R117.90  Inc VAT
R122.69
A low cost, high-performance microcontroller board built around Raspberry Pi's very own chip - the RP2040.
R69.90  Inc VAT
The Official Raspberry Pi Power Supply - Shipped with easily interchangeable heads for the UK and EU.
R179.90  Inc VAT
R449.90  Inc VAT
R249.90  Inc VAT
R99.90  Inc VAT
R179.90
Raspberry Pi Pico Maker kit 1 (Pico maker kit 1)

This Starter Kit is based around the Raspberry Pi Pico development board which features the Raspberry Pi RP2040 microcontroller chip.

Whats in the box:


Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts





R117.90  Inc VAT
R122.69
Raspberry Pi Pico Maker kit 2 power supply 5V 2A (Pico maker kit 2)

This Starter Kit is based around the Raspberry Pi Pico development board which features the Raspberry Pi RP2040 microcontroller chip.

Whats in the box:


Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts






R209.90  Inc VAT
Raspberry Pi Pico Maker kit 3 Official power supply 5.1V 2.5A (Pico maker kit 3)

This Starter Kit is based around the Raspberry Pi Pico development board which features the Raspberry Pi RP2040 microcontroller chip.

Whats in the box:


Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts






R269.90  Inc VAT
R272.60
Raspberry Pi Pico with presoldered headers (RPi Pico with headers)

https://www.raspberrypi.org/blog/raspberry-pi-silicon-pico-now-on-sale/

https://www.raspberrypi.org/products/raspberry-pi-pico/

https://www.youtube.com/watch?v=ZY-HrRGCQ4w

Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts

YouTube video on Pico by Jeff Geerling

Raspberry Pi Pico, a microcontroller board built on silicon designed here at Raspberry Pi.

Whether you choose to use our C/C++ SDK, or the official MicroPython port, everything you need to get started is here. You’ll also find links to the technical documentation for both the Raspberry Pi Pico microcontroller board and our RP2040 microcontroller chip.



Board Specifications

  • RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
  • Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz
  • 264kB of SRAM, and 2MB of on-board Flash memory
  • Castellated module allows soldering direct to carrier boards
  • USB 1.1 Host and Device support
  • Low-power sleep and dormant modes
  • Drag & drop programming using mass storage over USB
  • 26 multi-function GPIO pins
  • 2×SPI, 2×I2C, 2×UART, 3×12-bit ADC, 16×controllable PWM channels
  • Accurate clock and timer on-chip
  • Temperature sensor
  • Accelerated floating point libraries on-chip
  • 8×Programmable IO (PIO) state machines for custom peripheral support


Download Pinout Diagram


Documentation

Documentation for the Raspberry Pi Pico board and the RP2040 microcontroller:

The API level Doxygen documentation for the Raspberry Pi Pico C/C++ SDK is available as a micro-site.

While Raspberry Pi Pico does not come with anything soldered to its pads, we will recommend that users fit 2.54mm pitch male pin strip headers.


R149.90  Inc VAT
Raspberry Pi Official EU only Power Supply 5.1V 2.5A (Black) for RPi, RPi3, Zero and Pico (Pi3 Power 2.5A Black EU)

You'll need a USB Type C adapter to use this supply for Pi 4


This PSU supports up to 2.5A of current, so it won't let you down when powering hungry devices through your Raspberry Pi 3 Model B

Technical Data

  • 5.1V 2.5A Output
  • 1.5m Cable
  • Black with Raspberry Pi Logo
  • Input Voltage AC Max: 264V
  • Input Voltage AC Min: 90V
  • Output Connector: USB Micro
  • Output Voltage Nom.: 5.1V
  • Interchangeable Adaptor - EU/UK

    The below is a copy from https://www.raspberrypi.org/help/faqs/#powerReqs.

