Products meeting the search criteria
AlphaBot2-PiZero Acce Pack requires the controller Raspberry Pi Zero/Zero W /Zero WH if you don't have one in hand please use the links to add them to your order. Batteries are not included.
Overview
This AlphaBot2 robot kit is designed to use with Raspberry Pi Zero/Zero W (not included). It features rich common robot functions including line tracking, obstacle avoiding, ultrasonic ranging, Bluetooth/infrared/WiFi remote control (Bluetooth and WiFi are Zero W specific), video monitoring, etc.
Thanks to the highly integrated modular design, it is fairly easy to assemble by a snap, no soldering, no wiring. After a few minutes spent on hardware assembling, you're almost there, our open source demo codes is ready to help you get started fast.
AlphaBot2 Features
AlphaBot2 employs a 2-layer structure to provide excellent stability and compatibility.
AlphaBot2-Base, the lower base chassis:
- 5-ch infrared sensor, analog output, combined with PID algorithm, stable line tracking
- Onboard modules like line tracking, obstacle avoiding, needs no messy wiring
- TB6612FNG dual H-bridge motor driver, compared with L298P, it's more efficient, more compact, and less heating
- N20 micro gear motor, with metal gears, low noise, high accuracy
- Onboard RGB LEDs, true color lighting, pretty cool
AlphaBot2-PiZero, the upper adapter board for controller:
- LM2596 voltage regulator, provides the Pi with stable 5V power
- TLC1543 AD acquisition chip, allows the Pi to use analog sensors
- PCA9685 servo controller, make it more smoothly to rotate the pan head
- CP2102 UART converter, easy for controlling the Pi via UART
- USB HUB chip, more USB ports for devices like NIC
What's on the AlphaBot2-Base
- AlphaBot2 control interface: for connecting sorts of controller adapter board
- Ultrasonic module interface
- Obstacle avoiding indicators
- Omni-direction wheel
- ST188: reflective infrared photoelectric sensor, for obstacle avoiding
- ITR20001/T: reflective infrared photoelectric sensor, for line tracking
- Potentiometer for adjusting obstacle avoiding range
- TB6612FNG dual H-bridge motor driver
- LM393 voltage comparator
- N20 micro gear motor reduction rate 1:30, 6V/600RPM
- Rubber wheels diameter 42mm, width 19mm
- Power switch
- Battery holder: supports 14500 batteries
- WS2812B: true color RGB LEDs
- Power indicator
What's on the AlphaBot2-PiZero
- AlphaBot2 control interface: for connecting AlphaBot2-Base
- LM2596: 5V voltage regulator
- Raspberry Pi interface: for connecting Raspberry Pi Zero/Zero W
- IR receiver
- Buzzer
- FE1.1S: USB HUB chip
- 12M crystal
- USB TO UART: easy for controlling the Pi via UART
- USB HUB interface: extends the USB port of Raspberry Pi Zero/Zero W
- CP2102: USB TO UART converter
- PCA9685: servo controller, make it more smoothly to rotate the pan head
- TLC1543: 10-bit AD acquisition chip, allows the Pi to use analog sensors
- Servo interface
- USB indicators
- USB ports: more USB capability
Examples
AlphaBot2 multi robots line following
AlphaBot2-PiZero robot obstacle avoiding
AlphaBot2-PiZero robot RGB LED remote control
AlphaBot2-PiZero robot video monitor
AlphaBot2-PiZero robot Bluetooth control
Development Resources
Wiki : www.waveshare.com/wiki/AlphaBot2-PiZero
Note: this product requires two 14500 batteries to work, which are NOT included and should be purchased separately. Even though the battery holder fits the normal AA batteries DO NOT USE THEM! A 14500 lithium cell is identical in shape and size to a standard AA battery. But that is where the similarities end. AA supplies 1.5V each where 14500 supply 3.7V each.
Package Includes:
- AlphaBot2-PiZero (adapter board) x1
- AlphaBot2-Base (base chassis) x1
- RPi Camera (B) x1
- Ultrasonic sensor
- Micro SD Card 16GB x1
- Power adapter US standard 5V/2.5A USB output x1
- SG90 servo x2
- 2 DOF pan and tilt kit x1
- IR remote controller x1
- FC-20P cable 8cm x1
- Micro USB connector x1
- RPi Zero V1.3 Camera Cable 30cm x1
- USB type A plug to micro B plug cable x1
- AlphaBot2-PiZero screws x1
- Micro SD Card Reader x1
- Screwdriver x1
Note: Raspberry Pi 3 is NOT included. Batteries are not included
Overview
This AlphaBot2 robot kit is designed to use with Raspberry Pi 3 Model B (not included). It features rich common robot functions including line tracking, obstacle avoiding, Bluetooth/infrared/WiFi remote control, video monitoring, etc.
Thanks to the highly integrated modular design, it is fairly easy to assemble by a snap, no soldering, no wiring. After a few minutes spent on hardware assembling, you're almost there, our open source demo codes is ready to help you get started fast.
AlphaBot2 Features
AlphaBot2 employs a 2-layer structure to provide excellent stability and compatibility.
