Description:

This minimal Camera for the Pi Zero is perfect for small camera projects where space is at a premium.

The sensor is 5MP, and the whole shebang is mounted on a flexible circuit board. As such, a little care is needed when handling, just like the connector on the Pi Zero. Easy there Lennie.

Otherwise it's an economical and svelte solution for birdcams, bodycams, home security and simple computer vision projects.

Update: Without an IR filter, which is useful for night vision, especially when using IR lights to illuminate the subject

Only for Raspberry Pi Zero with CSI camera port.

Approx dimensions of camera: 10mm x 11.4mm x 5.1mm

Getting started with PiCamera

The RPIZ_CT3T1 is the same unit as the RPICT3T1 in the Raspberry pi Zero format.

Refer to the RPICT3T1 for full documentation.

Use with sct-013-000 split core current sensor and DS18B20 temp sensor

Please note: Raspberry Pi Zero and sensors are not included

The RPIZ_CT3T1 is the same unit as the RPICT3V1 in the Raspberry pi Zero format.

Refer to the RPICT3V1 for full documentation.

Use with sct-013-000 split core current sensor and 230VAC to 9VAC power adapter

Please note: Raspberry Pi Zero and sensors are not included

Note: The Raspberry Pi, High Quality Camera and flexible tripod not included)

Little brother to ProtoDock , ZeroDock will keep your desk tidy and all of your Raspberry Pi Zero accessories in one place. No more searching for your micro-SD cards , SD adapters , HDMI adapters , USB shims , breadboards or even the Raspberry Pi Zero itself.

It’s all here, every time you’re ready to prototype a project, in one neat and tidy package.

Please note: Simple assembly required. Please see the assembly guide.

The default configuration holds a mini breadboard (included), an SD card adapter, 2x micro SD cards, 2x USB devices, a micro-USB shim and of course the Raspberry Pi Zero itself.

Users can decide to use the micro-USB shim slot to hold a micro-HDMI adapter, or you may want to hold a Portsplus or similar GPIO reference card in the SD adapter slot. You can choose to store your USB micro-SD card reader or even other larger USB devices such as the USBDoctor. Use it in whatever way works best for you.

All of the Raspberry Pi Zero ports are accessible from the ZeroDock, including the camera port and reset/composite pin header. pHATs are also not obstructed, so you’re free to prototype with your favourite add-on boards.

The case is a stylish mix of clear and black acrylic layers, black fixings and a clear breadboard, fitting in well alongside most desktop PCs/monitors.

Assembly guide available here

Kit includes:

• 4 layer laser-cut acrylic case
• Case and Raspberry Pi fixings
• Mini breadboard

Please Note - Raspberry Pi Zero & accessories not included (but the breadboard is!)

• Hard to get started without additional devices (monitor, keyboard, and mouse). Beginners will either need to use additional devices or follow many steps just to get started. This may confuse them. For techies that want to know why, this is because it lacks an onboard USB to UART communication for your computer to get the IP address for SSH (headless), or to kick start configuration directly.
• Hard to get started with electronics. It doesn't come with any inputs or outputs, you will need to connect additional accessories to use it. Most beginners do not have basic knowledge of electronics. They will have a problem to understand the circuit diagram and connections needed when they first started learning. They will spend a substantial amount of time just to connect the wires and troubleshoot the connections.
• Hard to troubleshoot the GPIO. With just the raspberry pi, beginners face a common problem when learning electronics- difficulty in troubleshooting their circuit. This is because when it doesn't work, we do not know whether the problem is due to wire connection or coding.
• Access to GPIO is kind of difficult. There is no label on the pins, you need to search online to get the designated pin and know which pin to connect. For beginners, this definitely will make it harder for them to make the connection correctly.
• No easy way to properly shutdown using a switch. There is no programmable push button to enable proper shutdown through hardware. If the beginner turns off the power without properly shutting it down, the raspberry pi may not work the next time.