    Here is a table comparing the amount of power drawn in amps under different situations:

      Pi1 (B+)Pi2 BPi3 B (Amps)Zero (Amps)
    BootMax0.260.400.750.20
     Avg0.220.220.350.15
    IdleAvg0.200.220.300.10
    Video playback (H.264)Max0.300.360.550.23
     Avg0.220.280.330.16
    StressMax0.350.821.340.35
     Avg0.320.750.850.23
    Test conditions used a standard Raspbian image (current as of 26 Feb 2016),

R154.90  Inc VAT
Raspberry Pi Pico (RPi Pico)

https://www.raspberrypi.org/blog/raspberry-pi-silicon-pico-now-on-sale/

https://www.raspberrypi.org/products/raspberry-pi-pico/

https://www.youtube.com/watch?v=ZY-HrRGCQ4w

Add wifi to Pico using Cricket
https://www.thingsonedge.com/post/pico-cricket-blynk-phone-alerts

YouTube video on Pico by Jeff Geerling

Raspberry Pi Pico, a microcontroller board built on silicon designed here at Raspberry Pi.

Whether you choose to use our C/C++ SDK, or the official MicroPython port, everything you need to get started is here. You’ll also find links to the technical documentation for both the Raspberry Pi Pico microcontroller board and our RP2040 microcontroller chip.



Board Specifications

  • RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
  • Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz
  • 264kB of SRAM, and 2MB of on-board Flash memory
  • Castellated module allows soldering direct to carrier boards
  • USB 1.1 Host and Device support
  • Low-power sleep and dormant modes
  • Drag & drop programming using mass storage over USB
  • 26 multi-function GPIO pins
  • 2×SPI, 2×I2C, 2×UART, 3×12-bit ADC, 16×controllable PWM channels
  • Accurate clock and timer on-chip
  • Temperature sensor
  • Accelerated floating point libraries on-chip
  • 8×Programmable IO (PIO) state machines for custom peripheral support


Download Pinout Diagram


Documentation

Documentation for the Raspberry Pi Pico board and the RP2040 microcontroller:

The API level Doxygen documentation for the Raspberry Pi Pico C/C++ SDK is available as a micro-site.

While Raspberry Pi Pico does not come with anything soldered to its pads, we will recommend that users fit 2.54mm pitch male pin strip headers.


A low cost, high-performance microcontroller board built around Raspberry Pi's very own chip - the RP2040.
R69.90  Inc VAT
Raspberry Pi Official Pi3/ZERO/Pico Micro USB Universal Power Supply 5.1V 2.5A (White) (Pi3 Power 2.5A White)

You'll need a USB Type C adapter to use this supply for Pi 4

The Official Raspberry Pi Power Supply -
Shipped with easily interchangeable heads for the UK, US, EU and Australia you can now use your Pi in all four corners of the world!

This PSU supports up to 2.5A of current, so it won't let you down when powering hungry devices through your Raspberry Pi 3 Model B

Technical Data

  • 5.1V 2.5A Output
  • 1.5m Cable
  • White with Raspberry Pi Logo
  • Input Voltage AC Max: 264V
  • Input Voltage AC Min: 90V
  • Output Connector: USB Micro
  • Output Voltage Nom.: 5.1V
  • Interchangeable Adaptor - EU/UK/US/AUS

    The below is a copy from https://www.raspberrypi.org/help/faqs/#powerReqs.

    Here is a table comparing the amount of power drawn in amps under different situations:

      Pi1 (B+)Pi2 BPi3 B (Amps)Zero (Amps)
    BootMax0.260.400.750.20
     Avg0.220.220.350.15
    IdleAvg0.200.220.300.10
    Video playback (H.264)Max0.300.360.550.23
     Avg0.220.280.330.16
    StressMax0.350.821.340.35
     Avg0.320.750.850.23
    Test conditions used a standard Raspbian image (current as of 26 Feb 2016),

The Official Raspberry Pi Power Supply - Shipped with easily interchangeable heads for the UK and EU.
R179.90  Inc VAT
Get Started with MicroPython on Raspberry Pi Pico (book micropython pico)
What is MicroPython?