AlphaBot2-Base, the lower base chassis:
- 5-ch infrared sensor, analog output, combined with PID algorithm, stable line tracking
- Onboard modules like line tracking, obstacle avoiding, needs no messy wiring
- TB6612FNG dual H-bridge motor driver, compared with L298P, it's more efficient, more compact, and less heating
- N20 micro gear motor, with metal gears, low noise, high accuracy
- Onboard RGB LEDs, true color lighting, pretty cool
AlphaBot2-Pi, the upper adapter board for controller:
- LM2596 voltage regulator, provides the Pi with stable 5V power
- TLC1543 AD acquisition chip, allows the Pi to use analog sensors
- PCA9685 servo controller, make it more smoothly to rotate the pan head
- CP2102 UART converter, easy for controlling the Pi via UART
What's on the AlphaBot2-Base
- AlphaBot2 control interface: for connecting sorts of controller adapter board
- Ultrasonic module interface
- Obstacle avoiding indicators
- Omni-direction wheel
- ST188: reflective infrared photoelectric sensor, for obstacle avoiding
- ITR20001/T: reflective infrared photoelectric sensor, for line tracking
- Potentiometer for adjusting obstacle avoiding range
- TB6612FNG dual H-bridge motor driver
- LM393 voltage comparator
- N20 micro gear motor reduction rate 1:30, 6V/600RPM
- Rubber wheels diameter 42mm, width 19mm
- Power switch
- Battery holder: supports 14500 batteries
- WS2812B: true color RGB LEDs
- Power indicator
What's on the AlphaBot2-Pi
- AlphaBot2 control interface: for connecting AlphaBot2-Base
- Raspberry Pi interface: for connecting Raspberry Pi 3 Model B
- Servo interface
- USB TO UART: easy for controlling the Pi via UART
- LM2596: 5V voltage regulator
- TLC1543: 10-bit AD acquisition chip, allows the Pi to use analog sensors
- PCA9685: servo controller, make it more smoothly to rotate the pan head
- CP2102: USB TO UART converter
- Joystick
- IR receiver
- Buzzer
Examples
AlphaBot2 multi robots line following
AlphaBot2-Pi robot obstacle avoiding
AlphaBot2-Pi robot RGB LED remote control
AlphaBot2-Pi robot video monitor
AlphaBot2-Pi robot Bluetooth control
Development Resources
Wiki : www.waveshare.com/wiki/AlphaBot2-Pi
Package Includes:
Note: this product requires two 14500 batteries to work, which are NOT included and should be purchased separately. Even though the battery holder fits the normal AA batteries DO NOT USE THEM! A 14500 lithium cell is identical in shape and size to a standard AA battery. But that is where the similarities end. AA supplies 1.5V each where 14500 supply 3.7V each.
- AlphaBot2-Pi (adapter board) x1
- AlphaBot2-Base (base chassis) x1
- RPi Camera (B) x1
- Micro SD Card 16GB x1
- Power adapter US standard 5V/2.5A USB output x1
- SG90 servo x2
- 2 DOF pan and tilt kit x1
- IR remote controller x1
- FC-20P cable 8cm x1
- USB type A plug to micro B plug cable x1
- 15PIN FFC 25cm x1
- AlphaBot2-Pi screws x1
- Micro SD Card Reader x1
- Screwdriver x1
The dual-band wireless LAN comes with modular compliance certification, allowing the board to be designed into end products with significantly reduced wireless LAN compliance testing, improving both cost and time to market. The Raspberry Pi 3 Model B+ maintains the same mechanical footprint as both the Raspberry Pi 2 Model B and the Raspberry Pi 3 Model B.
We only stock UK made Raspberry Pi's manufactured in Sony's Pencoed factory in South Wales.
Please Note. It is recommended to use a 2.5A Power Supply with the Raspberry Pi 3 B+.
Specifications
- Processor
- Broadcom BCM2387B0 chipset.
- 1.4GHz Quad-Core ARM Cortex-A53 (64Bit)
- Connectivity
- 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2, BLE
- Gigabit Ethernet over USB 2.0 (maximum throughput 300Mbps)
- 4 × USB 2.0 ports
- GPU
- Dual Core VideoCore IV® Multimedia Co-Processor. Provides Open GL ES 2.0, hardware-accelerated OpenVG, and 1080p30 H.264 high-profile decode.
- Capable of 1Gpixel/s, 1.5Gtexel/s or 24GFLOPs with texture filtering and DMA infrastructure
- Memory
- 1GB LPDDR2
- Operating System
- Boots from Micro SD card, running a version of the Linux operating system or Windows 10 IoT
- Dimensions
- 85 x 56 x 17mm
- Power
- 5V/2.5A DC via micro USB connector
- 5V DC via GPIO header
- Power over Ethernet (PoE) enabled (requires separate PoE HAT)
Connectors
- Ethernet
- 10/100 BaseT Ethernet socket
- Video Output
- HDMI (rev 1.3 & 1.4)
- Composite RCA (PAL and NTSC)
- Audio Output
- Audio Output 3.5mm jack
- HDMI
- USB 4 x USB 2.0 Connector
- GPIO Connector
- 40-pin 2.54 mm (100 mil) expansion header: 2x20 strip
- Providing 27 GPIO pins as well as +3.3 V, +5 V and GND supply lines
- Camera Connector
- 15-pin MIPI Camera Serial Interface (CSI-2)
- Display Connector
- Display Serial Interface (DSI) 15 way flat flex cable connector with two data lanes and a clock lane
- Memory Card Slot
- Push/pull Micro SDIO
The Raspberry Pi 3 Model B+ will remain in production
until at least January 2023.
WARNINGS
- This product should only be connected to an external power supply rated at 5V/2.5 A DC. Any external power supply used with the Raspberry Pi 3 Model B+ shall comply with relevant regulations and standards applicable in the country of intended use.
- This product should be operated in a well-ventilated environment and, if used inside a case, the case should not be covered.
- Whilst in use, this product should be placed on a stable, flat, non-conductive surface and should not be contacted by conductive items.
- The connection of incompatible devices to the GPIO connection may affect compliance, result in damage to the unit, and invalidate the warranty.
- All peripherals used with this product should comply with relevant standards for the country of use and be marked accordingly to ensure that safety and performance requirements are met. These articles include but are not limited to keyboards, monitors, and mice when used in conjunction with the Raspberry Pi.
- The cables and connectors of all peripherals used with this product must have adequate insulation so that relevant safety requirements are met.