Maker pHAT solves all these. It is designed to:

• Simplify to get started with Raspberry Pi without additional monitor, keyboard or mouse (Headless). Go headless with a few simple steps as it enables users to remote access Raspberry Pi through serial.
• Simplify learning electronics. Beginners can skip the hassle of constructing the basic electronic circuit which is boring and time-consuming. Although it is equally important for them to learn about basic electronics, it can always come later after they have experienced how easy it is to create an awesome project. Start with fun and excitement. Start coding right away and see your board lights up and plays sound with the press of a button. It comes with onboard LEDs, pushbuttons, and a buzzer to easily learn how to control input and output. No messy wiring needed and no additional components needed.
• Simplify troubleshooting and prototyping. Not only do the onboard LEDs work as outputs, but they can also act as indicators, clearly showing what's happening on that pin. When the pin is used as input, you can clearly see whether the signal is received by just looking at changes on the LEDs. The pre-soldered header pins come with nice labels. This helps the user to easily connect inputs and outputs to the right pins. This will further assist them in interfacing with sensors and actuators.
• Simplify proper shutdown using pushbutton. You can easily follow the steps and choose one of the pushbuttons as the power button to properly shutdown the Raspberry Pi. Just press the button and it will shut down.

Maker pHAT is designed to be the same size as Raspberry Pi Zero board, it stacks perfectly on top of Rpi Zero with the four mounting holes aligned. (What is a HAT? Read this to know more) We do advise getting Raspberry Pi Zero WH (pre-solder header pin) for beginner because it is not an easy work to solder the 40-pin GPIO, don't forget you'll need to have the soldering tools too.



Maker pHAT is also compatible with Raspberry Pi 3B, 3B , 3A ,  and of course the latest 4B too. You just need to insert the 2x20 stacking header(included), as photo shows:

Maker pHAT is compatible with:

• Raspberry Pi Zero V1.3 (will need to solder 2x20 header pin - NOT included can consider Straight Pin Header (Male) 2x40 Ways)
• Raspberry Pi Zero W (will need to solder 2x20 header pin - NOT included can consider Straight Pin Header (Male) 2x40 Ways)
• Raspberry Pi Zero WH (Ready for plug and use)
• Raspberry Pi 1 https://www.pishop.co.za/store/raspberry-pi-model-aModel A (Will need 2x20 stacking header)
• Raspberry Pi 3 Model A (Will need 2x20 stacking header)
• Raspberry Pi 3 Model B (Will need 2x20 stacking header)
• Raspberry Pi 3 Model B (Will need 2x20 stacking header)
• Raspberry Pi 4 Model B 1GB (Will need 2x20 stacking header)
• Raspberry Pi 4 Model B 2GB (Will need 2x20 stacking header)
• Raspberry Pi 4 Model B 4GB (Will need 2x20 stacking header)

Maker pHAT is now Rev1.10:

Features:

• Raspberry Pi Zero size, stack perfectly on to Pi Zero Series of SBC (Single Board Computer).
• Compatible with standard size Raspberry Pi 3B/3B /4B1GB/4B2GB/4B4GB, medium size Raspberry Pi 3A and smaller size Raspberry Pi Zero/W/WH.
• Standard Raspberry Pi GPIO footprint.
• LED array for selected GPIO pins (GPIO 17, 18, 27, 22, 25, 12, 13, 19).
• 3x onboard programmable push buttons (GPIO 21, 19 and 20, need to configure as input pull up).
• Onboard active buzzer (GPIO 26).
• Proper label for all GPIOs, including SPI, UART, I2C, 5V, 3.3V, and GND.
• Utilize USB Micro-B socket for 5V input and USB to UART communication.
• USB serial facilitated by the CH340, Rev1.10 uses FT231X as the USB to UART
• Input voltage: USB 5V, from the computer, power bank or standard USB adapter.
• PURPLE PCB!

Documents/Tutorials:

• User's Manual
• Schematic Rev1.00 (pdf)
• Schematic Rev1.10 (pdf)
• Sample Python Code (Github)
• CH340 Driver (Windows)
• CH340 Driver (MacOS)
• CH340 Driver (Linux) - Pre-installed
• FT231X Driver on Rev1.10 (Windows, Linux, and macOS)
• PuTTY - For serial terminal
• Raspberry Pi: Mengawal LED di Maker pHAT

Packing List:

• 1 x Maker pHAT
• 1 x 2x20 Stacking Header

The FLIRC Raspberry Pi Zero Case is finally here - overly engineered, affordable and adorable!