MicroPython is a full implementation of the Python 3 programming language that runs directly on embedded hardware like Raspberry Pi Pico. You get an interactive prompt (the REPL) to execute commands immediately via USB Serial, and a built-in filesystem. The Pico port of MicroPython includes modules for accessing low-level chip-specific hardware.

What is Raspberry Pi Pico?
Raspberry Pi Pico, a microcontroller board built on silicon designed here at Raspberry Pi.




Your official guide

Microcontrollers, like RP2040 at the heart of Raspberry PiPico, are computers stripped back to their bare essentials. You don’t use monitors or keyboards, but program them to take their input from, and send their output to the input/output pins. Using these programmable connections, you can light lights, make noises, send text to screens, and much more. In Get Started with MicroPython on Raspberry Pi Pico, you will learn how to use the beginner-friendly language MicroPython to write programs and connect up hardware to make your Raspberry Pi Pico interact with the world around it. Using these skills, you can create your own electro‑mechanical projects, whether for fun or to make your life easier.

Contents of the Raspberry Pi Pico book:

Chapter 1: Get to know your Raspberry Pi Pico
Get fully acquainted with your powerful new microcontroller and learn how to attach pin headers and install MicroPython to program it

Chapter 2: Programming with MicroPython
Connect a computer and start writing programs for your Raspberry Pi Pico using the MicroPython language

Chapter 3: Physical computing
Learn about your Raspberry Pi Pico’s pins and the electronic components you can connect and control

Chapter 4: Physical computing with Raspberry Pi Pico
Start connecting basic electronic components to your Raspberry Pi Pico and writing programs to control and sense them

Chapter 5: Traffic light controller
Create your own mini pedestrian crossing system using multiple LEDs and a push-button

Chapter 6: Reaction game
Build a simple reaction timing game using an LED and push-buttons, for one or two players

Chapter 7: Burglar alarm
Use a motion sensor to detect intruders and sound the alarm with a flashing light and siren

Chapter 8: Temperature gauge
Use your Raspberry Pi Pico’s built-in ADC to convert analogue inputs, and read its internal temperature sensor

Chapter 9: Data logger
Turn Raspberry Pi Pico into a temperature data-logging device and untether it from the computer to make it fully portable

Chapter 10: Digital communication protocols: I2C and SPI
Explore these two popular communication protocols and use them to display data on an LCD



R184.90  Inc VAT
R199.90
5V 2A EU Power Supply Micro USB AC Adapter for Pico (pico power 5V 2A)
Features:

Input Voltage: AC 100-240V 50/60Hz
Output: DC 5.0V 2000mA (2.0A)
Cable Length: Approx.870 mm
Short Circuit Protection
Overload Protection
Consistent fixed switching voltage
Internal Fuse for Extra Safety

Package includes:

1 x EU Power supply with micro USB cable
R89.90  Inc VAT
UPS Module for Raspberry Pi Pico, Uninterruptible Power Supply (WS Pico UPS)
Uninterruptible Power Supply for Pico

Keeps your Pico running while recharging, monitoring battery status via I2C

Features at a glance

The Pico-UPS-A is a dedicated UPS (Uninterruptible Power Supply) module designed for Raspberry Pi Pico. It incorporates Li-ion battery switching charger with power path management, and voltage/current monitoring chip, allows monitoring the battery operating status via I2C bus.

  • Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series boards
  • Incorporates Li-ion battery switching charger with dynamic power path management, more stable power supply
  • I2C bus communication, monitoring the battery voltage, current, power, and remaining capacity in real time
  • Multi battery protection circuits: over charge/discharge protection, over current protection, short circuit protection, and reverse protection, along with the equalizing charge feature, more safe and stable
  • Onboard recharging indicator, power indicator, and battery warning indicator to check if the battery is connected correctly
  • Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
Specifications
Recharge voltage5V
Control busI2C
Battery support14500 Li-ion battery (NOT included)
Dimensions60 × 21mm

Raspberry Pi Pico header compatibility

onboard female pin header for direct attaching to Raspberry Pi Pico



Raspberry Pi Pico and Li-ion battery are NOT included.