To avoid malfunction of or damage to this product, please observe the following:
- Do not expose to water or moisture, or place on a conductive surface whilst in operation.
- Do not expose to heat from any source; the Raspberry Pi 3 Model B+ is designed for reliable operation at normal ambient temperatures.
- Take care whilst handling to avoid mechanical or electrical damage to the printed circuit board and connectors.
- Whilst it is powered, avoid handling the printed circuit board, or only handle it by the edges to minimize the risk of electrostatic discharge damage.
Getting Started with Raspberry Pi
The Raspberry Pi 3 Model A+ is the latest product in the Raspberry Pi 3 range. Like the Raspberry Pi 3 Model B+, it boasts a 64-bit quad core processor running at 1.4 GHz, dual-band 2.4 GHz and 5 GHz wireless LAN, and Bluetooth 4.2/BLE. The dual-band wireless LAN comes with modular compliance certification, allowing the board to be designed into end products with significantly reduced wireless LAN compliance testing, improving both cost and time to market.
The Raspberry Pi 3 Model A+ features 512mb SDRAM (over the Pi 3 B+'s 1GB), has no Ethernet port or function, and includes only one USB port. The Raspberry Pi 3 Model A+ has the same mechanical footprint as the Raspberry Pi 1 Model A+.
Please Note. It is recommended to use a 2.5A Power Supply with the Raspberry Pi 3A+. This purchase is for the Raspberry Pi 3 Model A+ Board only.
Specifications
- Processor
- Broadcom BCM2837B0 chipset.
- 1.4GHz Quad-Core ARM Cortex-A53 (64Bit)
- Connectivity
- 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2, BLE
- 1 × USB 2.0 ports
- GPU
- Dual Core VideoCore IV® Multimedia Co-Processor. Provides Open GL ES 2.0, hardware-accelerated OpenVG, and 1080p30 H.264 high-profile decode.
- Capable of 1Gpixel/s, 1.5Gtexel/s or 24GFLOPs with texture filtering and DMA infrastructure
- Memory
- 512mb LPDDR2
- Operating System
- Boots from Micro SD card, running a version of the Linux operating system or Windows 10 IoT
- Dimensions
- 65 x 56 x 8.5mm
- Power
- 5V/2.5A DC via Micro USB Connector
- 5V DC via GPIO Header
Connectors
- Video Output
- HDMI (rev 1.3 & 1.4)
- Composite RCA (PAL and NTSC)
- Audio Output
- Audio Output 3.5mm jack
- HDMI
- USB 1 x USB 2.0 Connector
- GPIO Connector
- 40-pin 2.54 mm (100 mil) expansion header: 2x20 strip
- Providing 27 GPIO pins as well as +3.3 V, +5 V and GND supply lines
- Camera Connector
- 15-pin MIPI Camera Serial Interface (CSI-2)
- Display Connector
- Display Serial Interface (DSI) 15 way flat flex cable connector with two data lanes and a clock lane
- Memory Card Slot
- Push/Pull Micro SDIO
Getting Started with Raspberry Pi
The Official Raspberry Pi Keyboard is finally here!
This sleek and stylish keyboard from the team at Raspberry Pi includes three in-built USB 2.0 type-A ports for powering other peripherals (such as the official Raspberry Pi mouse)!
Please Note. This keyboard is available in 6 language formats: UK, US, DE, FR, ES & IT. This model is the US version as used in South Africa.
Keyboard Specification:
- 79-key keyboard (78-key US keyboard)
- 3 USB 2.0 type-A ports for powering other peripherals
- Automatic keyboard language detection
- USB type-A to micro USB type-B cable for connection
- Compatible with all Raspberry Pi products
- Ergonomic design for comfortable use
- Available in Red/White and Black/Grey
The Official Raspberry Pi Mouse is finally here!
This sleek, stylish and ergonomic mouse from the team at Raspberry Pi includes three buttons, two main ones for right and left click, and a scroll wheel with button for scrolling. . . and more clicking. . . what more do you need from a mouse!
Mouse Specification:
- Three-button optical mouse
- Scroll wheel
- USB type-A connector
- Compatible with all Raspberry Pi products
- Ergonomic design for comfortable use
- Available in Red/White and Black/Grey
The Official Raspberry Pi Mouse is finally here!
This sleek, stylish and ergonomic mouse from the team at Raspberry Pi includes three buttons, two main ones for right and left click, and a scroll wheel with button for scrolling. . . and more clicking. . . what more do you need from a mouse!
Mouse Specification:
- Three-button optical mouse
- Scroll wheel
- USB type-A connector
- Compatible with all Raspberry Pi products
- Ergonomic design for comfortable use
- Available in Black/Grey and Red/White
The Official Raspberry Pi Keyboard is finally here!
This sleek and stylish keyboard from the team at Raspberry Pi includes three in-built USB 2.0 type-A ports for powering other peripherals (such as the official Raspberry Pi mouse)!
Please Note. This keyboard is available in 6 language formats: UK, US, DE, FR, ES & IT. This model is the US version as used in South Africa.
Keyboard Specification:
- 79-key keyboard (78-key US keyboard)
- 3 USB 2.0 type-A ports for powering other peripherals
- Automatic keyboard language detection
- USB type-A to micro USB type-B cable for connection
- Compatible with all Raspberry Pi products
- Ergonomic design for comfortable use
- Available in Red/White and Black/Grey
Get started with the Raspberry Pi with one of our pre-boxed kits
These kits are perfect for beginners that are just just getting exposed to the Raspberry Pi, Media enthusiasts looking to stream online content with Kodi, developers looking to exploit the many advantages of the RPI's GPIO pins and anybody looking to get some cool goodies at a great price! They contain all of the essential items that you need to get up and running in no time.
