEMS microphone (datasheet)
    • 0.96" colour LCD (160x80)
    • Connector only for particulate matter (PM) sensor*(sensor is not included)
    • pHAT-format board
    • Fully-assembled
    • Compatible with all 40-pin header Raspberry Pi models
    • Pinout
    • Python library
    • Dimensions: 65x30x8.5mm

    A couple of nice little extras... there's a spare ADC channel broken out on a header if you want to connect another analog sensor, along with I2C pins in the right configuration for plugging one of our Pimoroni I2C breakouts onto!

    Citizen science air quality monitoring

    We've developed this board in collaboration with the University of Sheffield, with the aim of letting you contribute real-time air quality data from your local area to open data projects like Luftdaten.

    The alarming drop in our air quality is something that's really important to understand. Devices like Enviro+ allow fine-grained, detailed datasets that let us see shifts in air quality through time and across different areas of cities. The more devices that contribute data, the better quality the dataset becomes.

    Particulate matter (PM) is made up of tiny particles that are a mix of sizes and types, like dust, pollen, mould spores, smoke particles, organic particles and metal ions, and more. Particulates are much of what we think of as air pollution. They can be measured, in size and quantity, by particulate matter sensors like the PMS5003 that you can connect to Enviro+.

    The analog gas sensor can be used to make qualitative measurements of changes in gas concentrations, so you can tell broadly if the three groups of gases are increasing or decreasing in abundance. Without laboratory conditions or calibration, you won't be able to say "the concentration of carbon monoxide is n parts per million", for example.

    Temperature, air pressure and humidity can all affect particulate levels (and the gas sensor readings) too, so the BME280 sensor on Enviro+ is really important to understanding the other data that Enviro+ outputs.

    We've got a tutorial (coming soon) that shows you how to use Enviro+ and a few easily-available bits to build the board into a weather-proof housing that you can mount outside your house to monitor local air quality.

    Indoor monitoring

    As well as outdoor air quality monitoring, Enviro+ is really good for indoor monitoring too. The temperature, humidity, light, and noise readings can be used to keep track of conditions in your home and, combined with the LCD to display the data and the proximity sensor for interaction, it makes an ideal headless monitoring device.

    Why not combine it with some IoT smarts like an Alexa skill so that you can ask what the temperature or humidity is? Or you could set up a trigger action with IFTTT that turns your Philips Hue lights on when the light level drops below a certain level. There's loads of possibilities!

    Software

    We've put together a Python library to control all the parts of your Enviro+. There's a bunch of examples for each of the individual parts, an all-in-one example that shows you the data from Enviro+'s sensors in a visual way. There's also an example that shows you how to contribute data to Luftdaten (requires particulate matter sensor).

    Getting started

    Have a read through our (exhaustive!) Getting Started with Enviro+ tutorial that walks you through how to install the software, how to run the code examples, and how to use the Enviro+ Python library.

    R799.90  Inc VAT
    Touch pHAT (3B3 touch phat)

    Six touch-sensitive buttons to use for whatever your heart desires, with added LEDs (did you expect anything less?)

    Touch pHAT has six capacitive touch buttons, each with a bright white LED, designed to be completely agnostic about what they're used for. You can even use a dry erase pen to write on the pads to label their function.

    It uses the CAP1166 capacitive touch and LED driver chip. The LEDs have been under-mounted and shine through exposed sections of the PCB to give a pleasing yellow-green glow and a completely smooth top surface!

    Use Touch pHAT as a controller for your robot, a controller for your Mote lights, a tiny drum machine, or use it to build a simple game where you have to taps the buttons to repeat the sequence of lights that just flashed.

    Features

    • Six capacitive touch buttons
    • Six bright white under-mounted LEDs
    • Microchip CAP1166 capacitive touch and LED driver chip
    • Compatible with Raspberry Pi 3, 2, B+, A+, Zero, Zero W
    • Python library
    • Female header requires soldering

    Software

    Our handy one-line installer will install the Touch pHAT Python library for you. We've included a couple of examples too, to show off what you can do with Touch pHAT.

    Six touch-sensitive buttons to use for whatever your heart desires, with added LEDs (did you expect anything less?)
    R109.96  Inc VAT
    Unicorn pHAT (Unicorn pHAT)

    What's going to protect your beloved Raspberry Pi from an onslaught of rainbow-coloured fusion? That's right, it's Unicorn pHAT.

    Sporting a matrix of 32 (8 x 4) RGB LEDs and powered directly from the Pi, this is the most compact pocket aurora available.