What's On Board

  1. ETA6003
    recharger chip
  2. INA219
    voltage/current monitoring chip
  3. S8261
    Li-ion battery protection chip
  4. FS8205
    Li-ion battery protection MOS
  5. AO3400
    reverse-proof MOS
  6. SI2305
    counter current preventing MOS
  1. Rapsberry Pi Pico header
    for direct attaching to Raspberry Pi Pico
  2. Power switch
  3. Activate button
    activate the protection circuit after replacing battery
  4. 14500 battery holder
Pinout definition



Outline dimensions



Resources & Services

R219.90  Inc VAT
Precision RTC Module for Raspberry Pi Pico Onboard DS3231 Chip (WS Pico RTC board)
Features at a glance

The Pico-RTC-DS3231 is a RTC expansion module specialized for Raspberry Pi Pico. It incorporates high precision RTC chip DS3231 and uses I2C bus for communication. More external sensors are allowed to be connected thanks to the stackable design.

  • Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series
  • Onboard high precision RTC chip DS3231, with backup battery holder
    • Real-Time Clock Counts Seconds, Minutes, Hours, Date of the Month, Month, Day of the Week, and Year with Leap-Year Compensation Valid Up to 2100
    • Optional format : 24-hour OR 12-hour with an AM/PM indicator
    • 2x programmable alarm clock
  • Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
Specifications

Operating voltage3.3V
Backup battery voltage2.3V ~ 5.5V
Operating temperature-40°C ~ +85°C
Power consumption100nA (sustains data and clock information)

Raspberry Pi Pico header compatibility

Onboard female pin header for direct attaching to Raspberry Pi Pico Stackable design


Raspberry Pi Pico is NOT included.

What's On Board


  1. DS3231
    high precision RTC chip, I2C bus
  2. RTC backup battery
    supports CR1220 button cell
  3. Power indicator
    enabled by soldering a 0Ω resistor on the jumper, disabled by default

Pinout definition



Outline dimensions



Resources & Services

R129.90  Inc VAT
10-DOF IMU Sensor Module for Raspberry Pi Pico Onboard ICM20948 and LPS22HB Chip (ws pico 10dof)
Incorporates 9-axis motion sensor ICM20948 and baroceptor LPS22HB

Features at a glance

The Pico-10DOF-IMU is an IMU sensor expansion module specialized for Raspberry Pi Pico. It incorporates sensors including gyroscope, accelerometer, magnetometer, baroceptor, and uses I2C bus for communication.

Combined with the Raspberry Pi Pico, it can be used to collect environment sensing data like temperature and barometric pressure, or to easily DIY a robot that detects motion gesture and orientation.

  • Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series
  • Onboard ICM20948 (3-axis gyroscope, 3-axis accelerometer, and 3-axis magnetometer) for detecting motion gesture, orientation, and magnetic field
  • Onboard LPS22HB barometric pressure sensor, for sensing the atmospheric pressure of the environment
  • Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
Specifications
Operating voltage5V
accelerometerresolution: 16-bit
measuring range (configurable): ±2, ±4, ±8, ±16g
operating current: 68.9uA
gyroscoperesolution: 16-bit
measuring range (configurable): ±250, ±500, ±1000, ±2000°/sec
operating current: 1.23mA
magnetometerresolution: 16-bit
measuring range: ±4900µT
operating current: 90uA
baroceptormeasuring range: 260 ~ 1260hPa
measuring accuracy (ordinary temperature): ±0.025hPa
measuring speed: 1Hz - 75Hz

Raspberry Pi Pico header compatibility

Onboard female pin header for direct attaching to Raspberry Pi Pico

Stackable design

Raspberry Pi Pico is NOT included.