Please Note: These kits are pre-boxed and cannot be modified at all, we do however keep stock on all of the individual items so if you have a special need simply feel free to browse through the rest of our product offerings and select the items that you'd like.
The kit comes equipped with:
- The Iconic Raspberry Pi 3 Model B+
- 32 GB Micro SD card with the latest version of NOOBS pre-installed
- 3 piece Heat Sink
- Cooling Fan
- 5V 2.5A Switch Power Adapter
- 1M HDMI Cable
- micro SD card reader
- NESPi CASE + mini Screwdriver
- 2 x Retro Gamepads
Perfect for use with RetroPie - https://retropie.org.uk/
Want to take your kit to the next level?
Turn your RPI into a Media Centre
Grab yourself a remote control, select LibreELEC or OSMC when setting up your RPI and you'll be streaming in no time. You can even add a wireless keyboard, mouse or other similar controllers
Want a cheap eco-friendly PC
Grab a Keyboard and Mouse, select Raspbian when setting up your RPI and you'll be browsing the web, sending emails, editing spreadsheets and watching videos just like you're used to with a desktop/laptop.
We know you love retro gaming!
Check out our Arcade section, whether you just want a retro control or a mini DIY arcade cabinet we have what you're looking for.
Did somebody say Robotics?
We've got some cool beginner's items in our robotic section
Our Kits come with the latest version of NOOBS – New Out Of the Box Software pre-installed, While we will certainly try our best to assist with any software related questions we cannot offer any kind of official support on community driven, open source, or non-PiShop produced proprietary software.
NOOBS, Raspbian, RetroPie, LibreELEC and OSMC are all open-source software, please visit the developer's respective websites for more info.
So what is NOOBS anyway?In Short, NOOBS is an installer, when you switch your RPI on NOOBS will guide you through the installation of your software of choice... seem confusing? Don't worry it really couldn't be easier
- Raspbian - a full desktop for normal day to day work. Email, internet, office suite, programming etc.
- LibreELEC RPi2 - our preferred version of Kodi for use as a media centre.
- OSMC Pi2 - for more control of your Kodi media centre
- Windows 10 IoT Core - nope this is not windows 10. It simply enables you to run projects and apps for the IOT environment.
- RetroPie, Lakka and Recalbox - retro gaming for the RPi.
A whole bunch of other really cool technical info can be found here.
Getting Started with Raspberry Pi
- Allows four different angles of repose.
- Four Screws to secure your camera
- Made from black acrylic
- hole for tripod mounting.
Compatible with the Raspberry Pi Camera Module V2 and NoIR Camera V2 “night vision”
We created this Alphabot Pi3B+ bundle to make shopping easier. View the list at the bottom of the description to view the contents of this bundle.
Overview
This AlphaBot2 robot kit is designed to use with Raspberry Pi 3 Model B+. It features rich common robot functions including line tracking, obstacle avoiding, Bluetooth/infrared/WiFi remote control, video monitoring, etc.
Thanks to the highly integrated modular design, it is fairly easy to assemble by a snap, no soldering, no wiring. After a few minutes spent on hardware assembling, you're almost there, our open source demo codes is ready to help you get started fast.
AlphaBot2 Features
AlphaBot2 employs a 2-layer structure to provide excellent stability and compatibility.
AlphaBot2-Base, the lower base chassis:
- 5-ch infrared sensor, analog output, combined with PID algorithm, stable line tracking
- Onboard modules like line tracking, obstacle avoiding, needs no messy wiring
- TB6612FNG dual H-bridge motor driver, compared with L298P, it's more efficient, more compact, and less heating
- N20 micro gear motor, with metal gears, low noise, high accuracy
- Onboard RGB LEDs, true color lighting, pretty cool
AlphaBot2-Pi, the upper adapter board for controller:
- LM2596 voltage regulator, provides the Pi with stable 5V power
- TLC1543 AD acquisition chip, allows the Pi to use analog sensors
- PCA9685 servo controller, make it more smoothly to rotate the pan head
- CP2102 UART converter, easy for controlling the Pi via UART
What's on the AlphaBot2-Base
- AlphaBot2 control interface: for connecting sorts of controller adapter board
- Ultrasonic module interface
- Obstacle avoiding indicators
- Omni-direction wheel
- ST188: reflective infrared photoelectric sensor, for obstacle avoiding
- ITR20001/T: reflective infrared photoelectric sensor, for line tracking
- Potentiometer for adjusting obstacle avoiding range
- TB6612FNG dual H-bridge motor driver
- LM393 voltage comparator
- N20 micro gear motor reduction rate 1:30, 6V/600RPM
- Rubber wheels diameter 42mm, width 19mm
- Power switch
- Battery holder: supports 14500 batteries
- WS2812B: true color RGB LEDs
- Power indicator
What's on the AlphaBot2-Pi
- AlphaBot2 control interface: for connecting AlphaBot2-Base
- Raspberry Pi interface: for connecting Raspberry Pi 3 Model B
- Servo interface
- USB TO UART: easy for controlling the Pi via UART
- LM2596: 5V voltage regulator
- TLC1543: 10-bit AD acquisition chip, allows the Pi to use analog sensors
- PCA9685: servo controller, make it more smoothly to rotate the pan head
- CP2102: USB TO UART converter
- Joystick
- IR receiver
- Buzzer
Examples
AlphaBot2 multi robots line following
AlphaBot2-Pi robot obstacle avoiding
AlphaBot2-Pi robot RGB LED remote control
AlphaBot2-Pi robot video monitor
AlphaBot2-Pi robot Bluetooth control
Development Resources
Wiki : www.waveshare.com/wiki/AlphaBot2-Pi
The Alphabot Essentials Bundle Includes:
Note: this product uses two 14500 batteries to work. Even though the battery holder fits the normal AA batteries - DO NOT USE THEM! A 14500 lithium cell is identical in shape and size to a standard AA battery. But that is where the similarities end. AA supplies 1.5V each where 14500 supply 3.7V each.