    Unicorn pHAT provides a wash of controllable colour that is ideal for mood-lighting, pixel art, persistence of vision effects, status indications, or just blasting colour into your surroundings.

    Features

    • 32 RGB LEDs (SK6218 - 3.5mm x 3.5mm)
    • LED data driven via DMA over PWM
    • Unicorn pHAT pinout
    • Compatible with Raspberry Pi 3, 2, B+, A+, Zero, and Zero W
    • Python library
    • Female header requires soldering

    Software

    Unicorn pHAT uses the same Python library as Unicorn HAT, so it's super-easy to use, should automatically detect that you're using the pHAT and includes some examples written specially for Unicorn pHAT.

    Notes

    • Warning: SK6218 LEDs are bright enough to cause eye pain, do not look at them directly when brightly lit. We recommend using Unicorn pHAT at lower brightness levels.
    • Photo-sensitivity warning: flashing, strobing, and patterns of lights may cause epileptic seizures. Always take care and immediately stop using if you feel unwell (dizziness, nausea, affected vision, eye twitching, disorientation).
    • Power: Unicorn pHAT works best with a >2A microUSB power supply for your Pi. We recommend the official Raspberry Pi power supply.
    • Compatibility (audio): as Unicorn pHAT uses PWM and GPIO18, it will interfere with analogue audio playback (random colour patterns and flickering). HDMI should work just fine! :D

    Tutorials & Projects

    R179.90  Inc VAT
    Enc28j60 Network Adapter Module For Raspberry Pi Zero (3B4 zero ethernet board)
    Raspberry Pi Zero and cables are not included.

    Description:


    The Pi zero Enc28j60 is a simple Network Adapter module for Pi zero.
    It is very easy to assemble and configure.
    It allows your Raspberry Pi zero to access the network.

    Features:

    1. Easy to assemble and setup
    2. Official OS overlay support
    3. Stable and fast

    How to configure it:

    1. Install the NIC module into the raspberry Pi.
    2. Connect the network cable and ensure that your router supports DHCP.
    3.Burn the Raspbian image to TF card.
    4. Edit the /boot/config.txt file with your favorite editor such as "Nano" or "vim.tiny", and add the following parameter:
    dtoverlay=enc28j60
    Then save and exit. Reboot the raspberry Pi.

    NOTE: The module has been tested only in the Raspbian OS environment.

    How to check if network adapter works:

    Open a terminal and type this command: ifconfig

    Package includes:

    1x Pi zero Enc28j60 Network Adapter Module
    R259.90  Inc VAT
    Cluster HAT V2.2 Kit Including 4 x Raspberry Pi Zero & 4 x Sandisk 16GB micro SD (C26 Cluster hat V2.2 kit)

    New Updated V2.2 Cluster HAT! The Cluster HAT is the perfect tool for modelling, testing and teaching small scale clusters. The Cluster HAT is designed to interface a controller (Raspberry Pi A+/B+/2/3) with 4 Raspberry Pi Zero's configured to use USB gadget mode. It's an ideal tool for teaching, testing or simulating small scale clusters.

    This Kit Includes 1 x Cluster HAT, 4 x Raspberry Pi Zero's V1.3, 4 x 16GB Micro SD Cards.

    Please Note. A Raspberry Pi 3, with SD Card & Power Supply are also required for set up. These items are NOT Included in the Kit but can be purchased separately.

    The Cluster HAT Features:

    • Small Scale Cluster Simulator
    • The Cluster HAT can be used with any mix of Pi Zero 1.2, Pi Zero 1.3 and Pi Zero W.
    • USB Gadget Mode: Ethernet and Serial Console.
    • Onboard 4 port USB 2.0 hub.
    • Zeros (not included) are powered via Controller Pi GPIO
    • Individual Raspberry Pi Zero power controlled via Controller Pi GPIO
    • Connector for Controller Serial Console (FTDI Basic).
    • Controller Pi can be rebooted without interrupting power to Pi Zeros (network recovers on boot).
    Kit includes:
    • V2 Cluster HAT
    • HAT standoffs and screws
    • Short USB rope (colour may vary)
    • 4 x Raspberry Pi Zero v1.3
    • 4 x 16GB Class 10 Micro SD Cards

    The MagPi magazine review on the cluster hat V1

    Assembly & Software Setup Guide

    The cluster HAT V2.2 is an ideal tool for teaching, testing or simulating small scale clusters.
    R1,390.90  Inc VAT
    R1,491.49
    Per Page      1 - 20 of 24