What's On Board


  1. ICM20948
    9-axis motion sensor, I2C bus
  2. LPS22HB
    barometric pressure sensor, I2C bus
  3. RT9193-33
    3.3V linear voltage regulator
  4. LSF0204PWR
    4-ch voltage translator
  1. RT9193-18
    1.8V linear voltage regulator
  2. Power indicator
  3. Raspberry Pi Pico header
    for attaching to Raspberry Pi Pico, stackable design
Pinout definition



Outline dimensions



Resources & Services

R249.90  Inc VAT
2.13inch E-Paper E-Ink Display Module for Raspberry Pi Pico, 250×122, Black / White, SPI (ws pico e-paper 250x122)
Partial refresh support, low power, wide viewing angle, paper-like effect



Features at a glance
  • No backlight, keeps displaying last content for a long time even when power down
  • Ultra low power consumption, basically power is only required for refreshing
  • SPI interface, requires minimal IO pins
  • Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
Specifications
operating voltage3.3V/5Vgrey scale2
interface3-wire SPI, 4-wire SPIpartial refresh time0.3s
outline dimensions65.00 × 30.50mmfull refresh time2s
display size48.55 × 23.70mmrefresh power26.4mW(typ.)
dot pitch0.194 × 0.194mmstandby current<0.01uA (almost none)
resolution250×122 pixelsviewing angle>170°
display colorblack, white

Advantages of EINK

E-paper display utilizes microcapsule electrophoretic technology for displaying, the principle is: charged particles suspended in clear fluid will move to sides of microcapsule when electric field is applied, making the microcapsule become visible by reflecting ambient light, just as traditional printed paper.
E-paper display will clearly display images/texts under lamplight or natural light, requires no backlight, and features nearly up to 180° viewing angle. It is usually used as e-reader due to its paper-like effect.

Raspberry Pi Pico header compatibility

Onboard female pin header for direct attaching to Raspberry Pi Pico




Raspberry Pi Pico is NOT included.

Application examples

Suitable for price Tags, asset/equipment Tags, shelf labels, conference name tags...


Pinout definition



Outline dimensions



Resources & Services

R259.90  Inc VAT
Dual GPIO Expander for Raspberry Pi Pico, Two Sets of Male Headers (ws pico expander dual)
Two sets of standard Raspberry Pi Pico GPIO male headers

Features at a glance
  • Standard Raspberry Pi Pico female header for direct attaching Raspberry Pi Pico (if male header soldered), or just through jumper wires
  • Two sets of 2x20 male header, allows connecting more Raspberry Pi Pico expansion modules
  • Clear pinout labels on the front side, easy to use
  • Immersion gold process, beautiful & practical, stunning aesthetic looking
Raspberry Pi Pico header compatibility

Center female pin header for direct attaching the Raspberry Pi Pico



Two sets of 2x20 male header

Allows connecting more Raspberry Pi Pico expansion modules


Please make sure there are no pin conflicts between the modules you want to use together before connecting.

Raspberry Pi Pico and expansion modules are NOT included.

Immersion gold process

Black base panel, white pinout labels, golden rounded outline, stunning aesthetic



Outline dimensions

R109.90  Inc VAT
Quad GPIO Expander for Raspberry Pi Pico, Four Sets of Male Headers, USB Power Connector (ws pico expander quad)
Four sets of standard Raspberry Pi Pico GPIO male headers, USB-powered support

Features at a glance
  • Standard Raspberry Pi Pico female header for direct attaching Raspberry Pi Pico (if male header soldered), or just through jumper wires
  • Four sets of 2x20 male header, allows connecting more Raspberry Pi Pico expansion modules
  • USB power input connector, ensures sufficient power supply for multiple expansion modules
  • Clear pinout labels on the front side, easy to use
  • Immersion gold process, beautiful & practical, stunning aesthetic looking
Raspberry Pi Pico header compatibility

Center female pin header for direct attaching the Raspberry Pi Pico



Four sets of 2x20 male header

Allows connecting more Raspberry Pi Pico expansion modules
Extra USB connector for external power supply



Please make sure there are no pin conflicts between the modules you want to use together before connecting.

Raspberry Pi Pico and expansion modules are NOT included.