- AlphaBot2-Pi (adapter board) x1
- AlphaBot2-Base (base chassis) x1
- RPi Camera (B) x1
- Micro SD Card 16GB x1
- Power adapter US standard 5V/2.5A USB output x1
- SG90 servo x2
- 2 DOF pan and tilt kit x1
- IR remote controller x1
- FC-20P cable 8cm x1
- USB type A plug to micro B plug cable x1
- 15PIN FFC 25cm x1
- AlphaBot2-Pi screws x1
- Micro SD Card Reader x1
- Screwdriver x1
- Raspberry Pi 3 model B
- 4x Rechargeable 14500 Li-ion Batteries
- Liitokala Lii-402 Battery Charger
- HDMI 1.8m flat noodle cable
- HC-SR04 Ultrasonic Sensor
The New GoPiGo3 Raspberry Pi Robot from Dexter Industries has landed at ModMyPi! The GoPiGo3 Base Kit is perfect if you already have a Raspberry Pi and want to get it moving. It includes the GoPiGo3 board, chassis, wheels, motors, encoders, and power battery pack. Visit the GoPiGo Product Support & Documentation page for step-by-step tutorials, technical specs, detailed product pictures, and sample code libraries.
The GoPiGo is a complete Raspberry Pi Robot Car. With so many programming languages and USB accessories available for the Pi, you can turn your GoPiGo into anything from a wifi controlled robot for exploring the scary spaces behind the couch to an autonomous rocket launching office enforcer. With the Raspberry Pi acting as the brains of the robot, the possibilities are infinite..
Features:
- Works with the Raspberry Pi Model A, A+, B, B+/2/3
- Powered by 8 AA batteries (not included)
- Software examples and API are provided by Dexter Industries.
- Kit takes less than 20 minutes to assemble.
- GoPiGo is compatible with Lego Technic parts.
What’s included?
- GoPiGo3 board (red board)
- Chassis (frame, wheels, hardware)
- Motors
- Encoders
- Power battery pack & cable (batteries not included)
- Scredriver for assembly
What’s not included? (But Required)
- 8AA Batteries
- Power Supply
- Ethernet Cable
- Raspberry Pi (we recommend the 3, but any version will work)
- microSD Card with Dexter Industries “Raspbian for Robots” software
- Computer, or a monitor, mouse, & keyboard for programming
- Recommended: Distance Sensor
- Recommended: 8GB Drive for Software Upgrades & Storing Photo's & Files
Example Projects
Raspberry Pi 4 Model B is the latest product in the popular Raspberry Pi range of computers. It offers ground-breaking increases in processor speed, multimedia performance, memory, and connectivity compared to the prior-generation Raspberry Pi 3 Model B+, while retaining backwards compatibility and similar power consumption. For the end user, Raspberry Pi 4 Model B provides desktop performance comparable to entry-level x86 PC systems.
This product’s key features include a high-performance 64-bit quad-core processor, dual-display support at resolutions up to 4K via a pair of micro-HDMI ports, hardware video decode at up to 4Kp60, up to 4GB of RAM, dual-band 2.4/5.0 GHz wireless LAN, Bluetooth 5.0, Gigabit Ethernet, USB 3.0, and PoE capability (via a separate PoE HAT add-on).
The dual-band wireless LAN and Bluetooth have modular compliance certification, allowing the board to be designed into end products with significantly reduced compliance testing, improving both cost and time to market.
Specifications
- Processor: Broadcom BCM2711, quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz
- Memory: 1GB, 2GB or 4GB LPDDR4 (depending on model)
- Connectivity: 2.4 GHz and 5.0 GHz IEEE 802.11b/g/n/ac wireless
- LAN, Bluetooth 5.0, BLE Gigabit Ethernet, 2 × USB 3.0 ports, 2 × USB 2.0 ports.
- GPIO: Standard 40-pin GPIO header (fully backwards-compatible with previous boards)
- Video & sound: 2 × micro HDMI ports (up to 4Kp60 supported), 2-lane MIPI DSI display port, 2-lane MIPI CSI camera port, 4-pole stereo audio and composite video port
- Multimedia: H.265 (4Kp60 decode); H.264 (1080p60 decode, 1080p30 encode); OpenGL ES, 3.0 graphics
- SD card support: Micro SD card slot for loading operating system and data storage
- Input power: 5V DC via USB-C connector (minimum 3A1), 5V DC via GPIO header (minimum 3A1)
- Power over Ethernet (PoE)–enabled (requires separate PoE HAT)
- Environment: Operating temperature 0–50oC
- Compliance: For a full list of local and regional product approvals, please visit https://www.raspberrypi.org/documentation/hardware/raspberrypi/conformity.md
- Production lifetime: The Raspberry Pi 4 Model B will remain in production until at least January 2026.
If you new Raspberry Pi 4 is not displaying anything, but is booting:
Please change the following settings in the /boot/config.txt setting. You can access these settings in a few ways.
1. Using another display to access the file: sudo nano /boot/config.txt
2. Insert the SD card into a computer/laptop and open the boot partition
Uncomment and change or add to the bottom of the file:
hdmi_safe=1
hdmi_force_hotplug=1
hdmi_ignore_edid=0xa5000080
hdmi_group=2
hdmi_mode=81 (or 39 this will depend on the type of display)
config_hdmi_boost=9
dtoverlay=vc4-fkms-v3d
max_framebuffers=2
Not all of these settings may be necessary, this will again depend on your type of display, however adding them all and removing one by one will help find the ones you may need.
WARNINGS
• This product should only be connected to an external power supply rated at 5V/3A DC or 5.1V/ 3A DC minimum. A good quality 2.5A power supply can be used if downstream USB peripherals consume less than 500mA in total. Any external power supply used with the Raspberry Pi 4 Model B shall comply with relevant regulations and standards applicable in the country of intended use.
