Got one of those teeny tiny, oh so shiny Raspberry Pi Zero's, and want to keep it safe?!
R89.00  Inc VAT
R169.00  Inc VAT
ModMyPi Pi Zero Case (MMP zero case laminated)

Got one of those teeny tiny, oh so shiny Raspberry Pi Zero's, and want to keep it safe?! Well, we're proud to introduce ModMyPi's new Pi Zero Case! Made with our trademark stealth-matte black acrylic, and accented with clear (to leave the good bits visible), the case itself is constructed of 4 layers. We've put the "ooh la la" back in lazoohlala cutting with this one, recessing the nuts and bolts to give a super sleek slim profile with no bumpy bits.

Newly updated for full compatibility with the Raspberry Pi Zero Camera cable!

ModMyPi's Pi Zero Case Features the Following:

  • GPIO access from the top & the bottom
  • SD card access
  • Recessed nuts & bolts keep the profile ultra slim
  • All ports accessible
  • Camera cable access port
  • Heat vents for SOC
  • Engraved port labels

Assembly Guide

Got one of those teeny tiny, oh so shiny Raspberry Pi Zero's, and want to keep it safe?!
R89.00  Inc VAT
Resistors (2K Ohm) (10 pack) (Resistor 2k)
Pic is for illustration purposes only

Resistors 1/4Watt 2K Ohm


Pack of 10
R5.00  Inc VAT
TEC1-12706 40x40mm Thermoelectric Cooler Peltier Plate 12V 60W (Peltier plate)

Description: Thermoelectric coolers (TEC or Peltier) create a temperature differential on each side. One side gets hot and the other side gets cool. Therefore, they can be used to either warm something up or cool something down, depending on which side you use. You can also take advantage of a temperature differential to generate electricity.

This Peltier works very well as long as you remove the heat from the hot side. After turning on the device, the hot side will heat quickly, the cold side will cool quickly. If you do not remove the heat from the hot side (with a heat sink or other device), the Peltier will quickly reach stasis and do nothing. We recommend using an old computer CPU heatsink or other block of metal to pull heat from the hot side. We were able to use a computer power supply and CPU heatsink to make the cold side so uncomfortably cold we could not hold our finger to it.

Note: It is imperative that a heat sink is used on the hot side of the module. Running the module without one can cause damage to this part. If it’s too hot to comfortably touch, you’re in the danger zone!

Features:

  • 40 x 40 x 3.6mm
  • lmax - 7A
  • Umax - 15.4V
  • Qcmax - 62.2W
  • Tmax - 69C
  • 1.7 Ohm resistance
  • 127 thermocouples
  • Max Operating Temp: 180°C
  • Min Operating Temp: -50°C

Documents:



Package includes:

  1 x cooler plate module(40mm x 40mm)

R74.10  Inc VAT
Ridiculous Resistor Kit 3 (995 Pieces) (C25 Resistor Kit 3 (995))
Resistors are used to restrict or limit the flow of current in a circuit, and they're often used to protect components such as LED's from damage. Our Rediculous Resitor Kit contains a total of 995 x 0.25W 5% Carbon Film Resistors!  Each 995 piece resistor Kit contains 63 unique values ranging from 4.7R to 10M, enough to keep any tinkerer fully stocked for a while!

The resistor Kit is separated into 8 packets, clearly marked with their contents and we've added in extra's of the more commonly used resistors (100 ohm, 10K, 47K 100K etc.), so you won't run out of them too quickly! All resistors are your standard Carbon Film '4-Band' 5% Precision Type Resistors (the small beige ones), and they're excellent for any small electronics projects, breadboarding, etc. Each pack has labelled contents, so you can easilly identify values on the go!

Technical Specification:
  • Wattage: 0.25W
  • Tolerance: ±5%
  • Maximum working voltage: 300V
  • Maximum overload voltage: 600V
  • Body dimensions (L xD): 6.3 x 2.3mm
  • Lead dimensions (H x D): 26 x 0.6mm
  • Temperature coefficient: 50ppm/°C
  • Temperature range: -65 to + 70°C
ModMyPi's Rediculous Resistor Kit Consists of the Following Resistor Quantities/Values:

10 x 4R710 x 150R15 x 1K230 x 10K15 x 68K25 x 470K
10 x 10R15 x 180R15 x 1K515 x 12K10 x 82K10 x 560K
10 x 15R20 x 220R10 x 1K815 x 15K30 x 100K10 x 680K
10 x 22R20 x 270R25 x 2K215 x 18K20 x 120K5 x 820K
10 x 33R20 x 330R20 x 2K720 x 22K15 x 150K20 x 1M
20 x 47R10 x 390R20 x 3K315 x 27K15 x 180K10 x 2M2
10 x 56R30 x 470R15 x 3K920 x 33K20 x 220K5 x 3M3
10 x 68R20 x 560R25 x 4K710 x 39K15 x 270K10 x 4M7
10 x 82R20 x 680R20 x 5K630 x 47K15 x 330K5 x 6M8
20 x 100R10 x 820R15 x 6K820 x 56K10 x 390K20 x 10M
10 x 120R30 x 1K10 x 8K2



Tutorials

How to Calculate a Resistor for a Simple LED Circuit

R185.00  Inc VAT
Resistor Kit 2 (500Pcs) (C25 Resistor Kit 2(500))

A great kit of 500 resistors with a range of the most used values!  All resistors are stapled into a tri-fold pack and clearly labeled. The back of the resistor kit even has a resistor color code look-up chart and a table of color codes for the included resistors! You'll never find a project put on hold for need of a resistor.

The Mini Resistor Kit Features:

25 of Each Type (Ω):

0 , 1.5 , 4.7 , 10 , 47, 100 , 220 , 330 , 470 , 680, 1k , 2.2k , 3.3k , 4.7k , 10k, 22k , 47k , 100k , 330k , 1M

Technical Specification:
  • Carbon Film
  • Wattage: 0.25W
  • Tolerance: ±5%
R169.00  Inc VAT