Immersion gold process

Black base panel, white pinout labels, golden rounded outline, stunning aesthetic



Outline dimensions

R159.90  Inc VAT
Raspberry Pi Pico MicroPython Programming Learning Kit(excluding book) (pico begin kit parts)
Raspberry Pi Pico Basic Kit

Basic entry-level kit prepared for Pico. All the parts you need to complete the tutorials in the MicroPython beginners book (not included)

Tested and selected by professional engineer, with rich tutorials and resources
fast getting started with Raspberry Pi Pico and MicroPython programming



What's in the kit

Raspberry Pi Pico with pre-soldered header

A Low-Cost, High-Performance Microcontroller Board With Flexible Digital Interfaces

more details...

  • RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
  • Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz
  • 264KB of SRAM, and 2MB of on-board Flash memory
  • Castellated module allows soldering direct to carrier boards
  • USB 1.1 with device and host support
  • Low-power sleep and dormant modes
  • Drag-and-drop programming using mass storage over USB
  • 26 × multi-function GPIO pins
  • 2 × SPI, 2 × I2C, 2 × UART, 3 x12-bit ADC, 16 × controllable PWM channels
  • Accurate clock and timer on-chip
  • Temperature sensor
  • Accelerated floating-point libraries on-chip
  • 8 × Programmable I/O (PIO) state machines for custom peripheral support



ItemDescription
LCD1602 RGB ModuleLCD1602 RGB backlight character LCD, using I2C bus to display text or adjust RGB backlight
PIR motion sensorPyroelectric IR sensor, outputs electric switch signal when IR array from human/animal body is detected
8-Bit WS2812 RGB LED8x RGB LED, play around with cool light effects by programming
AlarmQuality active announciator, used for alarming or playing music
Single-joint potentiometerAdjustable potentiometer, 0~10K range, used for ADC test, volume/brightness adjustment, etc.
Round buttonsThree colors, for button/switch detection
5mm LEDThree colors, for experiments like traffic light, PWM adjusted light, etc.
330R resistorsProviding current-limit protection when connected with LED in series
Breadboard and wires
Jumper wires
Quality 830 breadboard and sorts of wires, easy for connecting components
Plastic boxCustomized box for storing the modules and components


R499.90  Inc VAT
Raspberry Pi Pico MicroPython Programming Learning Kit including book (pico begin kit book)
Raspberry Pi Pico Basic Kit

Basic entry-level kit prepared for Pico. All the parts you need to complete the tutorials in the MicroPython beginners book (Included)

Tested and selected by professional engineer, with rich tutorials and resources
fast getting started with Raspberry Pi Pico and MicroPython programming



What's in the kit

Raspberry Pi Pico with pre-soldered header

A Low-Cost, High-Performance Microcontroller Board With Flexible Digital Interfaces

more details...

  • Get Started with MicroPython on Raspberry Pi Pico Book
  • RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
  • Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz
  • 264KB of SRAM, and 2MB of on-board Flash memory
  • Castellated module allows soldering direct to carrier boards
  • USB 1.1 with device and host support
  • Low-power sleep and dormant modes
  • Drag-and-drop programming using mass storage over USB
  • 26 × multi-function GPIO pins
  • 2 × SPI, 2 × I2C, 2 × UART, 3 x12-bit ADC, 16 × controllable PWM channels
  • Accurate clock and timer on-chip
  • Temperature sensor
  • Accelerated floating-point libraries on-chip
  • 8 × Programmable I/O (PIO) state machines for custom peripheral support



ItemDescription
LCD1602 RGB ModuleLCD1602 RGB backlight character LCD, using I2C bus to display text or adjust RGB backlight
PIR motion sensorPyroelectric IR sensor, outputs electric switch signal when IR array from human/animal body is detected
8-Bit WS2812 RGB LED8x RGB LED, play around with cool light effects by programming
AlarmQuality active announciator, used for alarming or playing music
Single-joint potentiometerAdjustable potentiometer, 0~10K range, used for ADC test, volume/brightness adjustment, etc.
Round buttonsThree colors, for button/switch detection
5mm LEDThree colors, for experiments like traffic light, PWM adjusted light, etc.
330R resistorsProviding current-limit protection when connected with LED in series
Breadboard and wires
Jumper wires
Quality 830 breadboard and sorts of wires, easy for connecting components
Plastic boxCustomized box for storing the modules and components