• This product should be operated in a well-ventilated environment and, if used inside a case, the case should not be covered.
• This product should be placed on a stable, flat, non-conductive surface in use and should not be contacted by conductive items.
• The connection of incompatible devices to the GPIO connection may affect compliance and result in damage to the unit and invalidate the warranty.
• All peripherals used with this product should comply with relevant standards for the country of use and be marked accordingly to ensure that safety and performance requirements are met. These articles include but are not limited to keyboards, monitors and mice when used in conjunction with the Raspberry Pi.
• Where peripherals are connected that do not include the cable or connector, the cable or connector must offer adequate insulation and operation in order that the relevant performance and safety requirements are met.
SAFETY INSTRUCTIONS
To avoid malfunction or damage to this product please observe the following:
• Do not expose to water, moisture or place on a conductive surface whilst in operation.
• Do not expose it to heat from any source; Raspberry Pi 4 Model B is designed for reliable operation at normal ambient room temperatures.
• Take care whilst handling to avoid mechanical or electrical damage to the printed circuit board and connectors.
• Avoid handling the printed circuit board whilst it is powered and only handle by the edges to minimise the risk of electrostatic discharge damage.
Raspberry Pi 4 Model B is the latest product in the popular Raspberry Pi range of computers. It offers ground-breaking increases in processor speed, multimedia performance, memory, and connectivity compared to the prior-generation Raspberry Pi 3 Model B+, while retaining backwards compatibility and similar power consumption. For the end user, Raspberry Pi 4 Model B provides desktop performance comparable to entry-level x86 PC systems.
This product’s key features include a high-performance 64-bit quad-core processor, dual-display support at resolutions up to 4K via a pair of micro-HDMI ports, hardware video decode at up to 4Kp60, up to 4GB of RAM, dual-band 2.4/5.0 GHz wireless LAN, Bluetooth 5.0, Gigabit Ethernet, USB 3.0, and PoE capability (via a separate PoE HAT add-on).
The dual-band wireless LAN and Bluetooth have modular compliance certification, allowing the board to be designed into end products with significantly reduced compliance testing, improving both cost and time to market.
Specifications
- Processor: Broadcom BCM2711, quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz
- Memory: 1GB, 2GB or 4GB LPDDR4 (depending on model)
- Connectivity: 2.4 GHz and 5.0 GHz IEEE 802.11b/g/n/ac wireless
- LAN, Bluetooth 5.0, BLE Gigabit Ethernet, 2 × USB 3.0 ports, 2 × USB 2.0 ports.
- GPIO: Standard 40-pin GPIO header (fully backwards-compatible with previous boards)
- Video & sound: 2 × micro HDMI ports (up to 4Kp60 supported), 2-lane MIPI DSI display port, 2-lane MIPI CSI camera port, 4-pole stereo audio and composite video port
- Multimedia: H.265 (4Kp60 decode); H.264 (1080p60 decode, 1080p30 encode); OpenGL ES, 3.0 graphics
- SD card support: Micro SD card slot for loading operating system and data storage
- Input power: 5V DC via USB-C connector (minimum 3A1), 5V DC via GPIO header (minimum 3A1)
- Power over Ethernet (PoE)–enabled (requires separate PoE HAT)
- Environment: Operating temperature 0–50oC
- Compliance: For a full list of local and regional product approvals, please visit https://www.raspberrypi.org/documentation/hardware/raspberrypi/conformity.md
- Production lifetime: The Raspberry Pi 4 Model B will remain in production until at least January 2026.
If you new Raspberry Pi 4 is not displaying anything, but is booting:
Please change the following settings in the /boot/config.txt setting. You can access these settings in a few ways.
1. Using another display to access the file: sudo nano /boot/config.txt
2. Insert the SD card into a computer/laptop and open the boot partition
Uncomment and change or add to the bottom of the file:
hdmi_safe=1
hdmi_force_hotplug=1
hdmi_ignore_edid=0xa5000080
hdmi_group=2
hdmi_mode=81 (or 39 this will depend on the type of display)
config_hdmi_boost=9
dtoverlay=vc4-fkms-v3d
max_framebuffers=2
Not all of these settings may be necessary, this will again depend on your type of display, however adding them all and removing one by one will help find the ones you may need.
WARNINGS
• This product should only be connected to an external power supply rated at 5V/3A DC or 5.1V/ 3A DC minimum. A good quality 2.5A power supply can be used if downstream USB peripherals consume less than 500mA in total. Any external power supply used with the Raspberry Pi 4 Model B shall comply with relevant regulations and standards applicable in the country of intended use.
• This product should be operated in a well-ventilated environment and, if used inside a case, the case should not be covered.
• This product should be placed on a stable, flat, non-conductive surface in use and should not be contacted by conductive items.
• The connection of incompatible devices to the GPIO connection may affect compliance and result in damage to the unit and invalidate the warranty.
• All peripherals used with this product should comply with relevant standards for the country of use and be marked accordingly to ensure that safety and performance requirements are met. These articles include but are not limited to keyboards, monitors and mice when used in conjunction with the Raspberry Pi.
• Where peripherals are connected that do not include the cable or connector, the cable or connector must offer adequate insulation and operation in order that the relevant performance and safety requirements are met.
SAFETY INSTRUCTIONS
To avoid malfunction or damage to this product please observe the following:
• Do not expose to water, moisture or place on a conductive surface whilst in operation.
• Do not expose it to heat from any source; Raspberry Pi 4 Model B is designed for reliable operation at normal ambient room temperatures.
• Take care whilst handling to avoid mechanical or electrical damage to the printed circuit board and connectors.
• Avoid handling the printed circuit board whilst it is powered and only handle by the edges to minimise the risk of electrostatic discharge damage.