The FLIRC Zero shares the same genetics as the original FLIRC case with some added features. FLIRC have kept everything that makes the original case great, shrunk it down, and added some nice elements that make this mini PC for every day carry.

The familiar aluminium casing with a core heatsink and smooth top is there, offering silent, passive and efficient cooling combined with great looks.

The SD Card is enclosed inside the case so it won't slip out or get stolen. The case needs to be disassembled before the SD card can be removed. There’s even a pre-installed lanyard included in the box in case you want to take your Zero somewhere other than the home.

Two top covers are included with the FLIRC Zero – allowing you to hide away and protect your GPIO, or leave it exposed for prototyping your projects. You can even add a pHAT without worrying about your Zero’s temperature.

Notes

1 x The Raspberry Pi Zero’s LEDs are not visible with this case
1 x Lanyard is removable (but fiddly to get back on)
1 x Ships with a thermal pad – fit this to the case heatsink core before fitting your Raspberry Pi Zero

• RS485 half-duplex communication: using SP3485, UART control, auto RX/TX switch
• CAN half-duplex communication: using MCP2515 SN65HVD230 solution, SPI control
• Onboard unibody power supply isolation, provides stable isolated voltage, needs no extra power supply for the isolated terminal
• Onboard photocoupler isolation, prevent interference from external high-voltage circuit connected to the relay
• Onboard TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient spike voltage in the circuit, lightningproof & anti-electrostatic
• Onboard resettable fuses and protection diodes, ensuring current/voltage stable output, preventing over current/voltage, better shock-resistance performance
• High quality relay, contact rating: ≤10A 250V AC or ≤10A 30V DC
• ABS protection enclosure with rail-mount support, easy to install, safe to use
• Comes with development resources and manual (wiringPi and python examples)

•     Designed for Raspberry Pi Zero, compatible with Zero series boards
•     Incorporates RTL8152B Ethernet chip, with 10M / 100M auto-negotiation RJ45 port
•     PoE (Power over Ethernet) feature, 802.3af-compliant
•     Fully isolated SMPS (Switch Mode Power Supply)
•     3x extended USB ports, compatible with USB 2.0 / 1.1
•     Angle rounded design, smooth hand feeling, "simple snap" case lid
•     Quality ABS material, dull polish surface, anti-fingerprint
•     Comes with two different lids, changing as you like

USB1 ~ USB3, compatible with USB 2.0 / 1.1

USB to Ethernet conversion by the RTL8152B chip, 10M / 100M auto-negotiation

"simple snap" design, easy to change, allows attaching other Zero HATs



Application example



Outline dimensions





Resources:

What's going to protect your beloved Raspberry Pi from an onslaught of rainbow-coloured fusion? That's right, it's Unicorn pHAT.

Sporting a matrix of 32 (8 x 4) RGB LEDs and powered directly from the Pi, this is the most compact pocket aurora available.

Unicorn pHAT provides a wash of controllable colour that is ideal for mood-lighting, pixel art, persistence of vision effects, status indications, or just blasting colour into your surroundings.

Features

• 32 RGB LEDs (SK6218 - 3.5mm x 3.5mm)
• LED data driven via DMA over PWM
• Unicorn pHAT pinout
• Compatible with Raspberry Pi 3, 2, B , A , Zero, and Zero W
• Python library
• Female header requires soldering

Software

Unicorn pHAT uses the same Python library as Unicorn HAT, so it's super-easy to use, should automatically detect that you're using the pHAT and includes some examples written specially for Unicorn pHAT.

Notes

• Warning: SK6218 LEDs are bright enough to cause eye pain, do not look at them directly when brightly lit. We recommend using Unicorn pHAT at lower brightness levels.
• Photo-sensitivity warning: flashing, strobing, and patterns of lights may cause epileptic seizures. Always take care and immediately stop using if you feel unwell (dizziness, nausea, affected vision, eye twitching, disorientation).
• Power: Unicorn pHAT works best with a >2A microUSB power supply for your Pi. We recommend the official Raspberry Pi power supply.
• Compatibility (audio): as Unicorn pHAT uses PWM and GPIO18, it will interfere with analogue audio playback (random colour patterns and flickering). HDMI should work just fine! :D