R649.90  Inc VAT
R699.90
Pico RGB Keypad Base (Pico RGB Keypad Base)

Connect a glorious, squishy, 4x4 rainbow-illuminated keypad to your Raspberry Pi Pico - perfect for making a custom USB input device!

Scoring very highly in the Pimoroni "things on our desk that make people say ooo" rankings, RGB Keypad Base equips a Pico with an eye-catching 4x4 silicone keypad, fully loaded with addressable APA102 LEDs so that each key can be illuminated in any colour that your little unicorn heart desires. It's all mounted on a sturdy base with rubber feet to keep it nice and level, with a handily labelled landing area for your Pico. We've broken out the full set of Pico pins to make it easy to connect up other hardware as well.

Connect your Pico project to another computer via USB for a beautiful macro keypad or a tidy midi controller. RGB Keypad Base would also work well in any project that would benefit from having fancy light up buttons as inputs - a code protected door lock perhaps, a disco dance floor for your fingers or a Simon Says style game with which to taunt your friends.

A Raspberry Pi Pico is not included - click here if you'd like to buy one!

Your Pico will need to have male headers soldered to it (with the pins pointing downwards) to attach to our add-on boards.

Features

  • 4x4 silicone keypad with conductive buttons
  • 16 x APA102 addressable RGB LEDs (datasheet)
  • Keypad buttons are connected via a TCA9555 IO expander (I2C address: 0x20).
  • Labelled landing area with female headers for attaching your Pico, with broken out pins.
  • Compatible with Raspberry Pi Pico.
  • Some assembly required!
  • No soldering required (as long as your Pico has header pins attached).
  • Dimensions: approx 60mm x 101mm x 16mm (L x W x H, assembled)
  • C/C++ and MicroPython libraries

Includes

  • 1x Pico RGB Keypad Base
  • 1x (reversible) square retainer plate
  • 1x silicone keypad
  • M2 8mm bolts and nuts
  • 4x rubber feet

Getting started

Turn the larger board over, and attach the little rubber feet to the paw print spaces on the bottom.

Flip it over again, and pop the silicone keypad over the buttons so the tabs fit into the holes. You can then slot the retainer plate over the top of the keys, matching up the key markings with those on the base board. You can install the retainer plate either way up, depending on whether you prefer it patterned or plain!

Poke the M2 bolts through the holes in the mounting plate (from the top) and screw on the nuts to keep all the layers sandwiched together. The bolts only need to be tightened up enough to keep the layers in place - if you find that the keys are hard to push or that the silicone layer is bulging out of the sides you might want to slacken them off a bit.

The labels on the base will show you which way round to attach your Pico - just match up the USB port to the markings on the board.

The easiest way to get started is by downloading and copying our custom MicroPython uf2 to your Pico, it includes all the libraries you'll need to use our add-ons. Click here for our beginner friendly tutorial!

You can find C examples here and MicroPython examples here.

Pinout

R449.90  Inc VAT
Pico Wireless Pack (Pico Wireless Pack)

Give your Raspberry Pi Pico project the capacity to chat with 2.4GHz Wi-Fi networks plus a handy microSD card slot!

Pico Wireless Pack attaches to the back of your Pico and uses an ESP32 chip to let your Pico connect to 2.4GHz wireless networks and transfer data. There's a microSD card slot for if you want to store lots of data locally as well as a RGB LED (for status updates) and a button (useful for things like enabling/disabling Wi-Fi).

Great for quickly adapting an existing Pico project to have wireless functionality, Pico Wireless Pack would come in handy for sending sensor data into home automation systems or dashboards, for hosting a web page from a matchbox or for letting your Pico interact with online APIs.