Featuring a captive USB-C cable, the power supply is available in four different models to suit different international power sockets, and in two colours, white and black.
Specifications
Output
- Output voltage: +5.1V DC
- Minimum load current: 0A
- Nominal load current: 3.0A
- Maximum power: 15.3W
- Load regulation: ±5%
- Line regulation: ±2%
- Ripple & noise: 120mVp-p
- Rise time: 100ms maximum to regulation limits for DC outputs
- Turn-on delay: 3000ms maximum at nominal input AC voltage and full load
- Protection: Short circuit protection, Overcurrent protection, Over temperature protection
- Efficiency: 81% minimum (output current from 100%,75%, 50%, 25%)72% minimum at 10% load
- Output cable: 1.5m 18AWG
- Output connector: USB Type-C
Input
- Voltage range: 100-240Vac (rated)
- 96-264Vac (operating)
- Frequency: 50/60Hz ±3Hz
- Current: 0.5A maximum
- Power consumption (no load): 0.075W maximum
- Inrush current: No damage shall occur and the input fuse shall not blow
UL94V-1
AC pin material
Brass (NI plated)
WARNINGS
• This product should be operated in a well-ventilated environment.
• The connection of incompatible devices to this power supply may affect compliance, result in damage to the unit and invalidate the warranty.
SAFETY INSTRUCTIONS
To avoid malfunction or damage to this product please observe the following:
• Do not expose to water or moisture, or place on a conductive surface whilst in operation.
• Do not expose to heat from any source; this is designed for reliable operation at normal ambient room temperatures.
• Do not attempt to open or remove the power supply case.
Featuring a captive USB-C cable, the power supply is available in four different models to suit different international power sockets, and in two colours, white and black.
Specifications
Output
- Output voltage: +5.1V DC
- Minimum load current: 0A
- Nominal load current: 3.0A
- Maximum power: 15.3W
- Load regulation: ±5%
- Line regulation: ±2%
- Ripple & noise: 120mVp-p
- Rise time: 100ms maximum to regulation limits for DC outputs
- Turn-on delay: 3000ms maximum at nominal input AC voltage and full load
- Protection: Short circuit protection, Overcurrent protection, Over temperature protection
- Efficiency: 81% minimum (output current from 100%,75%, 50%, 25%)72% minimum at 10% load
- Output cable: 1.5m 18AWG
- Output connector: USB Type-C
Input
- Voltage range: 100-240Vac (rated)
- 96-264Vac (operating)
- Frequency: 50/60Hz ±3Hz
- Current: 0.5A maximum
- Power consumption (no load): 0.075W maximum
- Inrush current: No damage shall occur and the input fuse shall not blow
UL94V-1
AC pin material
Brass (NI plated)
WARNINGS
• This product should be operated in a well-ventilated environment.
• The connection of incompatible devices to this power supply may affect compliance, result in damage to the unit and invalidate the warranty.
SAFETY INSTRUCTIONS
To avoid malfunction or damage to this product please observe the following:
• Do not expose to water or moisture, or place on a conductive surface whilst in operation.
• Do not expose to heat from any source; this is designed for reliable operation at normal ambient room temperatures.
• Do not attempt to open or remove the power supply case.
Get started with the Raspberry Pi with one of our pre-boxed kits
These kits are perfect for beginners that are just just getting exposed to the Raspberry Pi, Media enthusiasts looking to stream online content with Kodi, developers looking to exploit the many advantages of the RPI's GPIO pins and anybody looking to get some cool goodies at a great price! They contain all of the essential items that you need to get up and running in no time.
Please Note: These kits are pre-boxed and cannot be modified at all, we do however keep stock on all of the individual items so if you have a special need simply feel free to browse through the rest of our product offerings and select the items that you'd like.
The kit is availible in a number of options and comes equipped with:
- The Iconic Raspberry Pi 4 Model B 4GB
- An Official 5V 3A Power Supply in White
- A 1m micro HDMI cable
- 16 GB Micro SD card with NOOBS pre-installed
- An Official Pi4 Red/White Case
Want to take your kit to the next level?
Turn your RPI into a Media Centre
Grab yourself a remote control, select LibreELEC or OSMC when setting up your RPI and you'll be streaming in no time. You can even add a wireless keyboard, mouse or other similar controllers
Want a cheap eco-friendly PC
Grab a Keyboard and Mouse, select Raspbian when setting up your RPI and you'll be browsing the web, sending emails, editing spreadsheets and watching videos just like you're used to with a desktop/laptop.
We know you love retro gaming!
Check out our Arcade section, whether you just want a retro control or a mini DIY arcade cabinet we have what you're looking for.
Did somebody say Robotics?
We've got some cool beginner's items in our robotic section
Our Kits come with the latest version of NOOBS – New Out Of the Box Software pre-installed, While we will certainly try our best to assist with any software related questions we cannot offer any kind of official support on community driven, open source, or non-PiShop produced proprietary software.
NOOBS, Raspbian, LibreELEC and OSMC are all open-source software, please visit the developer's respective websites for more info.
So what is NOOBS anyway?In Short, NOOBS is an installer, when you switch your RPI on NOOBS will guide you through the installation of your software of choice... seem confusing? Don't worry it really couldn't be easier
- Raspbian - a full desktop for normal day to day work. Email, internet, office suite, programming etc.
- LibreELEC RPi2 - our preferred version of Kodi for use as a media centre.
- OSMC Pi2 - for more control of your Kodi media centre
- Windows 10 IoT Core - nope this is not windows 10. It simply enables you to run projects and apps for the IOT environment.
- Lakka and Recalbox - retro gaming for the RPi.
A whole bunch of other really cool technical info can be found here.
Getting Started with Raspberry Pi
Get started with the Raspberry Pi with one of our pre-boxed kits
These kits are perfect for beginners that are just just getting exposed to the Raspberry Pi, Media enthusiasts looking to stream online content with Kodi, developers looking to exploit the many advantages of the RPI's GPIO pins and anybody looking to get some cool goodies at a great price! They contain all of the essential items that you need to get up and running in no time.
Please Note: These kits are pre-boxed and cannot be modified at all, we do however keep stock on all of the individual items so if you have a special need simply feel free to browse through the rest of our product offerings and select the items that you'd like.
The kit is availible in a number of options and comes equipped with:
- The Iconic Raspberry Pi 4 Model B 4GB
- An Official 5V 3A Power Supply in White
- A 1m micro HDMI cable
- 16 GB Micro SD card with NOOBS pre-installed
- A 2 layer acrylic Case with fan and heatsinks. Ideal for projects.
Want to take your kit to the next level?
Turn your RPI into a Media Centre
Grab yourself a remote control, select LibreELEC or OSMC when setting up your RPI and you'll be streaming in no time. You can even add a wireless keyboard, mouse or other similar controllers
Want a cheap eco-friendly PC
Grab a Keyboard and Mouse, select Raspbian when setting up your RPI and you'll be browsing the web, sending emails, editing spreadsheets and watching videos just like you're used to with a desktop/laptop.
We know you love retro gaming!
Check out our Arcade section, whether you just want a retro control or a mini DIY arcade cabinet we have what you're looking for.
Did somebody say Robotics?
We've got some cool beginner's items in our robotic section
Our Kits come with the latest version of NOOBS – New Out Of the Box Software pre-installed, While we will certainly try our best to assist with any software related questions we cannot offer any kind of official support on community driven, open source, or non-PiShop produced proprietary software.
NOOBS, Raspbian, LibreELEC and OSMC are all open-source software, please visit the developer's respective websites for more info.
So what is NOOBS anyway?In Short, NOOBS is an installer, when you switch your RPI on NOOBS will guide you through the installation of your software of choice... seem confusing? Don't worry it really couldn't be easier.
- Raspbian - a full desktop for normal day to day work. Email, internet, office suite, programming etc.
- LibreELEC RPi2 - our preferred version of Kodi for use as a media centre.
- OSMC Pi2 - for more control of your Kodi media centre
- Windows 10 IoT Core - nope this is not windows 10. It simply enables you to run projects and apps for the IOT environment.
- Lakka and Recalbox - retro gaming for the RPi.
A whole bunch of other really cool technical info can be found here.
Getting Started with Raspberry Pi
This brilliant Starter Kit is a perfect starting point to get you up and running with your RPI Zero Wireless H so you can get Playing / Making/ Prototyping etc ASAP.
The Kit includes:
- Raspberry Pi Zero WH (presoldered header)
- 16GB preloaded Sandisk micro SD card(NOOBS)
- 3 Port USB Hub w/ Ethernet - Micro USB
- Official Raspberry Pi Zero Red & White Case
- Raspberry Pi Official USB-C 15.3W power supply White 5.1V 3A
- White USB type C female to USB micro B male adapter to use with the 3A power supply
- Official Raspberry Pi standard HDMI to mini HDMI Cable 1m White
Getting Started with Raspberry Pi
Get started with the Raspberry Pi with one of our pre-boxed kits
These kits are perfect for beginners that are just just getting exposed to the Raspberry Pi, Media enthusiasts looking to stream online content with Kodi, developers looking to exploit the many advantages of the RPI's GPIO pins and anybody looking to get some cool goodies at a great price! They contain all of the essential items that you need to get up and running in no time.
Please Note: These kits are pre-boxed and cannot be modified at all, we do however keep stock on all of the individual items so if you have a special need simply feel free to browse through the rest of our product offerings and select the items that you'd like.
The kit is availible in a number of options and comes equipped with:
- The Iconic Raspberry Pi 4 Model B 4GB
- An Black oneninedesign case
- A 1m micro HDMI cable
- 16 GB Micro SD card with NOOBS pre-installed
- An Official Pi4 Red/White Case
- An Official Pi4 black 5.1V 3A Power Supply
Want to take your kit to the next level?
Turn your RPI into a Media Centre
Grab yourself a remote control, select LibreELEC or OSMC when setting up your RPI and you'll be streaming in no time. You can even add a wireless keyboard, mouse or other similar controllers
Want a cheap eco-friendly PC
Grab a Keyboard and Mouse, select Raspbian when setting up your RPI and you'll be browsing the web, sending emails, editing spreadsheets and watching videos just like you're used to with a desktop/laptop.
We know you love retro gaming!
Check out our Arcade section, whether you just want a retro control or a mini DIY arcade cabinet we have what you're looking for.
Did somebody say Robotics?
We've got some cool beginner's items in our robotic section
Our Kits come with the latest version of NOOBS – New Out Of the Box Software pre-installed, While we will certainly try our best to assist with any software related questions we cannot offer any kind of official support on community driven, open source, or non-PiShop produced proprietary software.
NOOBS, Raspbian, LibreELEC and OSMC are all open-source software, please visit the developer's respective websites for more info.
So what is NOOBS anyway?In Short, NOOBS is an installer, when you switch your RPI on NOOBS will guide you through the installation of your software of choice... seem confusing? Don't worry it really couldn't be easier
- Raspbian - a full desktop for normal day to day work. Email, internet, office suite, programming etc.
- LibreELEC RPi2 - our preferred version of Kodi for use as a media centre.
- OSMC Pi2 - for more control of your Kodi media centre
- Windows 10 IoT Core - nope this is not windows 10. It simply enables you to run projects and apps for the IOT environment.
- Lakka and Recalbox - retro gaming for the RPi.
A whole bunch of other really cool technical info can be found here.
Getting Started with Raspberry Pi