Raspberry Pi Pico not included - click here if you'd like to buy one.

Features

  • ESP32-WROOM-32E module for wireless connectivity (connected via SPI) (datasheet)
  • 1 x tactile button
  • RGB LED
  • Micro-SD card slot*
  • Pre-soldered female headers for attaching your Raspberry Pi Pico
  • Fully assembled
  • No soldering required (as long as your Pico has header pins attached).
  • Compatible with Raspberry Pi Pico.
  • Dimensions: approx 53mm x 25mm x 11mm (L x W x H, including headers and components)
  • C++ and MicroPython libraries

Getting started

We've added C++/MicroPython support for Wireless Pack to our Pico libraries and our custom MicroPython uf2 comes with wireless drivers for the ESP32 baked in. You can find C++ examples here and MicroPython examples here - there's a Cheerlights example that shows you how to make requests from an API, and one that sets your Pico up as a tiny HTTP server, accessible through your browser.

Alternatively, you can use Pico Wireless Pack with CircuitPython and Adafruit's easy to use ESP32SPI and Adafruit_CircuitPython_SD libraries. You'll need to alter their examples to use the correct pins:

spi = busio.SPI(board.GP18, board.GP19, board.GP16)

esp32_cs = DigitalInOut(board.GP7)
esp32_ready = DigitalInOut(board.GP10)
esp32_reset = DigitalInOut(board.GP11)

SD_CS = board.GP22

Pinout



Notes

  • * Please note that SD card support in the C++ SDK is still quite experimental - if you're planning on doing things with data you might have an easier time of it if you use CircuitPython!
  • The cuttable traces on the back let you disconnect functions that you're not using, freeing up the pins and making it easier to use Wireless Pack with other add-ons.
R249.90  Inc VAT
PiBorg - Motor Controller (Piborg motor controller)

The PicoBorg is an ultra compact motor controller for the Raspberry Pi!

With PicoBorg, you can turn on and off fans, motors, solenoids or relays from your Raspberry Pi. There are 4 low side drivers, so you can turn on and off 4 devices, and one device is connected to the Pi's PWM pin, so you can vary the speed of that motor! Motor control is accessed via a simple GUI, which can be installed by following the PicoBorg installation instructions.

Motor power is not taken directly from the Raspberry Pi, so there's no risk of your Pi dropping out. Instead, the PicoBorg utilises a battery pack to drive the motors; meaning you're not restricted to 5V motors, in fact you can drive ANY motors up to 20V!

The PicoBorg is perfect for any small motor project, for example:

  • 4 fans on/off control over all and vary speed on one fan
  • 4 solenoids
  • 4 DC motors (on / off control over all and vary speed on one motor)
  • Control one 6 wire stepper motor in both directions
  • Rover project!

The PicoBorg Features:

  • Drive 4 x DC Motors (on/off) or 1 x 6-Wire Stepper motor (Bi-Direction)
  • Allows speed control on 1 x Motor
  • Max 20V recommended 12V or less
  • Max current 2.5A (stall) or less
  • Primarily designed to be used with large resistance, low inductance motors and for learning and experimenting purposes.

Warnings:
  • As there are no pull up or pull down resistors on the inputs, the picoBorg expects the Pi to be controlling the pins when the power is applied. Power the Pi first, run the software and then apply power to the PicoBorg.
  • There is no thermal shutoff, keep an eye on temperature of the FETs and diodes
  • There is no current limiting, you must observe current restrictions
  • There is no short circuit or reverse voltage protection
  • For commercial applications and control of larger motors and lower resistance coils etc, PiBorg or PiBorg nano may be a better solution
  • If you are new to electronics and getting started, we recommend you don't use a battery, rather a low current <100mA power supply as this can be more forgiving if you get things wrong
  • Be very careful of connections and soldering as mistakes could potentially hurt your picoBorg and Raspberry Pi.
R99.90  Inc VAT
R179.90
Per Page      1 - 20 of 26
